- Page 1 easyONE-DSC A10901/A10902 AIS MOB + DSC User manual english Vers.: 1.2 Stand 1.0...
-
Page 2: Table Of Contents
6.1.1 Automatic Activation (only A10901) ....12 6.1.2 Manual Activation ..........12 6.1.3 Functionality ............13 TEST-F (MOB TEST) ......... 16 UNCTION )....19 EACTIVATION SWITCHING OFF THE DEVICE PROGRAMMING OF MMSI NUMBERS FOR DSC CLOSED LOOP ............. 20 Weatherdock AG Page 2 www.easyAIS.com... - Page 3 DECLARATION OF CONFORMITY ....... 44 PERSONAL NOTES ..........47 Revision Status of the User Manual A10901, Version 1.0, DT, MK, VV 03/2018 A10901, Version 1.1, DT, VB, VV 02/2019 A10901, Version 1.2, JZ, VB 02/2020 Weatherdock AG Page 3 www.easyAIS.com...
- Page 4 Electronical Chart Display GMDSS Global Maritime Distress and Safety System GNSS Global Navigation Satellite System MMSI Maritime Mobile Service Identification Man over Board Search and Rescue SOLAS Safety of Life at Sea Speed over Ground Weatherdock AG Page 4 www.easyAIS.com...
-
Page 5: Fcc Statement
Wrongful triggering of an AIS alert is not a minor offense and may entail consequential costs. • The unauthorized opening of the device voids the war- ranty. Unauthorized and violent opening can destroy the device. Weatherdock AG Page 5 www.easyAIS.com... -
Page 6: Product And Performance Description
(A10901) verfügt neben der manuellen Auslösung, eine Auslöse- automatik per Wasserkontakt. Die Variante easyONE-DSC (A10902) kann nur manuell ausgelöst werden. Das Gerät ist ohne zusätzliche Hilfsmittel schwimmfähig. Der AIS/DSC Seenotsender easyONE-DSC dient in einer Notfall- Situation zur direkten Benachrichtigung mittels: Weatherdock AG Page 6 www.easyAIS.com... - Page 7 => Responsible regulating authority can provide country spe- cific information if DSC open loop is allowed in your area. The easyONE-DSCCL device is compliant to the world wide used AIS System (Automatic Identification System) and DSC radio sys- tem (Digital Selective Call).
-
Page 8: Product Overview
2. Upper section 9. Seizing, 1m 3. Antenna flap 10. GPS status LED 4. Alarm flap 11. FLASH LEDs 12. Red FLARE LED 5. Antenna 13. Water soluable 6. Antenna winding head cellulose tablet 7. “TEST” button Weatherdock AG Page 8 www.easyAIS.com... -
Page 9: Operating Elements
(3) at the same time. „ON“ button The easyONE-DSCCL can be activated manually pressing the “ON“ button (8). Parallel to the AIS Signal a DSC distress call is broadcasted. -
Page 10: Test" Button
When the antenna flap (3) was trig- gered upon water contact or the alarm flap (4) was removed manu- ally the antenna unfolds inde- pendently. The device activates au- tomatically upon water contact without requiring user intervention. Weatherdock AG Page 10 www.easyAIS.com... -
Page 11: Operation
Operating status FLASH-LED (11) + red FLARE LEDs (12) flash- Device is transmitting GPS-Status-LED (10) Current position is being determined permanently on GPS-Status-LED (10) GPS/GNSS signal is perfect. The posi- flashing tion is continously being determined Weatherdock AG Page 11 www.easyAIS.com... -
Page 12: Alert
(5) can unfold. The “ON” button (8) is now exposed and can be pressed in order to trigger the emergency signal. When activating manually, keep the device away from your face! IMPORTANT: The easyONE-DSC -M (A10902) can only be trig- gered manually. Weatherdock AG Page 12 www.easyAIS.com... -
Page 13: Functionality
(System update of display / chart may be necessary): On earlier systems, it appears as a ship symbol: The 9-digit “Unit-ID” (MMSI) of the easyONE-DSCCL, beginning with “972..” and a safety Message (SRM) “MOB ACTIVE” are displayed and an audible and/or visual alarm is triggered, re- spectively. - Page 14 DSC system within range. As an acknowledgement for this, the red FLARE LEDs will flash for a second. This single one-time DSC open loop distress call will not inter- fere other functionalities of the AIS MOB unit Weatherdock AG Page 14 www.easyAIS.com...
- Page 15 LEDs do. The FLARE will flash every 2 seconds. As longer the AIS MOB is in alert mode, the flashing time reduces but the intervall will stay at every 2 seconds. Weatherdock AG Page 15 www.easyAIS.com...
-
Page 16: Test-Function (Mob Test)
AIS receivers which needs to be connected to a chart plotter or laptop with nav- igation software. Usually the easyONE-DSC is displayed like an AIS S.A.R.T. as a circle symbol on the electronic display. Weatherdock AG Page 16 www.easyAIS.com... - Page 17 • The DSC transmission can be checked with a DSC enabled ra- dio. As information, the 9-digit “Unit-ID” (MMSI) of the easyONE-DSCCL, starting with “972 ..” and the message “TEST CALL” is displayed. • After a successful test, the device switches itself off.
- Page 18 (< 6 h). This happens when the device has been acti- vated (MOB ACTIVE) or if the expiration date is exceeded or if the “TEST” button has been pressed more than 30 times. Table 1: Blink-/ Leuchtmuster Test-Status Weatherdock AG Page 18 www.easyAIS.com...
-
Page 19: Deactivation (Switching Off The Device)
(www.easyAIS.com). The current battery status of the easyONE-DSC can be read out also by the Weatherdock-App via Bluetooth®. Please keep the amount of Bluetooth connections only the bare necessities to go easy on power resources for event of emergency. -
Page 20: Programming Of Mmsi Numbers For Dsc Closed Loop
• Press the TEST button for 3 seconds until the LEDs start flashing fast • The Bluetooth module needs up to 20 seconds to boot • After 20 seconds only the yel- low LED is illuminated → Bluetooth is ready Weatherdock AG Page 20 www.easyAIS.com... - Page 21 Tip on “scan for Device“, to connect the easyONE-DSC with your mobile device • Tip on easyONE-DSC to se- lect this kind of device • This App is designed for the programming of the AIS SART unit easyRESCUE-PRO as well Weatherdock AG Page 21 www.easyAIS.com...
- Page 22 • If the connection was not done automatically, tip to se- lect manually • Click on “Load” • Information to the easyONE- will appeare Weatherdock AG Page 22 www.easyAIS.com...
- Page 23 • On the back of the easyONE- you will find the unit ID of the device. Please check if the numbers are correct • If correct, please tip on the small right arrow to start pro- gramming the MMSI numbers Weatherdock AG Page 23 www.easyAIS.com...
- Page 24 • Tip on one of the eight “ShipID” fields to enter there the ships MMSI • Enter the MMSI number you want to programm • Tip on “Programm” to store the number into the easyONE- Weatherdock AG Page 24 www.easyAIS.com...
- Page 25 4 different ship MMSI • If you entered a wrong num- ber, just tip on that number to correct • All changes you do will be acknowledged by the yellow LED flashing after pressing “Programm” Weatherdock AG Page 25 www.easyAIS.com...
- Page 26 • In event of such a case please tip on the “down” arrow • A list opens up with all MMSI numbers which had been pro- grammed with this mobile de- vice • Choose the number you need to programm Weatherdock AG Page 26 www.easyAIS.com...
- Page 27 “YES” • If you want to delete a ship MMSI from the easyONE- , click on the number • Press “delete” • Every elimination will be con- firmed by the yellow LED flashing Weatherdock AG Page 27 www.easyAIS.com...
- Page 28 • If you don’t switch off the easyONE-DSC by your own, 1 minute of inactivity will trig- ger self-shut-down functional- • The easyONE-DSC is now ready for usage in case of emergency Weatherdock AG Page 28 www.easyAIS.com...
- Page 29 After that, please start your mobile de- vice again to connect with the easyONE-DSC to start pro- gramming. Please keep the amount of Bluetooth connections only the bare necessities to go easy on power resources for event of emergency. Weatherdock AG Page 29 www.easyAIS.com...
-
Page 30: Life Jacket Integration
With this positioning the device will be pushed out into the water the right way while the life jacket is inflating automati- cally when submerged. Please also note our video instructions and the information on our website (www.easyais.com) Weatherdock AG Page 30 www.easyAIS.com... -
Page 31: Maintenance And Service
Hold the Allen key with the thumb (Warning: Spring effect of the screwed antenna!) Insert the water soluble pill into the antenna flap. Close the antenna flap and fix it with the alert flap. Ready. Your easyONE-DSC is fully functional again. Weatherdock AG Page 31 www.easyAIS.com... - Page 32 4. / 5. Weatherdock AG Page 32 www.easyAIS.com...
- Page 33 The overhaul of the trigger mechanism by a non-certified dis- tributor or reseller is at your own risk! Only original spare pills are suited for replacement. Please also note our video tutorials and the reference infor- mation on our website (www.easyais.com) Weatherdock AG Page 33 www.easyAIS.com...
-
Page 34: Maintenance/Service
Weatherdock AG shall not be made liable for any specific, indirect, incidental or conse- quential damages as a result of its use. Weatherdock AG com- ponents may only be used in safety of life devices or systems,... -
Page 35: Disposal
Contact your local dealer for support. If the dealer may not be able to help, please contact our service department: Weatherdock AG Emmericher Strasse 17 D-90411 Nuernberg Phone: +49 (0)911-376638-30 Telefax: +49 (0)911-376638-40 E-Mail: info@weatherdock.de Internet: www.easyais.com Disposal The AIS MOB easyONE-DSC uses lithium batteries. -
Page 36: Troubleshooting
Keep the easyONE-DSC in one does not receive a GPS hand and hold it away from the position (GPS Status water as far as possible. This also in- LED not flashing) creases your transmission range! Weatherdock AG Page 36 www.easyAIS.com... - Page 37 After the TEST the Please take a look at the following LEDs are flashing table Table 2: Troubleshooting If the device cannot be activated (TEST / ON mode), send it back to your dealer for service immediately! Weatherdock AG Page 37 www.easyAIS.com...
-
Page 38: Rescue Database And Login
11 RESCUE Database and Login To increase functionality of AIS based personal locating beacons more safe and more effective, Weatherdock AG is providing a web-based database where customers can give additional rele- vant information. For more information about that service please look on our website: www.easyais.com... - Page 39 This is because of live saving reasons and happens only when your easyONE-DSC will be activated. To enter your data, please use the Unit-ID of the unit itself as well as the password, which is also printed on the product la- bel. Weatherdock AG Page 39 www.easyAIS.com...
-
Page 40: License Agreement
Weatherdock will at its sole option repair or replace any components that fail in normal use. Repairs or replacement at the ex- pense of Weatherdock AG will be made at no charge to the customer for parts or labour, provided that the customer shall be responsible for any transportation cost. - Page 41 It is the sole responsibility of the operator of the boat to operate the boat in a safe manner, maintain full surveillance of all boating conditions at all times, and never become distracted by easyONE-DSC to the exclusion of safe operating practices. Weatherdock AG Page 41 www.easyAIS.com...
-
Page 42: Specifications
DSC: ≥ 0,5 Watt 72 channel receiver with integrated an- GPS/GNSS receiver tenna pursuant to IEC61108-1 foldout; rolled up in the device during VHF antenna inactive mode 9 LEDs 1x GPS status 2x Flash Display 6x FLARE Weatherdock AG Page 42 www.easyAIS.com... - Page 43 DSC mode in test mode: TEST CALL in alert mode: DISTRESS RELAY Operating -10°C to +55°C temperatur -30°C to +70°C Storage temperatur MMSI: 972XXXXXX as MOB TEST or as Identification MOB ACTIVE Table 3: Specification Weatherdock AG Page 43 www.easyAIS.com...
-
Page 44: Declaration Of Conformity
15 Declaration of Conformity Due to legal requirements the following declaration of conformity has to be placed aboard always! Weatherdock AG Page 44 www.easyAIS.com... - Page 45 Weatherdock AG Page 45 www.easyAIS.com...
- Page 46 Weatherdock AG Page 46 www.easyAIS.com...
-
Page 47: Personal Notes
16 Personal Notes Weatherdock AG Page 47 www.easyAIS.com... - Page 48 Weatherdock AG Emmericher Strasse 17 D – 90411 Nuernberg Tel.: +49 (0) 911 – 37663830 Fax: +49 (0) 911 – 37663840 www.easyais.com info@weatherdock.de...
