Nexa KD-134A/10Y Instruction Manual

1134

Nexa Trading AB, Box 12200

402 42 Göteborg

13807/KD-134A/10Y

NEXA13807-CPR-001

EN14604:2005/AC:2008

Fire Safety and installed in buildings

The Instruction of Smoke Detector KD-134A/10Y with Lithium battery

Your wise choice of using smoke detector KD-134A/10Y is greatly appreciated. Please read the operation instruction before using

it and keep the instruction well after reading.

Summary:

The smoke detector works on the principle that infrared scatters in the smoke to probe the smoke which is generated by the

incomplete combustion at the initial stage of the fire. It consists of photoelectric system, signal processing identification circuit and

alarm circuit. The infrared scatters on the surface of the smoke when the smoke enters the darkroom of the detector, then the

photoelectric diode receives the scattered light and generates the photoelectric signal current. The photoelectric signal generates

the alarm signal after being processed by the identification circuit, accordingly the purpose of alarming is achieved. The product

KD-134A/10Y has a special design, modern and fashion, small and artistic, and is of convenience to use.

This smoke detector contains a 10-year lithium battery

Power Source: 9V battery Lithium, Long life. Recommended :ULTRALIFE U9VL-J, GOLD PEAK CR-V9, EVE

CR9V/P)

Quiescent current: 6—12uA

Working Temperature: -10℃~+40℃

Alarm decibel: ≥85db/3m

Size: (diameter) 101×34mm

Dust cover included

The instruction of smoke alarm devices

KD-134A/10Y with Lithium battery

Table of Contents

Do you have a question about the KD-134A/10Y and is the answer not in the manual?

Page 1 Fire Safety and installed in buildings The Instruction of Smoke Detector KD-134A/10Y with Lithium battery Your wise choice of using smoke detector KD-134A/10Y is greatly appreciated. Please read the operation instruction before using it and keep the instruction well after reading.
Page 2 Operation: A) Remove the mounting plate from the back of the detector and insert 9V battery. CAUTION! Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.). B) Depress the test button for a few seconds for the detector to sound. When you hear the alarm sound, please release the button (It alarms for two to three times, then stops automatically).
Page 3 Any man-made damage or improper operation of the product are not offered quality guarantee by the company. Receipt of purchase must be presented. You will find the Declaration of Performance (DoP) on our website Manufacturers Nexa Trading AB, Sweden www.nexa.se...
