Summary of Contents for Midian VM-3-SM1
- Page 1 VM-3-SM1 Speaker Microphone with Voice Storage Manual Revision: 2012-04-20 Covers Software Revisions: VS-1XXX: 01.53.00 & Higher...
-
Page 2: Hardware Specifications
2. Program the unit per the Product Programming Section of this manual. 3. Install the unit into the radio per the Hardware Installation Section of this manual. *** Midian is not responsible for any damage/loss resulting from the use of Midian’s products. -
Page 3: General Information
GENERAL INFORMATION Midian’s VM-3 is a voice storage speaker microphone for use in two-way radios. The VM-3 can record approximately 3 minutes of voice messages. Recording of voice messages occurs when the unit detects VOX. A button on the radio can then be used to play back what was recorded. -
Page 4: Hardware Installation
SM1. Charging: To charge the unit, plug the Midian supplied wall power adaptor into an outlet and then plug the 3.5 mm plug into the 3.5 connector on the unit. When the LED is glowing green the unit is charging. When the LED is not lit then it is done charging. -
Page 5: Product Programming
PRODUCT PROGRAMMING Midian’s SM-1 products are programmed via Midian’s KL-4 and KL-4 Option B. Please reference the KL-4 manual for setup instructions of the programming software and hardware. From the product selection screen in the software, select the VM-3-SM1 from the list and click OK. - Page 6 Store on COR/Store on VOX: Note: If connecting to a portable radio then VOX will most likely have to be used, as most portable radios do not provide a COR indication. Select the appropriate method that the unit should use to come out of power save.
- Page 7 Enable Call LED: Not used in this product. Receiver Stops Playback: Unless this box is checked, transmissions received off the air will not be heard while the unit is in playback mode. If this box is checked, playback mode will be stopped when COR (or VOX) becomes active so that receiver audio can be heard.
- Page 8 These fields set how the switch is used (short press, long press or double press) and for which function (record start or stop, playback start or stop, etc.). COR > Active Polarity: This sets whether the unit looks for an active low or active high to start recording the received audio.
- Page 9 PTT > Active Polarity: This sets the polarity necessary for the unit to assert the PTT of the radio. These fields set how the switch is used (short press, long press or double press) and for which function (record start or stop, playback start or stop, etc.).
- Page 10 Tones > Beep Volume: Adjust the slider for the desired beep volume. This level is expressed as a percentage of max voice audio level. Playback Level: This sets the volume level of the recorded voice to the radio’s speaker. Transmit Level: Not used in this product.
- Page 11 See the next page for instructions on the Voice Audio Levels.
- Page 12 AUDIO LEVELS ALIGNMENT This section describes how to determine and set the audio levels. The procedures below can be used to approximate the response of the internal microphone. These measurements must be taken within 15 seconds of powering the unit on. This is because the unit may enter power saving mode after that time.
-
Page 13: Operation
OPERATION The SM1 has three buttons; PTT, Button 1 and Button 2. The PTT button is the larger oblong button, Button 1 is the top round button with one nub and Button 2 is the bottom round button with two nubs. PTT Button: The PTT button is used to send a PTT command to the radio to cause the radio to transmit, as well as send the ANI, Emergency ANI and recorded voice messages. -
Page 14: Technical Notes
However, some features may not be available in the radio when an option board is used. If a feature is not available, please contact Midian to see if the feature can be added.
