Glider Assembly Instructions
Package Contents
1 - Seat (A)
1 - Back (B) -
1 - Left Arm (C)
style may vary
1 - Right Arm (D)
Tools needed:
• 7/ 1 6 Wrench
• 1/ 2 Wrench
• Rubber Mallet or Hammer
• #2 Square Drive Screwdriver
or Power Drill ∕ Driver
NOTE: Do not tighten any bolts
until step 4 is completed.
1 - Right Base Leg (E) 1 - Left Base Leg (F)
2 - Base Crosspiece (G)
4 - Glider Bearing (O)
Package contents continued on inside.
Advertisement
Table of Contents
Summary of Contents for AAA Storage Sheds Glider
- Page 1 1 - Right Base Leg (E) 1 - Left Base Leg (F) 1 - Back (B) - style may vary 2 - Base Crosspiece (G) 4 - Glider Bearing (O) 1 - Left Arm (C) 1 - Right Arm (D) Package contents continued on inside.
- Page 2 Package Contents Continued from front page Hardware Package 14 - ¼" Flange Nut (I) 10 - ¼" Short Bolt (H) 4 - ¼" Long Bolt (J) ⁄ "Washer (L) ⁄ " Locknut (M) ⁄ " Bolt (K) 1 - Bit (P) 12 - 1¾"...
- Page 3 Step 6 To assemble the glider base, you have to attach the base crosspieces (G) to the base legs (E) and (F) using 1¾" screws (N) NOTE the difference in the front and the back of the base as shown in figure (A) and figure (B) below.
- Page 4 (heads facing in). Slide a washer (L) onto the bolt, and then attach it to the glider bearing (O) with a lock nut (M). Repeat on all four corners. Now tighten ALL your bolts, and your glider is...
