AAF Flanders SAAFShield Installation, Operation And Maintenance Instructions

T H E W O R L D L E A D E R I N C L E A N A I R S O L U T I O N S
Detecting Unit Real-Time Reactivity Monitor
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS
Table of Contents
1.0 Principles of Operations
2.0 Components
3.0 Installing Quartz Crystal
Microbalance (QCMs)
4.0 Installing the Detecting Unit
5.0 Troubleshooting
6.0 Connecting to the Reading Unit
7.0 Spare Parts List
SAAFShield
Read and Save These Instructions!
Note: 1. Read and understand all operating instructions before
installing and using the SAAFShield Detecting Unit Real-Time
Reactivity Monitor.
2. Save this manual for future reference.
This instruction manual provides important information on the installation
and operation of the SAAFShield Detecting Unit Real-Time Reactivity
Monitor. These instructions must be carefully followed in order to operate the
unit safely and correctly. If there are any questions regarding the use or care
of this unit, please contact AAF Flanders at 888-223-2003 or by email at
SAAFShield@aafintl.com for assistance.
1.0 Principles of Operation
The SAAFShield Detecting Unit is the non-powered, sensing side of the
SAAFShield system that utilizes Quartz Crystal Microbalance (QCM)
technology to measure metal corrosion due to reactions with the
environment. The SAAFShield Detecting Unit works in combination with
the SAAFShield Reading Unit as part of a system that monitors atmospheric
corrosion in real time or on a periodic basis.
The SAAFShield Detecting Unit's oscillator Printed Circuit Board (PCB)
consists of specially marked tracking where electromagnetic induction
effects are significantly reduced in order to produce the most stable and
accurate frequency reading. As the metal-coated QCM corrodes, the
frequency of oscillation changes. The Detecting Unit has built-in
non-offgassing Ethylene Vinyl Acetate (EVA) foam spacers to prevent
unwanted movement of the QCMs within the enclosure.
®
