Abstract
The LAVA STS Product Family allows select Samsung Tablets to be charged while interacting with USB
accessories, and enable a tablet-based kiosk or enclosure to support a variety of applications requiring:
OTG USB Host operation with simultaneous tablet charging
Interaction with USB accessories while charging the tablet
Wired network operation (10/100 Ethernet)
Power over Ethernet (PoE)
The STS Product Family work with out-of-the-box (unrooted) Samsung tablets, and are ideal for
commercial and OEM applications.
This document describes the ports, indicators, and buttons on the STS** Products. This document describes
how to test and setup a STS** device. The term STS** is used in this document to refer to a member of the
Contents
Introduction.....................................................................................................................2
System Requirements ......................................................................................................3
Hardware Testing and Setup............................................................................................4
Hardware Test - Out of the box unit.............................................................................4
Hardware Setup - STS (formerly TL002c) ...................................................................6
Hardware Setup - STS-3U ...........................................................................................7
Hardware Setup - STS-E, STS-2UE, and STS-2UE+ ...................................................8
Hardware Setup - STS-PE, STS-P2UE, and STS-P2UE+.............................................9
Special Instructions for the Samsung Tab 4 ...............................................................10
Tablet Charging (SimulCharge versus Charge-Only Mode) ...........................................11
Ports, Indicators, and Buttons ........................................................................................12
"Mode Select" Button and Indicators.........................................................................12
"Micro-B USB To Tablet".........................................................................................12
"Micro-B USB 5V Power Input" ...............................................................................13
"Micro-B USB Aux 5V Input" ..................................................................................13
"USB-A" receptacles.................................................................................................13
"ETHERNET" Port and Indicators ............................................................................14
"PoE-ETHERNET" Port and Indicators.....................................................................15
"PoE power" Indicator...............................................................................................15
Power over Ethernet (PoE) ............................................................................................16
STS Module (formerly TL002c) ....................................................................................17
Dimensions ...................................................................................................................19
Technical Support .........................................................................................................20
History ..........................................................................................................................20
STS Product Family
User Manual
April 28, 2015
Revision A01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STS Series and is the answer not in the manual?

Questions and answers

Related Manuals for Lava STS Series

Summary of Contents for Lava STS Series

  • Page 1: Table Of Contents

    User Manual Abstract The LAVA STS Product Family allows select Samsung Tablets to be charged while interacting with USB accessories, and enable a tablet-based kiosk or enclosure to support a variety of applications requiring: OTG USB Host operation with simultaneous tablet charging...

  • Page 2: Sts Product Family

    The term STS** is used in this document to refer to a member of the STS Product Family. The LAVA product referred to as simply the “STS” is a 1-Port USB member of the LAVA STS Family of devices. This product is a single board OEM device. This product was formerly designated the TL002c.

  • Page 3: System Requirements

    SM-P900 Samsung Galaxy Note Pro (12.2”) Please check the LAVA Web Site for updates to the STS Product Compatibility Matrix. As new tablets are introduced, the Compatibility Matrix on the web site will be updated. The features used by the STS** Products are not universal across the Samsung Tablet line. Variations may also occur based on world region.

  • Page 4: Hardware Testing And Setup

    LAVA Computer MFG STS Product Family User Manual – A01 Hardware Testing and Setup Hardware Test - Out of the box unit This section describes how to confirm a STS** device is functional and verifies interaction with a tablet. The USB Hub feature of a STS** device requires no special setup within a tablet. STS** products with an Ethernet adapter requires some tablet setup, which is covered in the Hardware Setup tables.
  • Page 5 LAVA Computer MFG STS Product Family User Manual – A01 Connect the STS** to the tablet with the custom A tablet status message briefly appears to report Micro USB to Micro USB cable provided. “USB connector connected” and issues a beep.

  • Page 6: Hardware Setup - Sts (Formerly Tl002C)

    Hardware Setup - STS (formerly TL002c) The LAVA product referred to as simply the “STS” is a 1-Port USB member of the LAVA STS Family of devices. This product is a single board OEM device. This product was formerly designated the TL002c.

  • Page 7: Hardware Setup - Sts-3U

    LAVA Computer MFG STS Product Family User Manual – A01 Hardware Setup - STS-3U The STS-3U is a USB HUB, which has no required setup in the tablet. The tablet battery indicator icon can be useful to have enabled, but is optional. The charging status of the tablet can always be checked in the tablet battery menu.

  • Page 8: Hardware Setup - Sts-E, Sts-2Ue, And Sts-2Ue

    LAVA Computer MFG STS Product Family User Manual – A01 Hardware Setup - STS-E, STS-2UE, and STS-2UE+ The STS-E, STS-2UE, and STS-2UE+ have minimal setup requirements in the tablet. The tablet battery indicator icon can be useful to have enabled, but is optional. The charging status of the tablet can always be checked in the tablet battery menu.

  • Page 9: Hardware Setup - Sts-Pe, Sts-P2Ue, And Sts-P2Ue

    LAVA Computer MFG STS Product Family User Manual – A01 Hardware Setup - STS-PE, STS-P2UE, and STS-P2UE+ The STS-PE, STS-P2UE, and STS-P2UE+ have minimal setup requirements in the tablet. The tablet battery indicator icon can be useful to have enabled, but is optional. The charging status of the tablet can always be checked in the tablet battery menu.

  • Page 10: Special Instructions For The Samsung Tab 4

    LAVA Computer MFG STS Product Family User Manual – A01 Special Instructions for the Samsung Tab 4 Special Instructions for Samsung Tab 4 (8” and 10.1”) A Samsung Tab 4 Tablet which is powered off, cannot be turned on when the STS** is set to SimulCharge.

  • Page 11: Tablet Charging (Simulcharge Versus Charge-Only Mode)

    LAVA Computer MFG STS Product Family User Manual – A01 Tablet Charging (SimulCharge versus Charge-Only Mode) The tablet was originally intended as a stand-alone device. When the internal battery of the tablet requires charging, it is plugged into a Wall/USB Charger for a period of time to restore the battery charge. The tablet can continue to be used while being charged.

  • Page 12: Ports, Indicators, And Buttons

    The STS** Product Family supports an alternative OEM cabling scheme which can be discussed with a Lava Sales Representative, when lengths greater than 39” (100 cm) are required. This OEM option does not use the “Micro-B USB To Tablet” receptacle. The standard products are not shipped with this OEM option implemented.

  • Page 13: Micro-B Usb 5V Power Input

    LAVA Computer MFG STS Product Family User Manual – A01 “Micro-B USB 5V Power Input” The “5V Power Input” is a Micro USB-B Receptacle on STS** products without Power over Ethernet. The 5V Power Input provides power for the STS** product, the tablet, and for attached USB accessories.

  • Page 14: Ethernet" Port And Indicators

    LAVA Computer MFG STS Product Family User Manual – A01 The USB-A receptacles only function when the STS** device is powered. The STS** devices have a dedicated power input and are not intended to draw power from the tablet. A USB Hub can be attached to the STS** USB receptacles to extend the number of accessories supported by the system.

  • Page 15: Poe-Ethernet" Port And Indicators

    LAVA Computer MFG STS Product Family User Manual – A01 “PoE-ETHERNET” Port and Indicators The “PoE-ETHERNET” port is present on the STS** products which support Power over Ethernet (PoE). This port has all the features of the STS** ETHERNET Port, as well as the ability to receive power from the Network Cable.

  • Page 16: Power Over Ethernet (Poe)

    LAVA Computer MFG STS Product Family User Manual – A01 Power over Ethernet (PoE) Power over Ethernet (Poe) is a standard for passing electrical power through an Ethernet cable along with the network data. The STS** PoE devices always support an Ethernet adapter for wired network communications.

  • Page 17: Sts Module (Formerly Tl002C)

    STS Module (formerly TL002c) The LAVA product referred to as simply the “STS” is a 1-Port USB member of the LAVA STS Family of devices. This product is a single board OEM device. This product was formerly designated the TL002c.
  • Page 18 LAVA Computer MFG STS Product Family User Manual – A01 With the TYPE jumper installed, the MODE pins are set to level sensitive operation. Not shorting the MODE pins places the module in SimulCharge Mode. Shorting the MODE pins places the module in Charge-Only Mode.

  • Page 19: Dimensions

    LAVA Computer MFG STS Product Family User Manual – A01 Dimensions Case dimensions for the STS-P2UE and STS-P2UE+ Case dimensions for the STS-3U, STS-E, STS-PE, STS-2UE, and the STS-2UE+ 38.2 mm (+/- 0.5 mm) 38.2 mm (+/- 0.5 mm) 43.0 mm (+/- 1.0 mm) 43.0 mm (+/- 1.0 mm)

  • Page 20: Technical Support

    LAVA Computer MFG STS Product Family User Manual – A01 Technical Support LAVA Technical support is open from 9:00 am to 5:00 pm Monday to Friday (Eastern Time). Telephone: +1 416 674-5942 Fax: +1 416 674-8262 Toll Free (US and Canada): 800 241-5282 Internet: www.lavalink.com/helpdesk...
