Item Number: A03278
WARNING (To reduce the risk of fire, electric shock, or injury to persons):
1. We suggest installation by a licensed electrician.
2. Please read the instruction carefully and save it as you may need it at later time.
3. Before you start, NEVER attempt any work without shutting off the electricity until the work is done. A). Go
to the main fuse, or circuit breaker, box in your home. Place the main power switch in the "OFF" position. B).
Place the wall switch in the "OFF" position.
4. Mounting surface should be clean, dry, flat, strong enough and 1/4" larger than the canopy on all side. Any
gaps between the mounting surface and canopy exceeding 3/16" should be corrected as required.
5. Make sure that the ceiling or wall can stand the weight of the lamp before fixture.
6. Make sure the voltage you are using is 120V. The maximum wattage is 60W per bulb.
7. Keep the lamp away from acidic and basic objects in case of damaging the surface of the lamp.
8. When replacing bulb, you should turn off or unplug the lamp and you must wait until it is cool as bulbs get
hot quickly.
9. The safety instructions appearing in this manual are not meant to cover all possible conditions that may
occur. It must be understood that common sense, caution and care must be used with any electrical products.
IMAGE FOR FINISHED PRODUCT：
TOOLS REQUIRED (NOT INCLUDED):
Before doing assembly and installation please prepare the needed tools as below picture
Working hours : Mon - Fri
9:00 a.m. - 16:00 p.m. EST
www.ihomeangel.com
support@ihomeangel.com
Page: - 1 - / 3
Advertisement
Table of Contents
Related Manuals for HomeAngel A03278
Summary of Contents for HomeAngel A03278
- Page 1 Working hours : Mon - Fri 9:00 a.m. - 16:00 p.m. EST Item Number: A03278 WARNING (To reduce the risk of fire, electric shock, or injury to persons): 1. We suggest installation by a licensed electrician. 2. Please read the instruction carefully and save it as you may need it at later time.
- Page 2 +1 850 296 2377 support@ihomeangel.com Working hours : Mon - Fri 9:00 a.m. - 16:00 p.m. EST PARTS TYPE & QTY INCLUDING: (A) Mounting plate assembly (1) (B)Green ground screw (1) (E) Back plate (1) (F) Ball knob (2) (G) Knob nut(4) (H) Loam cake(1) (I) Fixture frame(1) ACCESSORIES &...
- Page 3 +1 850 296 2377 support@ihomeangel.com Working hours : Mon - Fri 9:00 a.m. - 16:00 p.m. EST Step A3: Make wire connections Connect wires as below wires connecting shown. TAKE NOTE OF YOUR WIRE COLOR OF FIXTURE ,NEVER CONNECT WIRE TO GROUND WIRE Connect ground wire according to below chart Connect wires according to below chart Twist plastic wire connector until wires are tightly joined together,wrap each connector with approved electrical tape.
