Model No. WESY5983.3
Serial No.
Write the serial number in the
space above for future reference.
Serial Number Decal (under seat)
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if a part is
damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT
DIRECTLY.
CALL TOLL-FREE:
1-877-992-5999
Mon.–Fri., 6 a.m.–6 p.m. MST
ON THE WEB:
www.weiderservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before
using this equipment. Save this
manual for future reference.
A A D D V V A A N N T T A A G G E E
USER'S MANUAL
Visit our website at
www.weiderfitness.com
new products, prizes,
fitness tips, and much more!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WESY5983.3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Weider WESY5983.3

Summary of Contents for Weider WESY5983.3

  • Page 1 Model No. WESY5983.3 Serial No. Write the serial number in the space above for future reference. Serial Number Decal (under seat) QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if a part is...

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Keep hands and fingers clear of this area. MAX by WEIDER is a trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    15. The resistance system is designed to be used with the included resistance, and the resistance included with a MAX by WEIDER MAX PACK. Do not use the resistance sys- tem with any other type of resistance.

  • Page 4: Before You Begin

    To help us assist you, please note the product model number and serial number before calling. The model number is WESY5983.3. The serial number can be found on a decal attached to the resistance system (see the front cover of this manual).

  • Page 5: Assembly

    ASSEMBLY Make Things Easier for Yourself This manual is designed to ensure that the resist- ance system can be assembled successfully by most people. However, it is important to realize that the versatile resistance system has many parts and that the assembly process will take time.
  • Page 6 2. Attach a Wheel (31) to the outside of the Base (1) with an M10 x 108mm Bolt (81), three M10 Washers (75), and an M10 Nylon Locknut (76). Do not overtighten the Locknut; the Wheel must be able to turn easily. Attach the other Wheel (not shown) in the same manner.
  • Page 7 6. Pull the Seat Knob (45, not shown) out as far as it will go, and slide the Seat Carriage (12) onto the Bench Rail (5). Engage the Seat Knob into the third hole from the end of the Bench Rail. See the inset drawing.
  • Page 8 9. Press two 38mm Round Inner Caps (38) into the ends of the Top Frame (10). Attach two Eyebolts (34) to the Top Frame (10) with two M8 Washers (59) and two M8 Nylon Locknuts (65). Do not overtighten the Locknuts; the Eyebolts must be able to rotate freely.
  • Page 9 12. Press two 25mm Square Inner Caps (54) into the indicated end of the Backrest Frame (15). Attach a Plastic Foot (53) to the Backrest Frame (15) with an M4 x 16mm Screw (62). Orient the Backrest (14) and the Backrest Backing (8) as shown.
  • Page 10 15. Slide the Leg Developer (19) into the Bench Rail (5). Align the hole in the Leg Developer with a hole in the Front Leg (6). Tighten the Bench Knob (42) into the hole in the Leg Developer. Connect the eyebolt on the Leg Lever Cable (32) to the indicated side of the Leg Lever (7) with an M8 Nylon Locknut (65).
  • Page 11 19. Wrap the Long Cable (80) under a 90mm Pulley (28) as shown. Attach the Pulley and a Pulley Guard (29) to the Upright (3) with an M10 x 113mm Button Head Bolt (40) and an M10 Nylon Locknut (76). Make sure the flat edge of the Pulley Guard is on the bottom.
  • Page 12 23. Locate the two Short Cables (33). Wrap one of the Cables around a 90mm Pulley (28). Attach the Pulley to a High Pulley Housing (21) with an M10 x 42mm Button Head Bolt (71) and an M10 Nylon Locknut (76). Repeat this step with the other Short Cable (33).

  • Page 13: Attaching High Pulleys/Leg Lever

    ADJUSTMENTS This section explains how to adjust the resistance system. See the EXERCISE GUIDELINES on page 17 for important information about how to get the most benefit from your exercise program. Also, refer to the accompa- nying exercise guide to see the correct form for each exercise. Make sure all parts are properly tightened each time the resistance system is used.

  • Page 14: Attaching The Accessories

    ATTACHING THE ACCESSORIES To attach a Short Handle (49) to a high pulley, first attach the high pulley to the resistance system (see ATTACHING THE HIGH PULLEYS AND LEG LEVER on page 13). Then, attach the Short Handle to the Short Cable (33) with a Cable Clip (51).

  • Page 15: Adjusting The Backrest

    ADJUSTING THE BACKREST The Backrest (14) can be used in a level position or one of three inclined positions. To use the Backrest in a level position, secure the Seat Carriage (12) at the hole in the Bench Rail (5) closest to the Leg Developer (19) (see ADJUSTING THE SEAT on page 13).

  • Page 16: Cable Diagram

    USING THE REMOVABLE RESISTANCE BARS The Removable Resistance Bars (36, 67) can be used to exercise apart from the resistance system, as shown in the video or on the exercise guide. To remove a Resistance Bar, pull it out of the Tray (35). To replace the Removable Resistance Bars (36, 67), slide them into the Tray (35) from the side shown, so that the arrows on the rings point toward the Tray.

  • Page 17: Exercise Guidelines

    EXERCISE GUIDELINES THE FOUR BASIC TYPES OF WORKOUTS Muscle Building To increase the size and strength of your muscles, push them close to their maximum capacity. Your mus- cles will continually adapt and grow as you progres- sively increase the intensity of your exercise. You can adjust the intensity level of an individual exercise in two ways: •...

  • Page 18: Muscle Chart

    Rest for a short period of time after each set. The ideal resting periods are: • Rest for three minutes after each set for a muscle building workout. • Rest for one minute after each set for a toning work- out.
  • Page 19 EXERCISE MONDAY Date: AEROBIC EXERCISE TUESDAY Date: EXERCISE WEDNESDAY Date: THURSDAY AEROBIC EXERCISE Date: EXERCISE FRIDAY Date: Make photocopies of this page for scheduling and recording your workouts. RESISTANCE RESISTANCE RESISTANCE SETS REPS SETS REPS SETS REPS...

  • Page 20: Part Identification Chart

    PART IDENTIFICATION CHART Refer to the drawings below to identify small parts used in assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST on the reverse side of this page. Note: Some small parts may have been pre-attached.
  • Page 21 M6 Black Nylon Locknut (69) M8 Nylon Locknut (65) M10 x 25mm Button Head Screw (87) M8 x 25mm Button Head Screw (46) M8 x 19mm Button Head Screw (86) M6 x 16mm Screw (82) M4 x 16mm Screw (62) M4 x 12mm Flat Head Screw (85) M4 x 5mm Screw (107)
  • Page 22 PART LIST—Model No. WESY5983.3 Key No. Qty. Description Base Base Plate Upright Lat Tower Bench Rail Front Leg Leg Lever Backrest Backing Seat Backing Top Frame Cross Tube Seat Carriage Seat Backrest Backrest Frame Backrest Cap 19mm Spacer Fulcrum Leg Developer...
  • Page 23 EXPLODED DRAWING—Model No. WESY5983.3 58 62 89 62 R1005A...

  • Page 24: Ordering Replacement Parts

    • The MODEL NUMBER of the product (WESY5983.3) • The NAME of the product (MAX by WEIDER ADVANTAGE resistance system) • The SERIAL NUMBER of the product (see the front cover of this manual) • The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST and EXPLODED DRAWING in the...
