  • Page 1 AWC708 Lite Motion Control System User Manual Laser Motion Control System RV 1.4 2017.06 www.sztrocen.com Copyright © 2016 Trocen Automation Tech. Co. Ltd. All rights reserved.
  • Page 2 Copyright TROCEN AUTOMATION TECHNOLOGY CO. LTD. Patent Trocen has already applied for a patent on our laser motion control system. Users have the responsibility to point out the design error and establish Attention! protection mechanisms. Trocen does not accept any responsibility or liability for any damage or loss resulting from improper operation.
  • Page 3: Table Of Contents

    AWC708 Lite User Manual Contents Outline............................1 1.1. Terms..........................1 1.2. Snapshot.......................... 1 LaserCAD Installation........................ 1 Hardware Installation........................1 3.1. Hardware Parts........................1 3.1.1. Accessories........................1 3.1.2. Panel........................2 3.1.2.1. Overview of Panel..................2 3.1.2.2. Size of Panel....................3 3.1.3. Wiring Board.......................3 3.1.3.1. Overview of Wiring Board................. 3 3.1.3.2.
  • Page 4: Outline

    I/O with control card of driver. Hardware Including panel, wiring board and accessories 1.2. Snapshot AWC708 Lite series, high efficiency in production, invented by Trocen for around 5 years, combines LaserCAD with controller and reduce product costs. Features of LaserCAD: User-friendly and versatile ...
  • Page 5: Panel

    Network Connect computer and panel. Cable CN1&CN2 as one set to connect wiring board and Cables panel. Extension Extension cords allow for long distance between Cords USB and network cable. 3.1.2. Panel 3.1.2.1. Overview of Panel...
  • Page 6: Size Of Panel

    3.1.2.2. Size of Panel 3.1.3. Wiring Board Wiring board plays a role of connecting panel and other parts, including: Connecting to driver  Detection of limit signal from axis  Detecting input signal  I/O signal and corresponding power supply unit ...
  • Page 7: Size Of Wiring Board

    3.1.3.2. Size of Wiring Board 3.2. Electric Connection 3.2.1. Wiring Diagram 3.2.2. Unit Port and Wiring Diagram on Wiring Board 3.2.2.1. Power Supply Port on Wiring Board The power supply for wiring board and panel and pay more attention to polarity when you are connecting them.
  • Page 8: Port Of Panel And Wiring Board

    Port No. Title Explanation 24V positive polarity 24V grounding 3.2.2.2. Port of Panel and Wiring Board CN cables connecting panel to wiring board. Title Explanation Connect CN1 to panel Connect CN2 to panel 3.2.2.3. Signal Input Port on Wiring Board There are two ports for signal input.
  • Page 9: I/O On Wiring Board

    3.2.2.4. I/O on Wiring Board There are two output ports for power supply outside and signal control. Ports Title Explanation 1.OUT OUT1 Blowing signal (blowing all the working time) OUT1 Blowing when output is high logic level OUT1 Do not blow when output is low logic level OUT2 Blowing signal (blow when laser is powering on) OUT2 Blowing when output is high logic level...
  • Page 10: Laser Power Supply Port On Wiring Board

    3.2.2.5. Laser Power Supply Port on Wiring Board There are two output ports on wiring board. Ports Title Explanation 5.LASER2 DC5V 5V power supply positive output 6.LASER1 Water protection input signal Laser power Laser switch signal Grounding output Here’s one road of laser’s wiring diagram as an example. 3.2.2.6.
  • Page 11: Input Port Of Limit Signal On Wiring Board

    3.2.2.7. Input Port of Limit Signal on Wiring Board 4 roads of limit signal of sensor on wiring board. 2 limit signals input on two side of each axis. (There are hard limit and origin limit.) X/Y limit signal input ...
  • Page 12 Limit Switch ELY+: Limit switch on another side opposite to origin on Y axis. ELY-: Limit switch on origin on Y axis.
