Summary of Contents for Unipulse F130
- Page 1 F130 LOADCELL INTERFACE FOR OMRON SYSMAC CJ1 OPERATION MANUAL 06DEC2019REV.1.00...
- Page 2 Thank you very much for purchasing our Loadcell Interface F130. For good performance, and proper and safe use of the F130, be sure to read this operation manual and properly understand the contents of it before use. Also, carefully keep this operation manual so that it can be referred to at any time.
- Page 3 Warning on design ● Before using the F130 as described below, be sure to consult with our sales personnel. - Use in environments not described in the operation manual. - Use in environments that greatly affects human life and assets, such as medical devices, transport equipment, recreational equipment, and safety devices.
- Page 4 ● For turning on/off the power, be sure to keep intervals of 5 seconds or more. ● After power-on, be sure to warm up the F130 for 30 minutes or more before use. ● If the F130 is not used by the specified method, its protective performance may be impaired.
- Page 5 The following notice must be observed when you install F130 unit. 1. F130 is an electrical device that are incorporated in machines and manufacturing installations. F130 conforms to the related EMC standards so that the devices and machines into which F130 is built can more easily conform to EMC standards.
-
Page 6: Table Of Contents
3-1．High Performance I/O Unit Restart Flag ..........7 3-2．Relay Area ....................7 3-2-1 Allocation of Measurement・Hold Data ............ 7 3-2-2 OUT (CPU Unit → F130) ................8 3-2-3 IN (F130 → CPU Unit) .................. 9 3-2-4 Register Allocations for Initial Settings ..........11 4．CALIBRATION METHOD .............12... - Page 7 CONTENTS 5．MEASUREMENT SETTINGS ..........17 5-1．Analog Filter Selection (m+2) ..............17 5-2．Digital Filter Count Setting (m+3) ............17 5-3．Digital Offset (m+4) ................. 17 6．MEASUREMENT・HOLD FUNCTIONS .......18 6-1．Measurement Function ................18 6-2．Hold Functions ..................18 6-2-1 Peak Hold ....................18 6-2-2 Bottom Hold ....................19 6-2-3 Average Hold .....................
-
Page 8: 1．Appearance Description
Operation status (Green) LED OFF Data exchange with CPU has been aborted LED ON Error occurred in F130 Error (calibration error / setting error) or overflow Error detected by the unit LED Blink (A/D input range over / measurement value over) (Red) occurred in F130. -
Page 9: Unit Number Select Switch
F130 acts as a Special I/O unit for Omron SYSMAC CJ1 series PLC. The data exchange between CPU unit and F130 are carried out by the high performance relay area of I/O and DM area. Relay and DM number used by F130 can be selected by the unit number selection switch located on the front panel. -
Page 10: 2．Connection Method
+EXC -EXC 2-2. Sensor Connection 2-2-1. 4-wire Connection F130 input uses an accurate 4-wire sensor connection. Use shielded 4-core cable for this connection and route it apart from noisy lines (power and digital devices) and AC power lines. +EXC -EXC... -
Page 11: 6-Wire Connection
SHIELD CAUTION The strain gauge type sensor excitation voltage of the F130 is 2.5V or 10V (selectable by setting). Set within the maximum excitation voltage of the strain gauge type sensor you use, and then make connection. Use exceeding the maximum excitation voltage may cause abnormal heating and damage. -
Page 12: Connections To Terminal Block
A1 to A9 and B6 to B9 are unnecessary in this specification, please do not connect input and output signal lines to them. Do not apply the voltage from the outside, or do not short-circuit with parts. It may cause malfunction of F130 and external equipment. -
Page 13: 3．Data Exchange With Cpu
Parameter settings for using F130 as a Loadcell Interface. A set of initial setting data for each F130 is allocated, based on its unit number, to a DM area for high performance I/O unit (inside CPU unit), and is written to this area when the unit is powered on, or a refresh cycle is started. -
Page 14: High Performance I/O Unit Restart Flag
15th unit restart flag OFF → ON → OFF A50300 16th unit restart flag A50715 95th unit restart flag 3-2. Relay Area 3-2-1. Allocation of Measurement・Hold Data OUT (CPU unit → F130) Factory- Equiv. Actual Hold Hold Mode Zero Survival... -
Page 15: Out (Cpu Unit → F130)
Survival confirmation request By changing this bit, the data transfer state between the CPU unit and F130 can be confirmed. A response is made to the 7th bit of n+1 CH as this bit is inverted (0 ⇔ 1). -
Page 16: In (F130 → Cpu Unit)
3.DATA EXCHANGE WITH CPU 3-2-3. IN (F130 → CPU Unit) Digital zero response Returns the state of the digital zero request bit. Hold response Returns the state of the hold request bit. Hold value clear response Returns the state of the hold value clear request bit. - Page 17 3.DATA EXCHANGE WITH CPU Mode selection response Returns the state of the mode selection request bit. Set value (n+2) Returns the indicated value of A/D-converted measurement. -32768 to +32767; two's-complement number. Data update counter (n+3) Returns a numerical value incremented by one each time the indicated value is updated (3000 times/sec.).
-
Page 18: Register Allocations For Initial Settings
3.DATA EXCHANGE WITH CPU Average value / strain gauge type sensor output value at the Zero calibration point (n+6) ・In normal operation mode Returns the average measurement value in the section specified by the hold request bit. When the hold request bit turns OFF, data update is stopped, and the average measurement value of that time is held. -
Page 19: 4．Calibration Method
4-1. What is Calibration? Calibration is performed for matching the F130 to a strain gauge type sensor. That is, F130 must be properly adjusted to indicate 10.00kN when an actual load of 10kN is placed on the strain gauge type sensor. -
Page 20: Actual Load Calibration And Equivalent Input Calibration Procedure
Write initial setting data to the DM area that corresponds to Input initial setting data MACH No. Register initial setting data to F130. To do this, either power on F130 Power on, the F130, or restart it by toggling restart flag in the following or restart sequence: OFF →... -
Page 21: Preparation For Calibration
Minimum data items required for performing proper calibration are: Excitation voltage, Minimum scale division, Sensor rated output value, and Sensor rated capacity value. Initial setting data are registered when F130 is powered on or it restarts. Excitation voltage selection (m) Select the bridge voltage supplied to the strain gauge type sensor. -
Page 22: Calibration Mode Selection
2. Make sure that the measurement value (n+2 CH) is stable without fluctuations. 3. Toggle the Zero calibration bit (8th bit of n CH) from 0 → 1. 4. F130 starts Zero calibration procedures when it acknowledges an ON edge (0 → 1) of the Zero calibration bit. -
Page 23: Equivalent Input Calibration
4-6. Equivalent Input Calibration 1. Toggle the Equivalent input calibration bit (10th bit of n CH) from 0 → 1. 2. F130 starts Equivalent input calibration procedures when it acknowledges an ON edge (0 → 1) of the Equivalent input calibration bit. -
Page 24: 5．Measurement Settings
5.MEASUREMENT SETTINGS 5. MEASUREMENT SETTINGS 5-1. Analog Filter Selection (m+2) A low-pass filter is provided for filtering input signals from the strain gauge type sensor and cancelingnoise components. The cut-off frequency can be selected from 3Hz, 10Hz, 30Hz, 100Hz, 300Hz, 1kHz. With an increase in the cut-off frequency, the response becomes faster, but noise components may be indicated. -
Page 25: 6．Measurement・Hold Functions
6-1. Measurement Function Measurement value and data update counter The F130 performs A/D conversion at a rate of 3000 times/sec to calculate the measurement value. Each time the measurement value is updated, the data update counter is incremented by one. Since the measurement value and counter value are returned in pairs, how often you see the measurement data of the F130 can be known from the progression of the counter value. -
Page 26: Bottom Hold
6.MEASUREMENT・HOLD FUNCTIONS 6-2-2. Bottom Hold The maximum value (bottom) in the negative direction of the specified section is held. Measurement value Bottom Detection Hold request Hold value clear request t1: Delay time between the instant when the hold request turns ON and the instant when the mea- surement value hold detection is started t2: Delay time between the instant when the hold request turns OFF and the instant when the mea- surement value hold detection is stopped... -
Page 27: Application Of The Hold Clear Function
6.MEASUREMENT・HOLD FUNCTIONS Point < About average value measurement time > What can be specified as a section for average value hold detection is up to 10 seconds (average count: 30000). Even if the hold request bit is ON exceeding that time, the average value in 10 seconds is held. Attention <... -
Page 28: 7．Block Diagram
7.BLOCK DIAGRAM 7. BLOCK DIAGRAM Reference Sensor voltage voltage (Vref) 4-wire strain gauge Preamplifier type sensor 24 bit ・At DC10V (30mA max) single 350Ωsensor fc selection Excitation voltage selection ・ At DC2.5V (30mA max) single 120Ωsensor Isolator four 350Ωsensors in parallel NOV.RAM PORT... -
Page 29: 8．Dimensions
8.DIMENSIONS 8. DIMENSIONS... -
Page 30: 9．Installation
9.INSTALLATION 9. INSTALLATION 9-1. Connection with CJ1 Unit Multiple of CJ1 units can be connected by simply engaging connectors and locking the slider. Add an end cover to the unit installed to the right most unit. 1. Engage the connector properly to connect units. Fooking hole Fook Connector... -
Page 31: Din Rail Installation
9.INSTALLATION 3. Add an end cover to the right most unit. End cover CAUTION You must install an end cover to the right most units. Without it, CJ1’s CPU unit issues “I/O bus error” (Operation Halt Error) and will not start operation (neithre “operation” nor “monitoring”... - Page 32 9.INSTALLATION 3. Lock all the DIN rail pins by pushing upwards. DIN rail pin 4. Secure the unit by installing a end plate. End plate To fix CJ1 assembly securely, sandwitch the assembly using a pair of endplates from both sides. Fook lower notch of the end plate to the lower plate of the rail ( ①...
-
Page 33: 10．Caution About Power Consumption
Design your system with sufficient consideration given to power consumption so that the total power consumption of the F130 and units of the CJ series (CPU unit, Configuration units, etc.) does not exceed the maximum supply capability of the power supply unit. -
Page 34: 11．Specifications
(Turns on when Normal operation) ERC (Red): Error detected by the unit (Turns on when an alarm occurs or blinks when an error occurs in the F130.) ERH (Red): CPU error (Turns on when an alarm occurs in data exchange with the CPU unit.) -
Page 35: Setting
Calibration value Stored in NOV RAM (non-volatile RAM) Set value Measurement starts with the set values (DM area) written from the CPU unit after power-on. (Not stored on the F130 side) 11-4. Terminal Block Layout Detachable terminal block (M3 screw) SHIELD...
