OWNER'S MANUAL
TRINITY PRO 72" STAINLESS STEEL ROLLING
WORKBENCH W/ ADJUSTABLE TOP
Model # TLSF-7211
Important / Important / Importante
FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS
Directives intelligentes
POUR DES DIRECTIVES D'ASSEMBLAGE 3D RAPIDES ET FACILES
Instrucciones Inteligentes
PARA INSTRUCCIONES DE ENSAMBLAJE RÁPIDAS Y SENCILLAS EN 3D
DOWNLOAD THE FREE APP | TÉLÉCHARGER L'APPLICATION GRATUITE | DESCARGUE LA APLICACIÓN GRATUITA
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TRINITY Pro TLSF-7211
Summary of Contents for TRINITY Pro TLSF-7211
- Page 1 OWNER’S MANUAL TRINITY PRO 72” STAINLESS STEEL ROLLING WORKBENCH W/ ADJUSTABLE TOP Model # TLSF-7211 Important / Important / Importante FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS Directives intelligentes POUR DES DIRECTIVES D’ASSEMBLAGE 3D RAPIDES ET FACILES Instrucciones Inteligentes PARA INSTRUCCIONES DE ENSAMBLAJE RÁPIDAS Y SENCILLAS EN 3D...
-
Page 3: Parts List
PARTS LIST Your TRINITY PRO 72in Stainless Steel Rolling Workbench w/ Adjustable Top should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com. - Page 4 ASSEMBLY INSTRUCTIONS STEP 1 Location of parts: 1) KEYS (H) are hooked to key leash mounted inside TOP MIDDLE Drawer. 2) LINERS (G) are inside BOTTOM RIGHT Drawer. 3) CASTERS (B/C), CASTER BOLTS (D), SHELF SUPPORTS (F) and CRANK (I) are boxed inside BOTTOM LEFT Drawer.
- Page 5 ASSEMBLY INSTRUCTIONS STEP 3 Carefully lift Workbench upright. Two people are needed. Do NOT attempt this alone. E (1) F (4) Position Tab SHELF (E) is shipped inside the bottom cabinet. Tilt SHELF (E) diagonally and remove it from cabinet. Attach SHELF SUPPORT (F) by hooking it over position tab at desired height.
-
Page 6: Usage Instructions
USAGE INSTRUCTIONS RAISE WOOD TOP Insert CRANK (I) into receiver on Workbench. Turn CRANK (I) clockwise to raise wood top. Remove CRANK (I) and store inside drawer after wood top is raised to desired position. I (1) LOWER WOOD TOP Turn CRANK (I) counterclockwise to lower wood top. - Page 7 USAGE INSTRUCTIONS DRAWER REMOVAL Pull drawer out so that it is almost fully extended. On RIGHT-hand side, push black release lever DOWN. On LEFT-hand side, pull black release lever UP. While holding levers as instructed, pull drawer forward until released from slides attached to Workbench (“Workbench Slides”). Note: Slides attached to drawer (“Drawer Slides”) are an integral part of drawer and must be removed along with drawer itself.
- Page 8 SERVICE PARTS LIST – TLSF-7211 TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description ZSV-12-015-1575 Slide (workbench side) XBK-22-006-2615 27” Drawer Liner ZSV-12-001-1575 Slide (drawer side) XBK-22-006-1727 Shelf Liner LNA-06-016-7219 Wood Top XBS-08-017-1421 Right Door...
-
Page 9: Service Parts List
TLSF-7211 SERVICE PARTS LIST – TRINITY Customer Service provides the following replacement parts: NOTE: Replacement keys may be ordered using the code shown on the face of the lock. © 2020 TRINITY - 800.985.5506... - Page 10 WARNINGS Read and understand all instructions. Failure to follow all instructions may result in injury and/or damage. The warnings, cautions, and instructions discussed in this manual cannot cover all possible conditions or situations that may occur. The user must always be aware of their environment and ensure that they use the product in a safe and responsible manner.
-
Page 11: Care And Maintenance
WARNINGS 15. Do NOT store items underneath the wood top. Crushing of items can occur. 16. Do NOT let children play near the workbench. 17. Load the workbench starting with the bottom drawers to prevent workbench from tipping. 18. Make sure all drawers and cabinet are closed tightly before locking or unlocking. CARE AND MAINTENANCE •... - Page 12 © 2020 TRINITY - 800.985.5506...
-
Page 13: Product Registration
PRODUCT REGISTRATION Thank you for purchasing a TRINITY PRO 72in Stainless Steel Rolling Workbench w/Adjustable Top. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com. - Page 14 © 2020 TRINITY - 800.985.5506...
-
Page 15: Year Limited Warranty
Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the TRINITY PRO 72in Stainless Steel Rolling Workbench w/Adjustable Top (“Product”) that each Product shall be free from defects in workmanship and materials for a period of 1 year from the date of original purchase. - Page 16 CONTACT US QUESTIONS? NEED PARTS? WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service. TRINITY Customer Service TEL: 800.985.5506 FAX: 310.347.4134 EMAIL: customerservice@trinityii.com...
