Ness HTA 100 Installation And Assembly

Installation and Assembly: Articulating Wall Arm for LCD screens
·Do not begin to install your mount product until you have read and understood the instructions.
·This product should only be installed by someone of good mechanical aptitude, has experience with basic building construction, and fully understands these
Instructions. Consult a qualified professional installer if unsure.
·Make sure that the supporting surface will safely support the combined load of the equipment and all attached hardware and components.
·Never exceed the Maximum Load Capacity of 30 lbs.
·If mounting to wood wall studs, mke sure that mounting screws are anchored into the center of the studs. Use of an "edge to edge" stud finder is highly
Recommended.
·Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
·Tighten screws firmly, but does not overtighten.Overtightening can damage the items, greatly reducing their holding power.
· Drill with 1/4" and 5/32" drill bits
Model: HTA100
Important
Tools Needed for
Assembly
· Stud finder
("edge to edge"
stud finder is
recommended)
Installation to
Wood Stud Wall
· Phillips
screwdriver
