1. HDMI port
2. USB port
3. TV-OUT port
4. Bracket base
5. Lens
6. Speaker
7. LED lamp
8. TF card slot
9. Status
indicator
Power capacity
Full
Middle
1. Directly connect the car charger to the USB port of the DVR, then
the device will automatically turn on and charge the battery. In
charging, the charge indicator will be on; after charge is over, it will
be off.
2. To charge the device with USB, be sure to connect one end of
the USB data cable to PC and the other end to the DVR. In
charging, the charge indicator will be on; after charge is over, it will
be off.
Installation and Removal of TF Card
1. In the direction as indicated, insert the TF card into the slot until it
is held firmly.
2. To take the TF card out, slightly press the TF card to eject it out.
Note:
10. LCD Screen
11. Emergency
Lock Key
12. Reset key
13. Down key
14. Mode key
15. OK key
16. Menu key
17. Up key
18. Power
On/Off key
Low
Advertisement
Table of Contents
Summary of Contents for eSYNiC SV058
- Page 1 1. HDMI port 10. LCD Screen 2. USB port 11. Emergency 3. TV-OUT port Lock Key 4. Bracket base 12. Reset key 5. Lens 13. Down key 6. Speaker 14. Mode key 7. LED lamp 15. OK key 8. TF card slot 16.
- Page 2 1. Observe the direction to insert the TF card; if the direction is reverse, the device and the TF card may be damaged. 2. When the TF card is inserted into the device, the machine will set the TF card as preset storage unit and the data in the original TF card will be unreadable.
- Page 3 recording videos; in recording videos, the icon on the upper left corner of the screen will flicker. Press the OK key again to stop, then the icon will disappear. In video taking process, press the UP key as shortcut key to activate/inactivate sound, press the DOWN key as shortcut key to have emergency lock.
- Page 4 present” and “Delete all”, press the OK to enter and again to confirm. You may add a lock to the file; before unlocking, you cannot delete it; in such way, some important files are protected. Mode of Videoing while Charging Connect the car charger to the USB port of the device, switch it off to enter such mode.
- Page 5 format Photo 12M/10M/8M/5M/2M resolutio Photo format memory card Micropho Inbuilt ne/Speak Light 50Hz/60Hz source frequenc NTSC/PAL output USB port USB2.0 Power 5V 1A supply port Battery Polymer Battery 240MA Operatio Windows n system 2000/XP/Vista/Windows 7 or above Note: We reserve the right to change the design and specs of this product without further notice.
