  • Page 1 Parker Assembly and Installation Instructions ...with people in mind 06.AL.00_12GB • 02/2016...
  • Page 2 Design Policy and Copyright ® and ™ are trademarks belonging to the ArjoHuntleigh group of companies. © ArjoHuntleigh AB 2011. As our policy is one of continuous improvement, we reserve the right to modify designs without prior notice.The content of this publication may not be copied either whole or in part without the consent of ArjoHuntleigh AB.
  • Page 3: Table Of Contents

    Contents Safety Precautions ..............5 Measurements and Weights ..........6 Site Preparation ..............8 Floor/Walls ..................8 Space requirements around the bath ..........8 Unpacking and Assembly ............ 10 Preparations ................... 10 Parker bath with details ..............10 Drain installation details ..............11 Special installations ...............
  • Page 4 Intentionally left blank...
  • Page 5: Safety Precautions

    Safety Precautions Definitions in this manual Make sure that the electrical supply components are according to the data • label. WARNING MODEL: AL2 XXXX-EU Meaning: Max Patient Weight 120 mm 210 kg / 463 lbs 4 3/4" Max Load Safety warning. Failure to understand and obey 300 kg / 661 lbs this warning may result in injury to you or to Product no...
  • Page 6: Measurements And Weights

    Measurements and Weights The Parker bath is delivered in one box. • • Measurements, box with contents L = Length 2035 mm (80 1/8”) H = Height 1128 mm (44 3/8”) W = Width 948 mm (37 3/8”) • Weight, box with contents approximately Depending on selected options 189 - 196 kg (417 - 432 lbs)
  • Page 7 50 mm 2” 1500 mm 730 mm 59" 28 3/4" Reclined 1960 mm 77 1/8" * These dimensions are approximate and unless otherwise stated, should be treated as minimum requirements.
  • Page 8: Site Preparation

    Site Preparation Floor/Walls The doorway shall not have a threshold but if necessary, it should be made of depressive rub- Prior to installing the Parker bath, the floor and ber material, to facilitate the use of a mobile aid. walls of the required area must be finished. The Parker bath must be installed more than The floor should be made of a slip resistant ma- 250 mm (10”) from any fixed object, to avoid...
  • Page 9 Alcove/Corner position 2460 (96 7/8") 250 (9 7/8") 250 (9 7/8") 250 (9 7/8") 2700 (106 1/4") * 1700 (66 7/8") * Peninsular position 3250 (128") * 250 (9 7/8") 3010 (118 1/2") 800 (31 1/2") 800 (31 1/2") 1700 (66 7/8") * * Space required when integrating with a lifting device...
  • Page 10: Unpacking And Assembly

    Unpacking and Assembly Preparations CAUTION During the unpacking of this product, always make sure that ALL staples are fully removed when removing the outer cover. This will prevent damage to the laminate surface. Remove the wooden lid, and then the box covering the product. Check the contents: Parker bath with details 1 Parker bath tub 5 Cable ties...
  • Page 11: Drain Installation Details

    Drain installation details 1 Drainage hose 690 mm 5 Elbow Ø40 mm (1 9/16”), 90° 2 Drainage hose 2100 mm 6 Pipe adapter with o-ring, Ø40 mm (1 9/16”) - Ø 38 mm (1 1/2”) 3 2 hose clamps 7 Air-gap bracket, assembly kit (Option) 4 3 pipe connectors Ø40 mm (1 9/16”) Special installations 1 Shower stand with assembly kit (GB only)
  • Page 12: Water Installation

    Water Installation WARNING Hot and cold water supply must be fitted with local isolating valves. CAUTION All plumbing connections and installations must comply with all relevant local, state or federal regulations and plumbing codes. NOTE Flush connection hoses prior to connecting to the mixer. NOTE For water supply requirement and water hoses requirements, see section Site Requirements and Specifications.
  • Page 13 Intentionally left blank...
  • Page 14: Mounting Of Parker Bath

    Mounting of Parker bath Final placement 4. Turn the nut on each foot to adjust the Parker bath height and lock it into its posi- • tion. Make sure that the Parker bath is lev- WARNING elled horizontally and ensure that the bath is Before lifting the Parker bath check stable.
  • Page 15 The following steps are not applicable for baths with the optional base on the legs. Two tracks Turn nut to adjust Parker bath’s height. Incorrectly mounted Correctly mounted...
  • Page 16: Installation Overview

    Installation Overview Mains connection Equipotential electrical and water bonding point Field wiring Hot water Cold water Drain to connect from wall from wall to floor or wall or floor or floor...
  • Page 17: Electrical Installation

    Electrical Installation WARNING • All plumbing and electrical work must be carried out by qualified personnel according to local codes and regulations. • To avoid risk of electrical shock, this equipment must only be connected to a supply mains with protective earth. •...
  • Page 18: Drain Installation

    Drain Installation Drain requirement Min. drainage capacity 100 l/min (26.4 US gal./min) Ø38 (1 1/2”) / Ø40 mm (1 9/16”) (Inner dimension) Drain connection size Ø46 mm (1 13/16”) (Outer dimension) The bath must be connected to a drain. Use an air gap bracket, if needed. Connections must be done in accordance with local regulations.
  • Page 19 Water trap Ø40 mm (1 9/16”) Inner dimension Drainage hose Hose clamp Pipe connector Pipe adapter Pipe connector Elbow Hose clamp Air gap bracket Pipe adapter Drainage hole for with o ring the drainage hose. M5 screw Self tapping Self tapping screw Drainage hole for the MultiClean.
  • Page 20: Drain Installation - Wall

    Drain installation - Wall Customized connection (Figure 3.) The distance between the floor and wall drain can only be at a maximum height of 100 mm At certain situations the elbow can be used to (4“). (Figure 1.) make the installation more suitable. Straight connection 1.
  • Page 21 Max.100 mm (4”) Hose clamp Ø38 mm Pipe adapter, use at (1 1/2”) wall connection Hose clamp Pipe Water trap connector Drainage hose Ø40 Pipe connector, use at mm (1 9/16”) wall connection Water trap Elbow...
  • Page 22: Water Connection

    Water Connection • • In house requirement 25 l/min (6.6 US gal/min) Min. flow / supply pipe 50 l/min CW + HW (13.2 US gal/min CW + HW) Water connection hoses requirement Flexible hoses Nominal size DN15 Connection dimension 3/4” B.S.P female Connect with shut off valves Min.
  • Page 23 (Red) COLD (Blue)
  • Page 24: Calibration Of The Thermostat Mixer

    Calibration of the Thermostat Mixer •l 7. If not in compliance, start from step 2 • WARNING by adjusting the brass part to get the right temperature value. Failure to calibrate the thermostatic mixer can lead to a scalding incident 8.
  • Page 25 WARNING! Do not use before calibration. AVERTISSEMENT! Ne pas utiliser avant calibration. WARNUNG! Vor der Kalibrierung nicht benutzen. WAARSCHUWING! Niet gebruiken vóór kalibreren. AVVERTENZA! Non utilizzare prima della taratura. ADVERTENCIA! No utilizar antes de la calibración. UWAGA! Nie używać przed przeprowadzeniem kalibracji. Water temperature adjustment...
  • Page 26: Connecting Disinfectant Bottle

    Connecting Disinfectant Bottle • 1. Put on protective gloves and glasses. CAUTION 2. Pull out the compartment for disinfectant To prevent equipment surface damage bottle and place the disinfectant bottle in the only use: compartment. (Figure 1.) • Arjo Clean 3.
  • Page 27 Attach suction part to bottle Turn suction part for right mix ratio Arjo Disinfectant Cleanser IV (60 Arjo General Purpose Disinfectant (35) Arjo Clean (30) Cen-Kleen IV (30...
  • Page 28: Shower Stand (Gb Option Only)

    Shower Stand (GB option only) 1. Prior to mounting the base shower stand 11. Check that the rotational movement of remove the base cover over the legs. the shower is 180 degrees over the bath. (Figure 1.) Make sure the pole is vertical. (Figure 8.) 2.
  • Page 29 Remove base cover Long screws Washers Assemble from bottom up Tighten the grub screws Short screws min. 44 mm (1 3/4”)
  • Page 30: Site Requirements And Specifications

    Site Requirements and Specifications Floor Maximum Load (resident + water) 300 kg / 661 lbs Maximum floor load 5400 N/m Maximum floor pressure 0,6 N/mm Slope 1:50 Ceiling height Min. 2510 mm + 50 mm (98 3/4” + 2”) Transport and Storage Ambient temperature range -20°C - 70°C (-4°F - 158°F)
  • Page 31 Drain requirement Flow capacity 100 L/min, 26.4 US Gal/min Position (floor, Wall) either Drain connection size Ø40 mm (1 9/16”) (Inner Dimension) Ø46 mm (1 13/16”) (Outer dimension) The bath must be connected to a drain. Use an air gap bracket, if needed. Connections must be done in accordance with local regulations.
  • Page 32 Intentionally left blank...
  • Page 33 Intentionally left blank...
  • Page 34 Intentionally left blank...
  • Page 35 AUSTRALIA FRANCE POLSKA ArjoHuntleigh Pty Ltd ArjoHuntleigh SAS ArjoHuntleigh Polska Sp. z o.o. 78, Forsyth Street 2 Avenue Alcide de Gasperi ul. Ks Piotra Wawrzyniaka 2 O’Connor CS 70133 PL-62-052 KOMORNIKI (Poznan) FR-59436 RONCQ CEDEX Tel: +48 61 662 15 50 AU-6163 Western Australia Tel: +61 89337 4111 Tél: +33 (0) 3 20 28 13 13...
  • Page 36 Getinge Group is a leading global provider of products and systems that contribute to quality enhancement and cost ef ciency within healthcare and life sciences. We operate under the three brands of ArjoHuntleigh, Getinge and Maquet. Getinge provides solutions for infection control within healthcare and contamination prevention within life sciences.
