RHYNO Caravan Mover Fitting Instructions

Fitting instructions

The Rhyno unit is designed to fit in a
simple but secure way to your caravan.

Tools required:

17mm socket or ring spanner
Standard screwdriver
Phillips screwdriver
Wire cutters
A power drill
22mm spade drill
Scissor car jack or trolley jack
Matt or ground covers for lying on
Prepare your caravan. Ensure there
is sufficient ground clearance and the
front of the caravan is raised to allow
you to have access to the underneath
of the caravan.
Apply the hand brake and have at least
two legs lowered whilst working under
the caravan.
Remove all security wheel clamps.
Clear the bunk or cupboard at the
rear of your battery box ready for the
positioning of the electric control box.
The first step to successfully fitting
your Rhyno Caravan Mover is to ensure
that all the components are laid out
together and to check that all the
following parts are included:
8 x M10 nyloc nuts
8 x M10 X80 high tensile bolts
8 x self-tapping screws
1 x control module
1 x handset
1 x aux cable
2 x bottom plates
2 x middle plates
2 x top plates
1 x red lead short
1 x red lead long
1 x black lead long
1 x isolator switch with key
12 x cable ties
2 x shear bolts
1 x cable grommet
Mount one of the motor units onto the
jack or wooden blocks and raise into
position as shown below.
