Summary of Contents for Kenyon ALL SEASONS A70026
- Page 1 www.CookWithKenyon.com ALL SEASONS SIDE WHEEL GRILL CART ® ASSEMBLY INSTRUCTIONS Part # 143875 Created: August 27, 2013 Revised: March 19, 2014...
-
Page 2: Table Of Contents
1. Unplug grill and allow to cool. 2. Remove any utensils or cooking equipment from cart shelf. 3. Grasp underneath your grill cart between the legs from the side without wheels. GRILL LOCATION GRASP AREA FOR PULLING CART FIGURE 1 - KENYON ALL SEASONS™ GRILL CART... -
Page 3: Product Specifications
28 1/2" 28 1/2" 13 1/2" 13 1/2" 12" 12" 31 3/16" 31 3/16" 28" 28" 25" 25" FIGURE 2 - GRILL CART DIMENSIONS Kenyon International, Inc. 8 Heritage Park Road P.O. Box 925 Clinton, CT 06413 USA Phone: 860-664-4906 www.CookWithKenyon.com... -
Page 4: Care Instructions
CARE INSTRUCTIONS Your Kenyon grill cart came with a sample bottle of stainless steel cleaner. Use this cleaner once a month to keep your grill cart looking like new. Rub the stainless steel cleaner with the grain, never across or diagonally. -
Page 5: Instructions
Instructions Step 1 - Unpack and Inspect Grill Cart Components a. Unpack cart components carefully, laying the parts out on a clean work surface. Check for damage or missing items. Refer to the package content list. b. Strip all of the protective vinyl from the sheet metal components. Leave any visible paint marks intact. - Page 6 e. Place (1) black washer over each axle. f. Place (1) angle end bushing onto each axle over the washer, with the angle end surface facing up. g. Slide (1) wheel/axle assembly onto one of the legs, aligning the axle end to the outer hole at the bottom of the leg.
- Page 7 Step 3 – Leg to Top Assembly a. Place the grill cart top on the work surface with the leg sockets facing up. The color paint marks will be visible along the sockets. Refer to figure 4. b. Remove the (4) quick release pins from the hardware kit. c. Slide each leg into the socket with the corresponding color mark, mating the lines of the legs to the lines of the cart top as shown in figure 4. The fit may be snug, you may need to wiggle the leg around to get it to seat fully.
- Page 8 Locate the cutting board and wash with warm soap and water. Allow to dry. Step 6- Grill and Cutting Board Installation a. Place your KENYON All Seasons grill into the cart top toward the side without the wheels, routing the GFCI electrical cord through the cart top opening and out toward the rear of the cart. Refer to figure 1. Maintain the grill location to the side of the cart...
