MANUAL
1 Product Summary
1.1 Product Pro le
BAT/47914 Battery Tester adopts currently the world's most advanced conductance testing technology to easily, quickly and accuratel y measure
the actual cold cranking amps capability of the vehicle starting battery, healthy state of the battery itself, and common fault of the vehicle
starting system and charging system, which can help maintenance personnel to nd the problem quickly and accurately, thus to achieve
quick vehicle repair.
1. Test all automotive cranking lead acid battery, including ordi nary lead acid battery, AGM at plate battery, AGM spiral battery, and Gel
battery, EFB battery, etc.
2. Directly detect bad cell battery.
3. Polarity reverse connection protection, reverse connection will not damage the tester or a ect the vehicle and battery.
4. Directly test the battery with loss of electricity, no need to full charge before testing.
5. Testing standards include currently the world's majority of battery standards, CCA, BCI, CA, MCA, JIS, DIN, IEC, EN, SAE, GB.
6. Support multi-languages, customer can select di erent language package, which includes: Chinese Simple, Chinese Traditional, English,
Japanese, Russian, Spanish, French, Ita lian, German, etc. Other languages can also be customized according to user's need.
1.2 Product Function
Main functions of BAT/47914 battery tester include: battery test, cranking test, charging test and other additional functions.
Battery test is mainly targeted to analyze the battery healthy status to calculate the actual cold cranki ng capability of the battery and the
aging extent, which provide reliable analysis evidence for the test and maintenance of the battery. It noti es the user to rep lace battery in
advance when the battery getting aged.
Cranking test is mainly to test and analyze the starting motor. Through te sting the actual required crank ing current and cranking voltage of
the starting motor, it can nd out whether the starting motor works ne. There are several reasons why the starting motor is abnormal:
lubricating system fault causing the starting loaded torque increasing or rotor friction of the starting motor causing the increasing friction of
the starting motor itself.
Charging test
is to check and analyze the charging system, including generator, recti er, recti er diode, etc., thus to nd out whether t he
output voltage of the generator is normal, the recti er diode works ne and the charging current is normal. Suppose one of the above
mentioned parts is not in normal situation, it will lead to over charge or incomplete charge of the battery, thus the battery will be quickly
damaged and also greatly shorten the using li fe of other loaded electrical appliance.
Additional functions include: Set language, voltmeter and screen brightness adjustment.
1.3 Technical Parameters
1. Cold Cranking Amps Measure Range:
M
e
s a
2. Voltage Measure Range: 8-30V DC
www.aqtron.com - info@aqtron.com
u
e r
S
a t
n
a d
d r
C
C
A
B
I C
C
A
M
C
A
J
S I
D
N I
E I
C
E
N
S
A
E
G
B
BAT/47914
M
e
s a
u
e r
R
a
n
g
e
1
0
0
2 -
0
0
0
1
0
0
2 -
0
0
0
1
0
0
2 -
0
0
0
1
0
0
2 -
0
0
0
2
6
A
1
- 7
2 -
4
5
H
5
2
1
0
0
1 -
4
0
0
1
0
0
1 -
4
0
0
1
0
0
2 -
0
0
0
1
0
0
2 -
0
0
0
1
0
0
1 -
4
0
0
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BAT/47914 and is the answer not in the manual?

Questions and answers

Summary of Contents for AQ-Tron BAT/47914

  • Page 1 1.1 Product Pro le BAT/47914 Battery Tester adopts currently the world's most advanced conductance testing technology to easily, quickly and accuratel y measure the actual cold cranking amps capability of the vehicle starting battery, healthy state of the battery itself, and common fault of the vehicle starting system and charging system, which can help maintenance personnel to nd the problem quickly and accurately, thus to achieve quick vehicle repair.
  • Page 2 MANUAL BAT/47914 1.4 Working Environment Requirement Working Environment Temp.: -20°C-60°C It is applicable for automotive manufacturers, automotive maintenance and repair workshop s, automotive battery factories, automotive battery distributors, and educat ional organizations, etc. 2 PRODUCT INFORMATION 2.1 Tool Description Up / Down keys: Select upwards or downwards via white UP and DOWN keys.

  • Page 3: Product Setup

    MANUAL BAT/47914 2) USB cable -- Provides link to tool and computer for print.. 3). CD--- Print software inside. 2.4 Product Setup The tool allows you to make the following adjustments and settings: 1) Language: Selects desired language. 2) Contrast adjustment: Adjusts the contrast of the LCD display.

  • Page 4: Tool Information

    MANUAL BAT/47914 Tool Information From Tool Setup menu, use Enter button to select Tool Information Press exit to return the previous menu. Tool Information Software Version: 1.00 Hardware Version: 1.00 3 Battery Test After entering battery test program, tester displays the tester model and version Tester will display the following contents in a sequence, select accordingly.
  • Page 5 MANUAL BAT/47914 2) Good, Recharge Healthy:78% 440CCA Charge:30% 12.20V Internal R=7.2m Rated: 500A GOOD, RECHARGE Good battery but low current, recharge before using. 3) Replace Healthy:46% 490CCA Charge:80% 12.68V Internal R=18.1m Rated: 500A REPLACE The battery is near to or already reached the end of the using life, replace battery, otherwise , bigger danger will be followed .
  • Page 6 Battery System Standard and Rating BAT/47914 battery tester will test each battery according to the selected system and rating. Use UP/DOWN key to select according to the actual system standard and rating marked on the battery. Use UP/DOWN key to select according to the actual system standard and rating marked on the battery.
  • Page 7 MANUAL BAT/47914 EN ： European Automobile Industry Association Standard SAE: Society of Automotive Engineers Standard GB ： China National Standard Select Input Rating range as following: Measure Standard Measure Range Input correct test standard and rating, press ENTER key, tester starts to test, and dynamic interface "TESTING" prompted. See below: Setting Rate It takes around 3 seconds to display the battery test result.

  • Page 8: Cranking Test

    MANUAL BAT/47914 2) Good, Recharge Healthy:78% 440CCA Charge:30% 12.20V Internal R=7.2m Rated: 500A GOOD, RECHARGE Good battery but low current, recharge before using. 3) Replace Healthy:46% 490CCA Charge:80% 12.68V Internal R=18.1m Rated: 500A REPLACE The battery is near to or already reached the end of the usi ng life, replace battery, otherwise , bigger danger will be followed .
  • Page 9 MANUAL BAT/47914 Cranking Test RPM Detected Normally, cranking voltage value lower than 9.6V is regarded as abnormal and it is ENTER if it is higher than 9.6V. Test result of the tester includes actual cranking voltage and actual cranking time.
  • Page 10 MANUAL BAT/47914 Charging Test Increasing RPM to 2500 r/min And keep it 5 seconds. Press OK to continue. Operate accordingly to increase the engine rotating speed to 2500turns or above, and keep for 5 seconds. Tester starts the charging volt te st after increase rev detected.
  • Page 11 Battery System Standard and Rating BAT/47914 battery tester will test each battery according to the selected system and rating. Use UP/DOWN key to select according to the actual system standard and rating marked on the battery. Use UP/DOWN key to select according to the actual system standard and rating marked on the battery.
  • Page 12 MANUAL BAT/47914 Rating range as following: Measure Standard Measure Range Input correct test standard and rating, press ENTER key, tester starts to test, and dynamic interface "TESTING" prompted. See b elow: Setting Rate It takes around 3 seconds to display the battery test result.

  • Page 13: Review Data

    MANUAL BAT/47914 2) Good, Recharge Healthy:78% 440CCA Charge:30% 12.20V Internal R=7.2m Rated: 500A GOOD, RECHARGE Good battery but low current, recharge before using. 3) Replace Healthy:46% 490CCA Charge:80% 12.68V Internal R=18.1m Rated: 500A REPLACE The battery is near to or already reached the end of the usi ng life, replace battery, otherwise , bigger danger will be followed .

  • Page 14: Print Data

    MANUAL BAT/47914 Healthy:96% 490CCA Charge:98% 12.64V Internal R=6.1m Rated: 500A GOOD BATTERY 3.5 Print Data Before choose the print data function, it is necessary to connect the tool to the computer via USB cable. Once all are available, please kindl y insert the CD to the computer Install the USB driver rstly.

  • Page 15: System Setup

    MANUAL BAT/47914 Main Menu 1.Quick Test 2.Battery in Vehicle 3.Out of Vehicle 4.Review Data 5. Print Data 6.System Setup 5.Once the data is transferred to the computer, the print software will show these information Healthy:96% 490CCA Charge:98% 12.64V Internal R=6.1m...
