Hvac 560 Series Operation, Installation And Maintenance Instructions

560 operation, instalation, and maintenance instructions
CAUTION, THIS OZONE GENERATO R PRO DUCES DANGERO US ULTRAVIOLET LIGHT,
SPECIFICATIONS FOR 560 SERIES ozone generator
M axim um output
Cabinet m aterial
Generation m ethod
W eight
Size
INTRODUCTION
This line of ozone generators are designed for installation in to the return duct of an air handling system . This
ozone generator can be used for m any uses such as deodorizing hom es as well as oxidizing m any organic
contam inants.
W ARRANTY (please refer to com plete warranty attached)
The 560 is warranted against defects in m aterials and workm anship for a period of 6 years from date of purchase.
The UV tubes are warranted for 6 m onths. Liability is limited to parts and labor only. Shipping is the sole
responsibility of the custom er. CAMI is not liable for dam age caused by shipping, use, m isuse, neglect or lack of
regular m aintenance.
LIABILITY
CAMI assum es no responsibility for any dam age done to item s from the use or m iss use of any product sold or
m anufactured by CAMI. It is the custom ers responsibility to test m aterials prior to use and to ensure that the
procedure and installation technique they are using is correct for the application.
HEALTH AND SAFETY
Ozone can be an irritant and a powerful oxidizing agent. As with m ost all products, ozone is dangerous only when
used im properly, as such it is important to follow safe usage guide lines.
*W hen doing a shock treatm ent, no people plants or pets/anim als m ay be in the room when the unit is running.*
The room should not be re entered until all ozone has been depleted unless proper breathing respirators are used.
M AINTENANCE FREQUENCY
Under heavy duty use or severely polluted areas, inspect the UV tubes for fine dust build up collecting on UV
generator tube surfaces. Light duty use requires cleaning every 2 to 12 m onths depending on the severity of dust
in the feed air. In severe dusty conditions cleaning can be as often as 4-6 weeks.
DESCRIPTION OF OZO NE GENERATOR
These ozone generators produce ozone by UV light, converting norm al oxygen to ozone gas which is a very strong
oxidizing agent used to destroy odors and other organic contam inants.
PLACEM ENT OF UNIT
This ozone generator is designed to be installed in the return or output side of an air handling system . It is
however recom m ended to install it in the return side before the filter if possible, placem ent before the filter will
increase the efficiency of the filter. It uses 100VAC - 240VAC desktop power adapter for North Am erica and for
European countries. European custom ers will have to supply the proper IEC power cord (this can be acquired at
any com puter shop).
Please note the follow ing points w hen placing the unit.
-Place in a spot in the duct that allows the rem oval of the UV tube without rem oving the entire tube m ount.
-If you wish to treat the entire area heated or cooled it is important to place the tube in the return duct, if
treatm ent of only one duct is required/preferred then install the tube m ount in that duct.
-Ensure that the unit gets proper fresh air flow and is not blocked by anything inside the duct.
-
1. Read instructions thoroughly before operating!!
DISCONNECT POW ER BEFORE OPENING TO SERVICE
560:(560m g/hr) (will produce 615gm /hr for first week)
Stainless steel
Ultraviolet Light
4lb
Control box: 6.75" W X 5.5" H X 4.25"D Tube m ount W/tube: 5.5" x 5.5" x 15.75 long
IM PORTANT!!!!!
