DuctSox SimpleSox Installation Manual

Thank you for selecting a SimpleSox
SimpleSox . Sections of fabric will be labeled, assembled, bagged, and boxed for shipping.
TM

Overview

Inventory

F o n t i s F u t u r a M d B T
The first step on any installation project is to check the order and familiarize yourself with what needs
M e d i u m I t a l i c
to be installed. We suggest reading through this manual completely to properly educate yourself on field
installation. Please make sure you have all the required components for the SimpleSox

Equipment Required:

• Drill
T e x t i l e A i r D i s p e r s i o n P r o d u c t s
• Screwdriver
• Tape measure
• Marker or pencil
• 5/16 nut driver
• Ladder or lift for extended heights

Available Components/Details

NOTE: We always provide
20% more cable. There will
actually be 120' of cable
included in the kit.
1
System. This guide should be helpful for installing
TM
Cable Assembly Kit
(includes 2 turnbuckles, 2 thimbles,
2 eyebolts, 4 cable clamps, and
100' of cable)
1.5' Section
2' Adjustable
Air Outlet
10' Section
Installation Guide
Adjustable Fabric Air Dispersion System
1' Inlet
5' Section 90 Degree Elbow
15' Section
Installation Guide: SimpleSox
System.
TM
0.5' Endcap Adjustable Flow
Device
(Fabric Mesh Damper)
Twisty
Cross Reducer
TM
System
