Summary of Contents for MSL SMART LOCKER
- Page 1 Assembly & Installation...
- Page 2 MSL Smart Locker End-user Manual This document consists of two parts, namely “Assembly” and “Installation.” End-users receive “MSL Smart Lockers” (locker) in two formats, namely “Assembled” and “Unassembled.” The assembly part of this document will not be applicable for End-users receiving lockers as “Assembled.”...
- Page 3 Assembly Instructions Step 1: Place the Bottom Cover (1) flat on an even surface where the round holes on all sides in the metal bent upside will be visible. Also, there will two square holes on the left side and two square holes on the right side.
- Page 4 Assembly Instructions (cont.) Step 3: Horizontal Chamber • Place the Left Cover (3) vertically by inserting the studs in the Left Cover (3) into the holes in the left side of the Bottom Cover (1). Note that there are holes at the top to insert the studs facing down in the Top Cover (4).
- Page 5 Assembly Instructions (cont.) Step 4: (figure 6) 1: Place the Top Cover (4) by inserting studs on the right side into the holes on the top of the Right Cover (2) and by inserting studs on the left side in the holes on the top of the Left Cover (3). (figure 7) (figure 8) bottom cover...
- Page 6 Assembly Instructions (cont.) Step 6: • Turn around the locker by 90 degrees and place the Left Cover on the flat surface. • Attach the Door (6) to the Right Cover (2) using the hinges attached to the Door (figure 9) (6) and the hinges attached to the Right Cover (2).
- Page 7 Lockers and in the case of wall mounted In-Home Delivery lockers where hole in a wall is used instead of sliding window. “MSL Wallet ” (iPhones, iPads, and Android Devices) In-Home & Business Delivery Lockers All content in this document copyright © 2020 MySingleLink. All rights reserved.
