- Page 1 Deluxe Toe Jack Instruction Manual Models 6-ton, 10-ton and 25-ton 12 Timber Lane • Marlboro NJ 07746 tel:732.462.6277 • fax:732.462.6355 email: sales@hilmanrollers.com 09/06/2019...
- Page 2 CONTENTS INTRODUCTION OPERATING INSTRUCTIONS SAFETY WARNINGS MAINTENANCE AND STORAGE TROUBLESHOOTING 9-10 SPARE PARTS LIST LIMITED WARRANTY...
-
Page 3: To Avoid Injury
Thank you For choosing a Deluxe Hilman Toe Jack The Deluxe Hilman Toe Jack enables you to lift heavy loads, machines and other items safely. Please read and comply with this user manual and the safety warnings prior to the use of these toe jacks to protect you and others. - Page 4 Deluxe Hilman Toe Jack User Manual Before you start using your new Hilman Deluxe Toe Jack, please check the following: - The weight you have to lift (A)? - Center of gravity? - Which toe height fits best (B)? - The area where the jack is positioned should...
- Page 5 Lifting and lowering using an external pump: Use only an external pump that can be pressure- regulated to a maximum pressure of 7540 psi (520 bar) -Connect the pump (hand or power) to the jack with a high pressure hose with the correct fittings (A). -Close the valve on the toe jack as shown in step 3 (B).
- Page 6 Always make sure that bystanders and children are away from the work area. Cordon off a NO-GO area with cones and tape, etc. The NO-GO area must be the area of the load plus a radius around the load of at least 1.5 times the highest dimension of the load.
-
Page 7: Troubleshooting
Before you start working you should fully understand that lifting and shifting heavy loads brings different risks and is dangerous. Therefore please follow this manual, ensuring that everyone who is using this equipment has fully read and understood this manual and the safety warnings. - Page 9 Please supply with your order the correct part number, quantity required and description as well as the type of the jack and serial number. If a repair has to be carried out, please send only the defective parts. Thank you. Spare parts, universal Pos.
- Page 10 Spare parts specific Pos. Description HTJ-6D HTJ-10D HTJ-25D Diagram 3: Pump /cylinder S/G-FLT 950620000 950620000 950620000 Cylinder XR 991103045 991103100 991103250 Screw cylinder S/G-FLT 990191019 990179007 990179007 Cylinder XR 990191022 990191023 990191025 Frame S/G-FLT 950610101 950610101 950610101 Frame XR 950610101 950610101 950610101 Swiveling leg...
- Page 11 LIMITED WARRANTY We warrant each new Hilman Toe Jack sold by us to be free from manufacturing defects in normal service for a period of one (1) year commencing with delivery of the Toe Jack to the original user. Our...
- Page 12 ____________ ______________________ Approval Stamp: WARNING IMPROPER USE OF HILMAN DELUXE TOE JACKS CAN RESULT IN SERIOUS INJURY TO AVOID INJURY: Always make sure that the load is fully supported by the toe or top plate Jack to rest on solid ground in VERTICAL position ...
