ARC Motion Sensor Instructions
The ARC Motion Sensor is used to detect motion on a shade. The result of strong vibration
can trigger a paired awning motor to move the shade to its home position for protection.
The motion sensor can only be programmed to operate External Motors (15Nm and
upwards).
FEATURES:
•
Compatible with AUTOMATE awning motors and controllers
•
Suitable for fitting to awning terminal bars
•
Provides protection from excessive wind gusts
•
9 x levels of sensitivity
•
Low battery warning
™
433 MHZ
BI-DIRECTIONAL
Advertisement
Table of Contents
Summary of Contents for rollease acmeda AUTOMATE ARC Motion Sensor
- Page 1 AUTOMATE ™ ARC Motion Sensor Instructions 433 MHZ BI-DIRECTIONAL The ARC Motion Sensor is used to detect motion on a shade. The result of strong vibration can trigger a paired awning motor to move the shade to its home position for protection. The motion sensor can only be programmed to operate External Motors (15Nm and upwards).
-
