T Platen Foil Blocking Conversion
Our Ref:
Key Features:
Price:
Contact us today for more details
Tel: +44(0)1473 725161 Email: info@sfservices.com
Heidelberg 10" x 15" / 26cm x 38cm
The Foil Expert is simply the most innovative and simple hot
foil conversions to use and fit, integrating neatly into the
original press design; installation requires no drilling or screw
fixings. We have designed the kit for quick and easy
installation, without compromising style and quality
2009d
1-Year part warranty
1 new foil pull unit – (hologram registration optional extra)
1 zone low profile honeycomb heater plate (lightweight 6 kg)
Foil tension mounting system (up to 6 foil rolls)
On Request
Advertisement
Summary of Contents for HEIDELBERG Foil Expert
- Page 1 Heidelberg 10” x 15” / 26cm x 38cm T Platen Foil Blocking Conversion The Foil Expert is simply the most innovative and simple hot foil conversions to use and fit, integrating neatly into the original press design; installation requires no drilling or screw fixings.
-
Page 2: Electrical System
Heidelberg 10” x 15” Platen Foil Blocking Conversion – FOIL EXPERT Foil Expert Features: Quick and easy to install (self-installation) Substantially constructed and mounted on the top of the press Up to two full width rewind rollers (optional extra) ... -
Page 3: Warranty
Heidelberg 10” x 15” Platen Foil Blocking Conversion – FOIL EXPERT Maintenance history and documentation The machine includes: Machine documentation • Operators manual • Parts Manual • Electrical wiring diagram • Installation, commissioning and requirements The conversion dimensions are: Height 290mm x width 900mm x depth 300mm - Weight 10kg The electrical supply is: single phase 110 or 220/240v –... - Page 4 Heidelberg 10” x 15” Platen Foil Blocking Conversion – FOIL EXPERT Foil Handling Maximum foil diameter 122 meters Foil core size 25.4mm ( 12mm / 16mm core optional) Minimum distance between foil rolls Number of foil rewinds 1 full width (2 optional)
- Page 5 Appendix 1 T presses have 2 register methods, 1. Fixed lays 2. Register lay bar mechanism. Using Lay bar mechanism and fixed lays, you can only use a 12mm / 16mm foil bar with a reduced width of the heater plate, this is due to the presses lay bar mechanical linkage, shown below.
- Page 6 9. Switch on Unit – Very simple to install 10. Certain top guards will require slightly modifying to secure back on top. 11. Fit Pull-through sensor to provide a signal to Foil Expert each machine revolution. 12. Full instructions will accompany the Foil Expert.
- Page 7 Left side mounting frame securing point Right side mounting frame securing point Foil Expert Left side mounting bracket securing point Foil Expert Right side mounting bracket securing point HEATER PLATE MOUNTING USES ALL ORIGINAL LOCATION POINTS Heater plate left bottom securing point...
- Page 8 Fit Sensor at pump location using original Heidelberg drillings. *Bracket with sensor fitted is secured in position using the pump drive housing. *When the pump rotates part 1. Passes the sensor Part 2 and activates the Foil Expert each time. PUMP ARM PART 1...
- Page 9 Heater plate plug & socket to allow removal of Heater plate to = Set up dies or insert Cutting Chase for cutting & Creasing Heater plate side locating plates (Using original Heidelberg fixing holes) Contact us today for more details...
