HOMEBOX XXL

Congratulations you now have an original Homebox XXL!

HOMEBOX XXL®

Before setting up the Homebox

1. Check all parts are there!

2. Read instructions carefully!

3. Do not equip before

set up is complete.

4. Assemble on a clean and flat

surface.

A x 1

B x 1

C x 2

D x 1

Need help?

Do you have a question about the XXL and is the answer not in the manual?

Page 1 HOMEBOX XXL® HOMEBOX XXL Congratulations you now have an original Homebox XXL! Before setting up the Homebox 1. Check all parts are there! 2. Read instructions carefully! 3. Do not equip before set up is complete. 4. Assemble on a clean and flat surface.
Page 2 HOMEBOX XXL® Assemble (3) and (5) using the plastic connectors. The square edge end of the connectors must be vertical! Create frame like shown left. Put connector onto poles. square edge end pointing downwards!
Page 3 HOMEBOX XXL® Fit in poles (1); (6); (7) and (8) into upper frame. Lay out the tent bottom (A) and place frame carefully into it.
Page 4 HOMEBOX XXL® Pull the tent top (B) carefully over the frame. Pay attention at the corners!!! Zip on parts (C) to Top (A) and Bottom (B). TIP! Start with the top zips first.
Page 5 HOMEBOX XXL® Once you have zipped on parts C (both are identical) your Homebox XXL should look like this (see above) Add Bottom (D) and fix with Velcro.
Page 6 HOMEBOX XXL® Place fixtures and straps into upper frame as shown above. Repeat this process for both sides...
Page 7 HOMEBOX XXL® Even though the Homebox has 2 waterproof floors make sure that the area in which you set up your Homebox Close all zippers carefully. is protected against possible tank leaks or other types of water damage. FINISHED! a. Passive air intakes - there are 2...
