STUDER K + I
Kommunikation und Informatik
Emergency and Information Telephone NIT 960
Caution!
For emergency use, connect EXICALL ® NIT 960 to a
direct exchange line whenever possible. This
ensures that emergency calls can still be made in the
event of a power failure (failure of the subscriber's
switchboard or internal telephone exchange).
Programming can be performed only with the exchange
line and power supply connected!
See pages 5 and 6 for instructions
New: Remote control
s/n 1000 onwards)
(10 commands possible during the call,
*additional contact K3, plus remote hang-up
New: Seizure relay option
(separate box, contact K4)
New: Day/night switch
(additional function: ext. ack. contact K2)
New: Explosion protection
(Zone 2, T1 - T6, SW27)
Brief Tech. Description
Copyright © 1997 Studer K+I, CH-3074 Muri BE. All rights reserved.
EX-E99-TK.doc / 17 / Tog / 31.08.2006
STUDER K + I
Kommunikation + Informatik
Tavelweg 2
CH-3074 Muri BE
EXICALL
Article Number: 121.5000
(standard from
Description pages 7 and 8
Phone
031 959 11 11
Fax
031 959 11 44
Mobile
079 302 11 11
STU D ER
®
7 pulse lengths from 2-8 seconds*
1 pulse, held until end of call *
1 test, acknowledgement contact
1 remote call termination
)
1 floating contact output,
closed when seized
Choice of separate day/night
telephone numbers., selectable via
a floating contact
SEV/ESI certificate A.no.96.1 10403
Ex-classification Ex nVL IIC T6
Web:
www.studercom.ch
Email: info@studercom.ch
®
Page 1 of 8
PC no. 30-7032-0
MWSt. no. 367 246
Gewerbekasse in Bern
Advertisement
Summary of Contents for Studer EXICALL NIT 960
- Page 1 (Zone 2, T1 - T6, SW27) Ex-classification Ex nVL IIC T6 Description pages 7 and 8 Brief Tech. Description Copyright © 1997 Studer K+I, CH-3074 Muri BE. All rights reserved. EX-E99-TK.doc / 17 / Tog / 31.08.2006 Page 1 of 8 STUDER K + I...
- Page 2 STU D ER ® STUDER K + I Kommunikation und Informatik Table of Contents Chapter Page EXICALL Technical Data ................Customised EXICALL Programming ............EXICALL Local Programming ..............EXICALL Remote Programming ..............Additional Functions and Modifications for software version V02.22..
- Page 3 STU D ER ® STUDER K + I Kommunikation und Informatik 1. Technical Data Power supply Voltage range 11V – 60V DC or 11V – 42V AC Power consumption Max. 2.5W Safety level EN 60950 / EN 41003 Safety low voltage electrical circuit (SLEV circuit) Caution: The TNV electrical circuit can carry hazardous voltages up to 120V DC.
- Page 4 STU D ER ® STUDER K + I Kommunikation und Informatik User interface Visual display Backlit LCD Text messages Choice of - German - French - Italian - English or multilingual cycling Locally on unit Via DTMF keypad and visual...
- Page 5 STU D ER ® STUDER K + I Kommunikation und Informatik 2. Customised EXICALL Programming (software version V02.22) EXICALL connection: Exchange line internal Tel. no. _____ /_____________ Name ___________________ Company __________________ Tel. no. ___________________ 1. sub-menu sub-menu sub-menu selection (status) default progr customer progr.
- Page 6 STU D ER ® STUDER K + I Kommunikation und Informatik ® 3. EXICALL Local Programming Log-in: (exchange/switchboard A/B cable and power supply connected!!) Place TTW pad on loudspeaker: Press no. 1, then also simultaneously 1 + key hold down Exicall key...
- Page 7 STU D ER ® STUDER K + I Kommunikation und Informatik 5. Additional functions and modifications in software version V02.22 5.1 Password handling New: up to 6 incorrect password entries are allowed, after which a 3 minute pause must be observed.
- Page 8 STU D ER ® STUDER K + I Kommunikation und Informatik 6.24 Answer to status request External acknowledgement when contact K2 is activated: EXICALL hangs up External acknowledgement when contact K2 is open: no action 6.3 Terminal Assignment Exicall (S/N 1000-R and up) now has a floating output contact K3:...
