ADINA RANGE
OWNERS MANUAL
INVERTER REVERSE CYCLE
SPLIT SYSTEM AIR CONDITIONER
IMPORTANT INFORMATION
Carefully read this instruction manual before installation of your air
conditioner. Please retain this manual for product warranty and for
future reference.
Contents of manual may be updated without notice.
For the latest version of this manual please refer to our website:
www.scandiastoves.com.au
Part No: SG070100041 Version 1 2 20/09/19
MODEL
SG010400001
(2.5kW Cooling/2.6kW Heating)
SG010400002 (3.3kW Cooling/3.4kW Heating)
SG010400003 (5. 1 kW Cooling/5.1kW Heating)
SG010400004 (7.3kW Cooling/8.0kW Heating)
Scandia Group Pty Ltd
Head Office
58 Access Way
Carrum Downs VIC 3201
Australia
+61 3 8579 5900
service@scandiastoves.com.au
www.scandiastoves.com.au

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADINA Series and is the answer not in the manual?

Questions and answers

Related Manuals for scandia ADINA Series

Summary of Contents for scandia ADINA Series

  • Page 1 SG010400001 (2.5kW Cooling/2.6kW Heating) SG010400002 (3.3kW Cooling/3.4kW Heating) SG010400003 (5. 1 kW Cooling/5.1kW Heating) SG010400004 (7.3kW Cooling/8.0kW Heating) Scandia Group Pty Ltd IMPORTANT INFORMATION Head Office Carefully read this instruction manual before installation of your air 58 Access Way conditioner. Please retain this manual for product warranty and for Carrum Downs VIC 3201 future reference.
  • Page 2 Current AS/NZS 3000 Commonwealth, State, Territory and local legislation, regulations and codes, including local OH&S requirements. For continued safety of this appliance, it must be maintained in accordance with the manufacturer’s instructions. REFRIGERANT Scandia Model Numbers: SYSTEM INDOOR OUTDOOR SG010400001 SG010400005...

  • Page 3: Table Of Contents

    INTRODUCTION Congratulations on purchasing a genuine Scandia Split System Air Conditioner. When cared for properly, these high quality, finely crafted air conditioners will offer many years of reliable performance. This instruction manual has been developed to ensure optimum performance from your Scandia air conditioner.

  • Page 4: Warnings And Information

    WARNINGS AND INFORMATION Explanation of symbols displayed on the indoor unit or outdoor unit WARNING This symbol shows that this air conditioner uses a flammable refrigerant. If the refrigerant leaks and is exposed to an external ignition source, there is a risk of fire. Warning: Combustible Read the Read the...
  • Page 5 SAFETY RULES AND RECOMMENDATIONS FOR THE INSTALLER Read this guide before installing and using this appliance. The SG010400004 shall be installed, operated and stored in a room with a floor area larger than 1.92 m The air conditioner is supplied pre-charged. If any refrigerant is added to the system the minimum floor area will need to be calculated for all models.
  • Page 6 SAFETY RULES AND RECOMMENDATIONS FOR THE USER – OPERATION Only use the air conditioner as instructed in this booklet. These instructions are not intended to cover every possible condition and situation. As with any electrical household appliance common sense and caution are therefore always recommended for installation, operation and maintenance.
  • Page 7 SAFETY RULES AND PROHIBITIONS Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. Do not pierce or burn. Be aware that refrigerants may not contain an odour. 4. Before accessing the terminals, all power circuits must be disconnected from the power supply. Maintenance must be carried out by specialised technical personnel.

  • Page 8: Appliance Components

    INDOOR UNIT YOUR AIR CONDITIONER AT A GLANCE INDOOR UNIT INDOOR UNIT Description Front panel Air filter Optional filter (if installed) LED Display Signal receiver Terminal block cover Ionizer generator (if installed) Deflectors Emergency button Indoor unit rating label (Stick position optional) Airflow direction flap Remote controller OUTDOOR UNIT...

  • Page 9: Weights And Dimension

    WEIGHTS AND DIMENSIONS MODEL WIDTH (mm) DEPTH (mm) HEIGHT (mm) WEIGHT (kg ) – Net SG010400001 Indoor Outdoor SG010400002 Indoor 1010 Outdoor SG010400003 Indoor 1186 Outdoor SG010400004 Indoor 1186 Outdoor OPERATING TEMPERATURE RANGES Mode TEMPERATURE Cooling Heating Room Temperature 17ºC – 32ºC 0ºC –...

  • Page 10: Important Considerations

    IMPORTANT CONSIDERATIONS Installation Safety Principles 1. Site Safety Open Flames Prohibited Ventilation necessary 2. Safety Mind static electricty Must wear protective clothing and anti-static gloves Don’t use mobile phones 3. Installation Safety • Refrigerant Leak Detector The left picture is the schematic diagram of a refrigerant leak detector •...
  • Page 11 INSTALLATION MANUALS – Important considerations Special Tools Tool Name Requirement(s) for use It should be an explosion-proof vacuum pump suitable for use with R32 Mini Vacuum Pump and ensure that its final vacuum should be lower than 10Pa (75 micron). It should be a special explosion-proof filling device suitable for R32 and Filling Device have certain precision and its resolution should be less than 5g.

  • Page 12: Selecting The Installation Place

    Mounting plate INSTALLATION MANUAL – Selecting the Installation Place Mounting plate Mounting plate Condensate drain pipe INDOOR UNIT Sleeve insulating covering • Install the unit on a strong wall that is not subject to vibrations electrical cable Condensate drain pipe •...

  • Page 13: Indoor Unit

    INSTALLATION MANUAL – Installation of the indoor unit Do not install your air conditioner in a wet room such as a bathroom or laundry. The installation site should be 180cm or more above the floor. INSTALLATION FOR THE MOUNTING PLATE Ensure that the wall structure on which the units are to be mounted is capable of supporting the weight of the air conditioner and the associated pipework.
  • Page 14 INSTALLATION MANUAL – Installation of the indoor unit ELECTRICAL CONNECTIONS – Indoor unit Front panel Must be installed, maintained and removed by authorised persons in accordance with AS/NZS 3000 and all other Wiring diagram relevant local regulations and municipal building codes including OH&S requirements.
  • Page 15 INSTALLATION MANUAL – Installation of the indoor unit REFRIGERANT PIPING CONNECTION The piping can be run in the 3 directions indicated by numbers in the picture. When the piping is run in direction 1 or 3, cut a notch along the groove on the side of the indoor unit with a cutter.
  • Page 16 torque wrench INSTALLATION MANUAL – Installation of the indoor unit Indoors Outdoors The connectors INDOOR UNIT CONDENSATE DRAINAGE should be outdoors The indoor unit condensate drainage is fundamental for the success of the installation. • Place the drain hose below the piping, taking care not to create a kink. •...

  • Page 17: Outdoor Unit

    INSTALLATION MANUAL – Installation of the outdoor unit OUTDOOR UNIT The outdoor unit can be installed either on the ground or on a wall. • If the unit is installed on a wall, ensure that the wall is solid and the unit is securely fastened to it.
  • Page 18 side plate outdoor unit INSTALLATION MANUAL – connection pipes Installation of the outdoor unit CONNECTING THE PIPES flare nuts Screw the flare nuts to the outdoor unit coupling with the same tightening procedures described for the indoor unit. gas tap To avoid leakage be aware of the following: to indoor •...

  • Page 19: Installation Checklist

    (7) Turn to fully open the valve valve cap Service port nut (1) Turn (1) Turn (8) Tighten (2) Turn (8) Tighten valve cap (8) Tighten INSTALLATION MANUAL – Operation test COMPLETING THE INSTALLATION Clamps insulating covering Fit thermal insulation around the refrigerant piping and joints and retain with insulation tape.

  • Page 20: Operating Manual

    OPERATING INSTRUCTIONS INDOOR UNIT DISPLAY Icon Function SLEEP SLEEP mode TIMER Temperature display (if present) (1) Lights up during Timer operation when the air TIMER TIME /Error code conditioner is operational. TIMER TIMER (2) Displays the malfunction code when fault occurs. TIMER Lights up during TIMER operation.
  • Page 21 EMERGENCY FUNCTION & AUTO-RESTART FUNCTION EMERGENCY FUNCTION If the remote control fails to work, the air conditioner can be operated with reduced functionality from the indoor unit as follows: Open and lift the front panel up to an angle to reach the emergency front panel front panel button:...

  • Page 22: Remote Control

    REMOTE CONTROL TIMER TIMER TIMER TIMER I FEEL TIMER TIMER I FEEL MILDEW I FEEL Button Function MILDEW MILDEW To turn ON or OFF the air conditioner. SLEEP TIMER I FEEL CLEAN HEALTH MILDEW AUTO COOL DRY CLEAN DISPLAY 8º CH TIMER TIMER SLEEP...
  • Page 23 MILDEW SLEEP TIMER I FEEL CLEAN HEALTH MILDEW CLEAN DISPLAY 8º CH REMOTE CONTROL 8º CH TIMER TIMER I FEEL Remote control DISPLAY MILDEW Meaning of symbols on the liquid crystal display AUTO COOL DRY SLEEP TIMER I FEEL CLEAN DISPLAY 8ºCH HEALTH...
  • Page 24 REMOTE CONTROL Replacement of Batteries Remove the battery cover plate from the rear of the remote control, by sliding it in the direction of the arrow. Install the batteries in accordance with the indicated direction (+ and -) shown on the Remote Control.
  • Page 25 OPERATING INSTRUCTIONS OPERATING MODES When the air conditioner is off (standby): Press the ON/OFF button to turn on the air conditioner. The air conditioner will begin to operate. All current operational settings, modes and the battery status are shown on the LCD screen. When the air conditioner is running: Press the ON/OFF button to turn off the air conditioner.
  • Page 26 OPERATING INSTRUCTIONS… cont DRY MODE This function reduces the humidity of the air to make the room more comfortable. To activate the DRY function, press MODE button until DRY appears in the display. An automatic function of alternating cooling cycles and air fan is activated.
  • Page 27 OPERATING INSTRUCTIONS… cont ECO FUNCTION In ECO mode the air conditioner automatically sets the operation to achieve energy savings. 1. To activate ECO operation, press the ECO button, the air conditioner will run in ECO mode and ECO will be shown on the LCD screen. 2.
  • Page 28 Exchanger I FEEL TIMER TIMER MILDEW I FEEL SLEEP TIMER I FEEL OPERATING INSTRUCTIONS… cont CLEAN HEALTH MILDEW CLEAN DISPLAY 8º CH MILDEW TIMER TIMER 8º CH I FEEL SLEEP TIMER I FEEL CLEAN HEALTH MILDEW TIMER TIMER CLEAN DISPLAY 8º...
  • Page 29 I FEEL OPERATING INSTRUCTIONS… cont MILDEW TIMER TIMER DISPLAY SLEEP TIMER I FEEL I FEEL CLEAN TIMER TIMER HEALTH MILDEW SLEEP FUNCTION MILDEW CLEAN DISPLAY 8º CH I FEEL TIMER TIMER SLEEP SLEEP TIMER I FEEL CLEAN 8º CH HEALTH MILDEW MILDEW I FEEL...
  • Page 30 OPERATING INSTRUCTIONS… cont TIMER TIMER TIMER I FEEL FUNCTION I FEEL TIMER TIMER I FEEL MILDEW I FEEL This function optimises the temperature around you to ensure maximum MILDEW SLEEP TIMER I FEEL CLEAN MILDEW comfort. The remote control measures the temperature at its current HEALTH MILDEW CLEAN...
  • Page 31 TIMER OPERATING INSTRUCTIONS… cont I FEEL MILDEW SELF-CLEAN FUNCTION CLEAN TIMER TIMER I FEEL TIMER TIMER This function cleans accumulated dirt from the indoor coil. 8º CH MILDEW We suggest operating this function during the following ambient conditions I FEEL to avoid activating certain safety protection features.

  • Page 32: Maintenance

    MAINTENANCE Note: There are no user serviceable components in the air conditioner. All servicing must be done by a suitably licensed, qualified technician. Periodic maintenance is required to keep your air conditioner operating efficiently. Turn off the power before you perform any maintenance; otherwise it may cause electric shock.

  • Page 33: Troubleshooting

    TROUBLESHOOTING MALFUNCTION POSSIBLE CAUSE Power failure/isolating switch off. Damaged indoor/outdoor unit fan motor. Faulty compressor thermomagnetic circuit breaker. Faulty protective device of fuses. The appliance does not operate Loose connections. It sometimes stops operating to protect the appliance. Voltage higher or lower than the voltage range. Active TIMER-ON function.

  • Page 34: Warranty

    WARRANTY This limited warranty is given by Scandia Group Pty Ltd (ACN 104 878 588) (Scandia or we) to the original retail purchaser (you) of the air conditioner to which the warranty applies. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage.
  • Page 35 If the air conditioner has not been installed, then at any time we may require that you return the air conditioner to the original place of purchase (and collect it from there once the replacement or repair is complete) at your cost. Scandia will not be responsible for any associated freight, disconnection or re-installation costs (including labour costs). REGISTER YOUR PRODUCT...

  • Page 36: Parts Listing And Exploded Diagrams

    ADINA AIR CONDITIONER – SPARE PARTS 2.5kW/2.6kW SPARE PARTS LIST – HEAD UNIT 3.3kW/3.4kW SPARE PARTS LIST – HEAD UNIT SCANDIA PART NO.(INDOOR) LEGEND PART 2.5kW / 2.6kW 3.3kW / 3.4kW Front Panel SG031200052 SG031200054 Air Filter SG031200027 SG031200028 Face Frame...
  • Page 37 ADINA AIR CONDITIONER – EXPLODED DIAGRAM 2.5kW/2.6kW SPARE PARTS LIST – HEAD UNIT 3.3kW/3.4kW SPARE PARTS LIST – HEAD UNIT...
  • Page 38 ADINA AIR CONDITIONER – SPARE PARTS 5. 1 kW/5. 1 kW SPARE PARTS LIST – HEAD UNIT 7.3kW/8.0kW SPARE PARTS LIST – HEAD UNIT SCANDIA PART NO. (INDOOR) LEGEND PART 5. 1 kW / 5. 1 kW 7.3kW / 8.0kW...
  • Page 39 ADINA AIR CONDITIONER – EXPLODED DIAGRAM 5. 1 kW/5. 1 kW SPARE PARTS LIST – HEAD UNIT 7.3kW/8.0kW SPARE PARTS LIST – HEAD UNIT...
  • Page 40 ADINA AIR CONDITIONER – SPARE PARTS 2.5kW/2.6kW SPARE PARTS LIST – CONDENSOR UNIT 3.3kW/3.4kW SPARE PARTS LIST – CONDENSOR UNIT SCANDIA PART NO. (OUTDOOR) LEGEND PART 2.5kW / 2.6kW 3.3kW / 3.4kW Back Grill Enquire Enquire Top Cover SG031200063 SG031200064...
  • Page 41 ADINA AIR CONDITIONER – EXPLODED DIAGRAM 2.5kW/2.6kW SPARE PARTS LIST – CONDENSOR UNIT 3.3kW/3.4kW SPARE PARTS LIST – CONDENSOR UNIT...
  • Page 42 ADINA AIR CONDITIONER – SPARE PARTS 5. 1 kW/5. 1 kW SPARE PARTS LIST – CONDENSOR UNIT 7.3kW/8.0kW SPARE PARTS LIST – CONDENSOR UNIT SCANDIA PART NO. (OUTDOOR) LEGEND PART 5. 1 kW / 5. 1 kW 7.3kW / 8.0kW...
  • Page 43 ADINA AIR CONDITIONER – EXPLODED DIAGRAM 5. 1 kW/5. 1 kW SPARE PARTS LIST – CONDENSOR UNIT 7.3kW/8.0kW SPARE PARTS LIST – CONDENSOR UNIT Head Office Scandia Group Pty Ltd 58 Access Way (03) 8579 5900 Carrum Downs VIC 3201 service@scandiastoves.com.au...
