Summary of Contents for BINO Hampton Cot bed
- Page 1 Hampton Cot bed IMPORTANT - RETAIN FOR FUTURE REFERENCE. READ CAREFULLY. WARNING : DO NOT LEAVE YOUR CHILD UNATTENDED - YOUR CHILD'S SAFETY IS YOUR RESPONSABILITY...
- Page 2 THESE INSTRUCTIONS ARE IMPORTANT – PLEASE READ CAREFULLY AND RETAIN FOR FUTURE REFERENCE We strongly suggest you spent a short time reading through this leaflet and then follow the simple step by step guide to assembly. WARNING : Do not leave your child unattended. The correct use and maintenance of your changer will ensure it gives long and trouble free use.
-
Page 3: Care And Maintenance
WHEN THIS ITEM IS IN COT MODE: The age range is from birth to 18 months. • Warning: Be aware of the risk of open fire and other sources of strong heat, such as electric bar fires, gas fires, etc. in the near vicinity of the cot. •... - Page 4 PARTS 11 x4 8 x2...
- Page 5 HARDWARES M6x60mm M6x50mm M6x35mm Bolt Bolt Bolt Cam-Bolt Cam-Lock M4x35mm M3x16mm Dia.12x1mm Plastic Allen Key Screw Screw Washer Wheel...
- Page 6 COT MODE ASSEMBLY Bolt (M6x35mm) X4 Plastic Washer (Dia.12x1mm) X4 Not to tighten the screws until the both cot sides assembled. Height 3 Make sure to face base slats upwards 'THIS SIDE UP' (see label Height 1 Turning base the wrong way will weaken its structure.
- Page 7 Tighten all the screws for both sides and base. Bolt (M6x50mm) X8 Plastic Washer (Dia.12x1mm) X8 Cam-Bolt X8 Cam-Lock X6 CAM-PILLAR CAM-LOCK Tighten until shoulder is flush with panel. Do not overtighen Align with long point of cross or undertighten (see example WHEN FITTING CAMS Shoulder below)
- Page 8 CAM-LOCK Align with long point of cross WHEN FITTING CAMS ENSURE STARTING POSITION IS CORRECT BEFORE YOU INSERT CONNECTING CAM-PILLAR TURN CLOCKWISE UNTILE SECURE WRONG CORRECT Pillar head needs to be in centre Screw (M4x35mm) X10 Screw (M3x16mm) X10 Wheel X5 Cam-Lock X2...
- Page 9 JUNIOR BED MODE ASSEMBLY Not to tighten the screws until the brackets assembled. Bolt (M6x35mm) X4 Plastic Washer (Dia.12x1mm) X4 Make sure to face base slats upwards 'THIS SIDE UP' (see label Turning base the wrong way will weaken its structure.
- Page 10 Tighten all the screws for brackets and base. Bolt (M6x60mm) X8 Bolt (M6x35mm) X4 Plastic Washer (Dia.12x1mm) X12 Turn Product...
