- Page 1 TECHNICAL BULLETIN Ri 6230 SUBJECT: BULLETIN INDEX 10/10/00 SUBJECT: BULLETIN # NEW MODEL PRODUCT INFORMATION ....................1...
- Page 2 Feed and long-life consumables. Training for the Ri 6230 is available at our Dallas NTC. The class is 5 days and will cover Print/Scan System L. Please contact your Regional offices to sign up for Ri 6230 Training Certification or use the new on-line Training Reservation System on Dealernet.
- Page 3 Includes Printer Board, Scanner Board (NS-20) and Network Card (IB-20) and CD-ROM’s containing the Print Drivers, Network Utility, Scanner Utility and Paper Port. The IB-20 NIC provides 10Base-2, 10/100BaseT Networking. Ri 6230 YIELDS & COST PER COPY Description Part Number...
- Page 4 EP-ROM is equal to or higher than the number given in the chart above. Operation problems can occur if the processing speed is a lesser value. NEW & REPAIR PRINTED CIRCUIT BOARDS PCB NAME NEW PCB P/N REPAIR PCB P/N REPAIR PCB PRICE Main PCB (Ri 6230) 2A068081 8492A081 Engine Output PCB 2A001161 8492A061 Operation Unit Main PCB...
-
Page 5: Preventative Maintenance
Ri 6230-01 October 10, 2000 Page 4 PREVENTATIVE MAINTENANCE Ri 6230 PM CYCLE Ri 6230 MONTHLY VOLUME 300,000 prints. 300,000 prints 300K PM Kit Contents P/N 5832A030 $101.59 Items Description Qty. 36793312 Cleaning Blade 2A018050 Cleaning Brush 36718110 Terminal, Cleaning Brush... - Page 6 Ri 6230-01 October 10, 2000 Page 5 Ri 6230 Machine Specifications Type Console Copying system Dry, indirect electrostatic system Originals Sheets and books Maximum size: 11" x 17" Original feed system Fixed Copy paper Cassette and duplex unit: Plain paper 16~24lb. Bond Bypass table: Plain paper 16~43lb.
- Page 7 Ri 6230-01 October 10, 2000 Page 6 Noise and Ozone Levels Noise Pursuant to JIS Z-8731 (acoustic pressure level, equivalent noise) (1) Stand-by Fan Motor Rotating 48db (2) During Warm-up 59db (3) During Copying Main Body 64db Main Body + SRDF-1...
- Page 8 Ri 6230-01 October 10, 2000 Page 7 F-4220 Saddle Stitcher Specifications Type Floor standing Number of trays Sort tray: 1 Non-sort tray: 1 Paper Weight 17 ~ 53lb. Bond Stacking capacity Sort tray 1 When not stapling/non-sort: 1000 sheets, (11" x 8 1/2", 8 1/2" x 11"R) 500 sheets, (11"...
- Page 9 Ri 6230-01 October 10, 2000 Page 8 System Overview Ri 6230...
- Page 10 300 x 300 dpi or 600 x 600 dpi, software switchable Print Size 11 x 17, 8.5 x 14, 11 x 8.5, 8.5 x 11R, 5.5 x 8.5R, envelopes +1.4, -0.5 Print Speed (Ri 6230) One-sided 11 x 8.5 sheets per min. +1.4, -0.5 11 x 17 sheets per min.
- Page 11 Ri 6230-01 October 10, 2000 Page 10 Additional Procedure for Installation of the Cap Ref. No. Part No. Description Qty. Protective Cap 1. When the 10Base-2 connector is not being used, attach the Cap firmly to the connector as shown in Fig.
- Page 12 Ri 6230-01 October 10, 2000 Page 11 IB-20 Specifications (Network Board) Interface 10BaseT and 100BaseT (shield cable) 10Base 2 Connector RJ45 1Port Protocols TCP/IP, IPX/SPX, AppleTalk, NetBEUI NOS Support Win95/98/2000 Win NT 3.5x/4.0x, MAC System 7.6.1 and Later, Novell NetWare 3.1/3.11/3.12/4.1/4.11 Unix Sun OS4.1.1, 4.1.2/4.1.3...
-
Page 13: Sending E-Mail
Ri 6230-01 October 10, 2000 Page 12 Email Function Limitations E-mail Size Limit Setting The E-mail function cannot be used if either 1 of the below 2 restrictions applies. 1. Scanner Delivery Utility (Mail Block) 2. SIM 338 (E-mail size limit setting) -
Page 14: Memory Management
Page 13 Memory Management The Ri 6230 uses common 12 MB of Bitmap memory built into Memory Board 1 used for copying and printing functions. This is considered Work Memory and can not be expanded. The Ri 6230 has one Standard Memory Board (See Chart Below) with 64MB of Memory (non-upgradable). It is not possible to install an additional Memory Board. - Page 15 Approx. 27’ Main Functions of Tandem Option 1. It is possible to connect two (2) Ri 6230 machines with TS-1, and output 124cpm/ppm. 2. You can evenly divide a job from the copier or the PC, and output to 2 machines.
- Page 16 Ri 6230-01 October 10, 2000 Page 15 Ri 6230 Precaution During Set-up or Preventative Maintenance (Image Formation Unit) If the Image Formation Unit is not inserted completely, the Drum Couplings will not mesh correctly, causing poor Drum rotation. Since the Drum does not rotate during this period, an excessive charge will be placed on one area, causing damage and in some cases pinholes on the Drum.
- Page 17 Page 16 Updated Service Information The Information outlined below was not available at the time of the Ri 6230 introduction. Please add this information to your Service Manual and/or Parts List. Initial production machines manufactured before September 2000 do not have the Main Switch Junction Wiring installed.
- Page 18 Ri 6230-01 October 10, 2000 Page 17 U058 (Setting the paper deck feed timing data) Maintenance Mode U058 will set the ON/OFF timing of the paper feed conveying clutch for the large capacity paper Tray (LCT). Purpose: Maintenance Mode U058 has been added to compensate for the quality of paper being used. An adjustment can be made if a paper jam or multiple paper feed occurs.
- Page 19 Ri 6230-01 October 10, 2000 Page 18 Adjustment Procedure 1. From the Maintenance Mode, Enter U339. Press the start key. 2. Select “ON” or “OFF”. Default setting: “OFF” Display Contents The drum heater will be turned “ON” when the main switch is turned OFF.
- Page 20 Ri 6230-01 October 10, 2000 Page 19 3. The following screen will be displayed. 4. Select the mode according to the end users specification. Default setting: Energystar compliance. Display Contents Instant Ready The fixing control temperature will not be lowered and only the operation panel display will be turned OFF.
