  • Page 1 Quantum II RFID ECU Installation instructions PK3724-T - 2019 - 05...
  • Page 2 Components Quantum II RFID ECU Exploded View Figure 1 Quantum II RFID ECU ITEM PART NUMBER DESCRIPTION QTY. A21710-COLOR Quantum II RFID Reader Assembly A32760-COLOR Quantum II RCU Faceplate 94640 RCU Gasket A22770 Mounting Bracket A28732-RMO PCB Assembly / RFID MT2...
  • Page 3: Product Description

    ECU. There are many variations in elevator controls and local codes; for this reason, the ECU must be installed by a qualified elevator technician Quantum II RFID ECU PK3724_T 05-19...
  • Page 4: Installing The Ecu

    (Refer to the exploded diagram Figure 1) Surface mount reader installation 1. Insert the ECU assembly through the elevator pan- el cut out (Surface mount prep) and secure it with four (4) #6 screws. Quantum II RFID ECU PK3724_T 05-19...
  • Page 5: Installation Steps

    Installation Steps Flush Mount Reader Figure 4 Flush Mount Reader Installation Dimensions 3.38 ELEVATOR PANEL 1.20 1.71 2.30 2.37 2.05 Figure 5 Flush Mount Reader Installation Template 1.75 1.50 Ø.88 3X Ø.281 Quantum II RFID ECU PK3724_T 05-19...
  • Page 6 Installation Steps Surface Mount Reader Figure 6 Surface Mount Reader Installation Dimensions 4.56 ELEVATOR PANEL 4.48 1.71 2.37 2.05 Figure 7 Surface Mount Reader 3.25 Installation Template 1.81 1.63 2.25 3.25 4X #6-32 TAPPED HOLE Quantum II RFID ECU PK3724_T 05-19...
  • Page 7 Refer to fig 8 for proper orientation Reader Power Plug the reader power Red lead into the white power port on the ECU PCB. Refer to fig 9. Quantum II RFID ECU PK3724_T 05-19...
  • Page 8 Relay 5 Amp SPDT Reader power connector Power leads 12 to 24 volts MAX AC or DC @125mA Relay leads Red = Common (COM) Blue = Normally Open (NO) Black = Normally Closed (NC) Quantum II RFID ECU PK3724_T 05-19...
  • Page 9 Figure 10 Typical ECU Wiring 12 to 24 Volts AC or DC Not Supplied Floor call Button Common Floor call Button Floor call Button White Floor call White Button Blue NO Red COM Black NC Quantum II RFID ECU PK3724_T 05-19...
  • Page 10 If the ECU is programmed to the property verify that all property programmed keys function to the specifica- tions of the properties key design. Appearance Verify that the readers finish is free of blemishes or scratches that would distract from the ECUs appearance. Quantum II RFID ECU PK3724_T 05-19...
  • Page 11: Troubleshooting Table

    FCC Warning: The users of this equipment shall not change or modify the equipment in any way, or they could void their authority to oper- ate the equipment under FCC rules. ©2019 dormakaba All trademarks and registered trademarks are the property of their respective owners. Quantum II RFID ECU...
