Rollex Medical Matos Installation Manual

Matos

Fridge Installation & Guide

PLEASE READ

Unpacking & Setting Up

When installing the fridge, please ensure that the space is adequate with a minimum 5cm ventilation

gap either side of the machine and above.

Install the two rubber "bungs" in the port hole on the side of the fridge (both inside and outside) and

place the shelves evenly throughout the fridge to assist with air-flow.

If you have a Matos Cloud fridge, install the supplied fuse in the

3.15A battery fuse holder on the back of the fridge.

The use of a surge protector is required for warranty requirements.

You may require force to insert the plug into some models of surge

protector fully to ensure the plug is connected correctly.

This fridge has been pre-programmed and tested by Rollex Medical technicians before being

dispatched to you and no adjustment should be necessary. The refrigerator will not need

reprogramming after being unplugged or a power cut.

Typically the set point is set to 3.5°C and the refrigerator will then cycle above this point. It is normal

for the temperature on the display to change as it shows the current internal probe temperature.

Typically it will cycle between 3.5° – 6°C.

It is recommended you adjust the front feet or install furniture cups to level / tilt the cabinet so that

the door will close from approximately 1 cm.

NOTE: Placing the fridge on carpet is not recommended.

IMPORTANT: Overstocking, poor airflow and doors left ajar can lead to ice buildup and

this may require being manually defrosted.

ROLLEX MEDICAL NZ LTD

38E Highbrook Drive, East Tamaki, Auckland 2013

PO Box 204159, Highbrook, Auckland 2016

Phone: 09 274 0707

Fax: 09 274 0709

Web: www.rollexmedical.co.nz

Email: nzsales@rollexmedical.co.nz

Table of Contents

Need help?

Do you have a question about the Matos and is the answer not in the manual?

Page 1 Install the two rubber “bungs” in the port hole on the side of the fridge (both inside and outside) and place the shelves evenly throughout the fridge to assist with air-flow. If you have a Matos Cloud fridge, install the supplied fuse in the 3.15A battery fuse holder on the back of the fridge.
Page 2 MATOS Override has been activated to bring the internal temperature back up to the correct range. NOTE: The MATOS Override function will only be activated if the unit’s internal temperatures exceed the normal operating range (normally 2-8°C).
Page 3 To view the Average, Maximum and Minimum Temperatures… 1. Press the EXIT key The display will show STATISTICS 2. Press the ENTER key The display will show STATISTICS – Tavg the Average Temperature, in this example 3.5°C 3. Press the DOWN key The display will show STATISTICS –...
Page 4 3 seconds to turn the internal light on/off. If you would like any further clarification on any of these matters please get in touch with us. Rollex Medical NZ Limited Postal Address: PO Box 204159, Highbrook, Auckland 2161, New Zealand...
