P A R T S I N C L U D E D :
Screen Frame
W A R N I N G
AV S - 0 2 1 - S M K 1 - I N S T - A - M AY 2 0 1 6
Installation Instructions for
AV/VC One Screen Mount Kit
AV S / 0 2 1 / S M K 1
A V S / 0 2 1 / S M K 1
VESA Rail x2
REFER ALSO TO MAIN
INSTALLATION INSTRUCTIONS
FOR AV/VC ONE
I M P O R TA N T N O T E
For dual screen installations you
will require 2x AVS/021/SMK1
Screw x2
E L E C T R I C A L S A F E T Y
•
Safe installation of electrical equipment is the responsibility of the installer.
•
Colebrook Bosson Saunders recommends that only double-insulated
electrical equipment and cables are installed in AV/VC One unit.
M A I N T E N A N C E A N D I N S P E C T I O N
•
Ensure all screws and fixings are fully tightened and occasionally re-tighten if necessary.
•
Clean with a dampcloth. DO NOT use solvents.
D I S C L A I M E R
As part of Colebrook Bosson Saunders ongoing product improvement
programme, the design of products may change without prior notice and
details may vary from those illustrated.
VESA fixing kit
Washer x4
Hex Nut x2
Advertisement
Summary of Contents for AV/VC One AVS/021/SMK1
- Page 1 Colebrook Bosson Saunders recommends that only double-insulated electrical equipment and cables are installed in AV/VC One unit. M A I N T E N A N C E A N D I N S P E C T I O N •...
- Page 2 Note that screen sizes larger than 65” may be mounted in dual screen configuration but only if the AV/VC One is stabilised by securing to the wall (or building structure) using the AV/VC One Wall Brace Kit (Product Code: AVS/021/WBK1) Note that maximum screen weight limits still apply, regardless of screen size.
- Page 3 Install single frame to column 1 . 1 I N S T A L L S C R E E N F R A M E T O S C R E E N S U P P O R T B R A C K E T S I M P O R TA N T N O T E 1 .1 A 1 .1 b...
- Page 4 I N S T A L L I N G A C A M E R A M O U N T ? If your AV/VC One installation requires YOU wILL NEED: a Camera Mount please install it at this...
- Page 5 Install screen onto column 3 . 1 I N S T A L L S C R E E N O N T O S C R E E N F R A M E /FB1 e - Front Box Kit (incl Front Panel) I M P O R TA N T N O T E Ensure that the lower screw is withdrawn so it does not obstruct...
- Page 6 Install dual screen frames to column 4 . 1 F I X 2 X S C R E E N F R A M E S T O G E T H E R I M P O R TA N T N O T E Ensure all fixings are fully tightened 4 .
- Page 7 I N S T A L L I N G A C A M E R A M O U N T ? If your AV/VC One installation requires YOU wILL NEED: a Camera Mount please install it at this...
- Page 8 Install screens onto column 6 . 1 I N S T A L L B O T H S C R E E N S O N T O S C R E E N F R A M E I M P O R TA N T N O T E I M P O R TA N T N O T E h E AV Y L O A D...
- Page 9 6 . 4 S E C U R E S C R E E N S T O S C R E E N F R A M E I M P O R TA N T N O T E Ensure ALL FOUR fixing screws are fully tightened 6 .
