Clas Ohlson 40-7184 Instruction Manual

Tool Cabinet
Art.no. 40-7184
Please read the entire instruction manual before using the pro-
duct and save it for future reference. We reserve the right for
any errors in text or images and any necessary changes made
to technical data. If you have any questions regarding technical
problems please contact Customer Services.
Safety
• Make sure that all parts are correctly assembled and
not damaged.
• Test the cabinet to make sure that it is stable before using it.
• Regularly check that all screws are adequately tightened.
• Do not overload the drawers and shelves with too much weight.
• Open one drawer at a time; otherwise, the cabinet might tip over.
• Place the heaviest tools at the bottom of the cabinet/in the
lower drawers.
Product description
The cabinet is intended to help you organise and store your tools
in an orderly fashion. The product is only intended for use in the
home and not for commercial use.
Contents
1. Chest with
4 drawers
2. Cabinet
3. Door with tool
hanger
4. 2 fixed castors
5. 2 swivel castors
with brakes
6. Tool tray
7. 2 x M6 bolts
8. 2 x M6 washers
9. Shelf
10. 6 x hooks
11. 2 x handles
12. 8 x screws
13. Instruction manual
Assembly
Attaching the castors
• Note: For this you will
require a rubber mallet.
Turn the cabinet (2)
upside down.
• Knock the castors (4 and
5) into the holes on the
bottom of the cabinet (2)
using a rubber mallet.
• Turn the cabinet right
side up again.
GREAT BRITAIN For consumer contact, please visit www.clasohlson.co.uk
and click on customer service.
ENGLISH
Attaching the tool tray
• Note: For this you will require a 10
mm spanner.
• Bolt the tool tray (6) to the left side
of the cabinet using the bolts (7)
and washers (8).
Fitting the shelf
• Tilt the shelf (9) a little to help fit it
into the cabinet (2).
• Rest the shelf on the shelf
supports making sure that it is
level. There are four available
height settings.
Attaching the tool hooks
• Push the hooks (10) into the holes
on the inside of the door.
Fitting the side handles
• Screw the handles (11) onto the
sides of the chest (1) using the
screws (12).
Operation
The drawers in the chest (1) are controlled by a master lock.
The drawers can only be opened when the lid is open.
Care and maintenance
• Wipe the tool cabinet using a soft, damp cloth.
• Never use solvents or abrasive cleaning agents.
Disposal
Follow local ordinances when disposing of this product.
If you are unsure of how to dispose of this product, please
contact your municipality.
Specifications
Complete unit
Chest
Cabinet with castors
Material
Weight
Approx. 52 x 105 x 28 cm (W x H x D)
Approx. 45 x 33 x 24 cm (W x H x D)
Approx. 52 x 72 x 28 cm (W x H x D)
Metal
Approx. 19.5 kg
