Eufficio Innera Leisure ISRAEL Installation Instructions

Design & Electric
INSTALLATION INSTRUCTIONS

Components:

1 x Innera Leisure

Critical safety information:

Prior of use, please examine and verify that the product is not defected. Please do not install or operate if there is a defect of any kind.
If in any case you are facing misunderstanding of installation procedure, the installation should be carried out by certified electrician
Make sure you are installing the product on smooth straight surface. Do not install in any case that the surface is not straight or if there are levels differences.
Make sure water will not penetrate into the unit. In any case please make sure you are installing the unit, where proper leakage protection device is connected.

Installation:

L
W
Drill hole into the surface according to the
Installation Table on page 2. Please verify
your purchased item's model No and drill the hole
according to the model's cutout dimensions.
Tight the locking handles by install it on the rails
and push it up to the surface.
1
REMARK: In case you need to connect the
Innera Leisure to a standard socket, you should buy
a starter cable separately which not included in this
Kit and connect it according to illustration above.

Cleaning:

The product can be cleaned by a soft and dry fabric. Please do not use moisture, abrasives materials,solvents or any detergents which can be conductive
Engineered in Germany
Innera Leisure
Read the instructions prior to installation.
ATTENTION:
2 x Locking
Handle
A
Remove the locking Handles by pulling & Pushing
it down the rail before you are Inserting the Innera
Leisure into the hole.
D
Tight the handles strongly to the surface and
verify the Innera Leisure is firmed and cannot be
rotated.

Operation:

2
G
For use, press the cover.
ISRAEL
Tools required:
Power Saw
B
Insert the Innera Leisure into the hole.
E
Connect the GST Male connector to power
and the Innera Leisure is ready for use.
The Innera Leisure is ready for use
1
Hole Cutter Power Drill
C
F
