- Page 1 Operating Instructions ATMOS Cam 41 HD ® English GA1GB.150404.0 2017-07 Index 03...
-
Page 2: Table Of Contents
Table of contents Introduction ........3 4.9 Freeze or take pictures ....16 1.1 Notes on operating instructions ..3 4.10 Perform white balance ....16 1.2 Explanation of pictures and 4.11 Perform pixel error correction ..16 symbols..........4 Cleaning and Disinfection ... 18 1.3 Intended use ........4 5.1 Camera control unit ......18 1.4 Function ..........5... -
Page 3: Introduction
Read chapter „2 Hints for your safety“ on page 7 before using the device for the fi rst time. This helps you avoid potentially dangerous situations. The product ATMOS Cam 41 HD bears CE marking CE according to the ® EC Directive of the council for medical products 93/42/EEC and meets the basic requirements of Appendix I of the directive. -
Page 4: Explanation Of Pictures And Symbols
Freeze image (on camera Take a picture (on camera head) head) Zoom (on camera head) 1.3 Intended use Name: ATMOS CAM 41 HD ® Main functions: The ATMOS CAM 41 HD is an endoscopy camera for displaying the ® Introduction... -
Page 5: Function
The ATMOS Cam 41 HD consists of a camera head and a camera control unit with an ® endoscope coupler. The 3 m long connecting cable on the camera head is connected to the camera control unit. -
Page 6: Intended Users
2. Fill in the form QD 434 “customer complaint/return shipment”. This form is enclosed to each delivery and can be found at www.atmosmed.com. 3. Send in the device to ATMOS (chapter „6.4 Sending in the device“ on page 22). Ambient conditions for transport and storage: •... -
Page 7: Hints For Your Safety
2 Hints for your safety The safety of the ATMOS Cam 41 HD complies with all the recognized rules of technolo- ® gy and the guidelines of the Medical Products Law. Read and follow the safety instructions carefully before using the product. - Page 8 2.3 Damage to the device Avoid sun and bright light sources. The sensor in the camera head will be damaged. • Attach the lens cover when you are not using the camera. • Never hold the camera in the sun or in bright light sources. Avoid incorrect handling, storage or transport Connection cable, camera head or camera control unit could be damaged.
-
Page 9: Setting Up And Starting Up
3 Setting up and starting up 3.1 Device overview Front view camera control unit Button o Green LED Button L ight ouRCeS Button M Camera head connection Rear View camera control unit Video output DVI-D Video signal output S-Video Video signal output composite No function No function Video signal output RGB... -
Page 10: Connection Diagram
Camera head Focus wheel on the endoscope coupler Endoscope connection Camera head Camera head buttons Connection cable Cap for camera plug Camera plug Red sealing ring on the C-mount adapter 3.2 Connection diagram Labelling Connection DVI-D Monitor S-Video Monitor or grabber Composite Video Monitor RGB/YPbPr... -
Page 11: Connecting The Device
2. If the device is damaged: Document and report the transport damage. Send the device to ATMOS, see chapter „6.4 Sending in the device“ on page 22. 3. Refer to the guidelines for medical electrical systems in chapter „3.3 Use with other devices“... -
Page 12: Operation
21. 1. Press the button o » The green LED on the button illuminates. » A white background with an ATMOS logo appears briefl y on the monitor. 4.3 Switch off the device 1. Press the button o » The green LED on the button no longer illuminates. 4.4 Connect and remove the camera head Connect the camera head 1. -
Page 13: Attach And Remove The Lens Protection
4.5 Attach and remove the lens protection On one side the lens protection can be screwed to the camera head. On the other side the lens protection can be attached to the endoscope connector of the endoscope coupler. Camera head 1. -
Page 14: Set The Buttons Of The Camera Head
4.7 Set the buttons of the camera head 4.7.1 Factory settings Button assignment during operation Button Push duration Function Short Take a picture (only if recording device is connected) Long No function Short Freeze image ight Long Rotate the image by 180 degrees Short Zoom in predetermined steps entRe... -
Page 15: Adjust Image
Display setup menu Function Setting options Amplification Off; Min; Medium; High Gain White balance Pixel error correction Freeze image Freeze; release Freeze Increase zoom level 1.0 to 2.5 Zoom up Reduce zoom 2.5 to 1.0 Zoom down Continuous zoom levels 1.0; 1.2; 1.4; 1.6 Zoom Loop Mirror the image horizontally On; Off Mirror Rotate the image by 180... -
Page 16: Sharpen The Image
2. Repeatedly press the L button briefly on the front side of the camera ight ouRCeS control unit to select the light source. 3. Perform a white balance. See chapter „4.10 Perform white balance“ on page 16. & If the colour temperature of the preceding light source differs greatly, you may need to perform the white balance twice. 4.8.3 Sharpen the image 1. - Page 17 • ABB OK: Pixel error correction performed successfully. • Error message: Pixel error correction could not be carried out. Possible error messages Error message Possible cause Remedy Lens protection not 1. Attach the lens protection to the ABB NOT GOOD / attached properly.
-
Page 18: Cleaning And Disinfection
5 Cleaning and Disinfection We recommend that you always document all maintenance work and exchange of parts in writing. WARNING Risk of infection due to secretion on the device. Deadly diseases can be transmitted. • Always wear disposable gloves during any cleaning. •... -
Page 19: Automated Cleaning And Disinfection
3. Check that the endoscope coupler fi ts well and the red seal on the C-mount adapter exists. 4. Rinse the camera head with connection cable and endoscope coupler under running water. 5. Rinse with deionized water. 6. Dry the camera head with connection cable and endoscope coupler with a dry cloth. 7. Dip the camera head with connection cable and endoscope coupler in disinfectant solution. -
Page 20: Instrument Disinfectants
5.3.1 Instrument disinfectants Camera head • Kohrsolin 5.3.2 Surface disinfectant Camera control unit • Surface disinfectant 20 Cleaning and Disinfection... -
Page 21: Maintenance And Service
To carry out these measures the person must have the necessary test devices and original spare parts. ATMOS recommends: Work should be carried out by an authorized ATMOS service partner. This ensures that repairs and testing are carried out professionally, original spare parts are used and warranty claims remain unaffected. -
Page 22: Sending In The Device
5. The device must be well padded and packed in suitable packaging. 6. Place the form QD 434 „Delivery complaint / return shipment“ and the respective decontamination certificate in an envelope. 7. Affix the envelope to the outside of the package. 8. Send the product to ATMOS or to your dealer. 22 Maintenance and Service... -
Page 23: Troubleshooting
7 Troubleshooting The ATMOS Cam 41 HD was subjected to a thorough quality control in the factory. ® However, should an error occur, you may be able to solve this yourself. Error indication Possible cause Remedy Device is not Device is not switched on. -
Page 24: Accessories
8 Accessories Options MediCapture On request ATMOS Strobo 21 LED 507.4700.0 ® ATMOSoft ENT 31 license dongle 700.0039.0 ATMOSoft ENT 41 license dongle 700.0040.0 ATMOSoft GYNE 31 700.0037.0 ATMOSoft GYNE 41 700.0038.0 Cable Connecting cable S-VHS, L = 1 m 008.0635.0... -
Page 25: Spare Parts
9 Spare parts Spare part Camera head 507.5501.0 Endoscope coupler 507.5502.0 Mains cable 507.0859.0 Spare parts... -
Page 26: Disposal
® 1. Clean and disinfect the device. 2. In Germany: Send in the device to ATMOS or your specialized dealer. They will dispose of the device professionally. 3. In other countries: Dispose of the device professionally and according to coun- try-specific laws and regulations. -
Page 27: Technical Data
11 Technical data Standard Image sensor 1/3 type CCD Sensor size (width x height) 5.59 mm x 4.68 mm Minimal lighting 0,1 lx (F1.4) Shutter speed Auto: 1/50 s to 1/100000 s Trigger OFF: 1/50 s Signal-to-noise ratio 50 dB White balance Triggering automatic white balance Gain control... - Page 28 Ambient conditions Transport / storage Temperature: - 20° C - +60 °C Humidity: 10 % - 90 % without condensation Air pressure: 70 – 106 kPa Operation Temperature: +10 - + 40 °C Humidity: 30 % - 75 % without condensation Air pressure: 70 – 106 kPa 28 Technical data...
-
Page 29: Notes On Emc
Guidance and manufacturer's declaration - electromagnetic emissions The ATMOS Cam 41 HD is intended for use in the electromagnetic environment spec- ® ified below. The customer or user of the ATMOS Cam 41 HD should ensure that it is ®... - Page 30 U the UT) cial or hospital environment. variations for 0,5 Cycles for 0.5 Cycle If the user of the ATMOS ® according to IEC Cam 41 HD requires contin- 40 % U 40 % UT 61000-4-11 ued function during interrup-...
- Page 31 Cam 41 HD is used exceeds the above compliance level, the ATMOS ® ® Cam 41 HD is to be observed to verify the intended use. If abnormal performance characteristics are noted, additional measures might be necessary, e. g. a changed arrangement or another location for the ATMOS Cam 41 HD ®...
- Page 32 Recommended safety distance between portable and mobile RF Communications equipment and the ATMOS Cam 41 HD ® The ATMOS Cam 41 HD is intended for use in electromagnetic environment in which ® radiated disturbances are controlled. The customer or user of the ATMOS Cam 41 HD ®...
-
Page 33: For Your Notes
13 For your notes For your notes... - Page 34 34 For your notes...
- Page 35 For your notes...
- Page 36 ATMOS MedizinTechnik GmbH & Co. KG Ludwig-Kegel-Straße 16 79853 Lenzkirch / Germany Phone: +49 7653 689-0 atmos@atmosmed.de www.atmosmed.com...
