Weed Eater WET6500A Owner's Manual

Weed Eater WET6500A Owner's Manual

6.5 hp 17 inch tiller
Hide thumbs Also See for WET6500A:
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
MODEL NO. WET6500A
6.5 HP 17 Inch
Tiller
•
Assembly
•
For Parts and Service, contact our authorized distributor: call 1-800-849-1297
Operation
•
Maintenance
•
Service and Adjustments
•
Storage
•
For Technical Assistance: call 1-800-829-5886
Troubleshooting
•
Repair Parts
®
01029-weedeater
186100 Rev. 3 06.17.03 TR
PRINTED IN U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WET6500A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Weed Eater WET6500A

Summary of Contents for Weed Eater WET6500A

  • Page 1 OWNER'S MANUAL MODEL NO. WET6500A 6.5 HP 17 Inch Tiller • Assembly • Operation • For Parts and Service, contact our authorized distributor: call 1-800-849-1297 Maintenance • Service and Adjustments • Storage • Troubleshooting • Repair Parts For Technical Assistance: call 1-800-829-5886 ®...

  • Page 2: Safety Rules

    Safe Operation Practices for Walk-Behind Powered Ro ta ry Tillers TRAINING • Read the Owner’s Manual care ful ly. Be thor ough ly fa mil iar with the controls and the proper use of the equip ment. Know how to stop the unit and disengage the controls quickly.

  • Page 3: Table Of Contents

    PRODUCT SPECIFICATIONS Gasoline Capacity: 3 Quarts (2.8L) Unleaded Reg u lar Oil (API-SF-SJ): SAE 30 (Above 32°F/0°C) (Capacity: 20 oz./0.6L) SAE 5w-30 (Below 32°F/0°C) Spark Plug : Champion (Gap: .030"/0.76mm) RN4C CONGRATULATIONS on your purchase of a new tiller. It has been designed, en gi neered and manu fac tured to give you the best pos sible de penda bil ity and per form ance.

  • Page 4: Tools Required For Assembly

    Your new tiller has been assembled at the factory with exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your tiller, all parts and hardware you assemble must be tightened securely. Use the correct tools as necessary to insure proper tightness. TOOLS REQUIRED FOR ASSEMBLY A socket wrench set will make assembly easier.
  • Page 5 UNPACKING CARTON (See Fig. 2) CAUTION: Be careful of exposed sta ples when handling or disposing of cartoning material. IMPORTANT: WHEN UN PACK ING AND AS SEM BLING TILLER, BE CAREFUL NOT TO STRETCH OR KINK CABLES. • While holding handle assembly, cut cable ties se cur ing handle assembly to top frame.

  • Page 6: Assembly

    ATTACH CLUTCH CABLE (See Fig. 6) • Hook end of clutch cable through hole in control bar bracket if necessary. CONTROL BAR END OF BRACKET CLUTCH CABLE CONTROL BAR BRACKET CLUTCH CABLE FIG. 6 ASSEMBLY CONNECT SHIFT ROD (See Fig. 7) •...

  • Page 7: Know Your Tiller

    KNOW YOUR TILLER READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TILLER. Compare the illustrations with your tiller to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. These symbols may appear on your Tiller or in literature supplied with the product. Learn and understand their meaning.
  • Page 8 The operation of any tiller can result in foreign objects thrown into the eyes, which can result in severe eye damage. Always wear safety glasses or eye shields before starting your tiller and while tilling. We recommend a wide vision safety mask over spectacles or standard safety glasses.

  • Page 9: Before Starting Engine

    TURNING • Release the drive control bar. • Move throttle control to “SLOW” position. • Place shift lever indicator in “F” (forward) position. Tines will not turn. • Lift handle to raise tines out of ground. • Swing the handle in the opposite direction you wish to turn, being careful to keep feet and legs away from tines.
  • Page 10 TO START ENGINE (See Fig. 13) CAUTION: Keep drive control bar in “DISENGAGED” position when start- ing en gine. When starting engine for the fi rst time or if engine has run out of fuel, it will take extra pulls of the recoil starter to move fuel from the tank to the engine.

  • Page 11: Operation

    TINE SHEAR PINS The tine assemblies on your tiller are secured to the tine shaft with shear pins (See “TINE REPLACEMENT” in the Service and Ad just ments section of this manual). If the tiller is unusually overloaded or jammed, the shear pins are designed to break before internal damage occurs to the trans mis sion.

  • Page 12: Maintenance Schedule

    MAINTENANCE SCHEDULE FILL IN DATES AS YOU COMPLETE REGULAR SERVICE Check Engine Oil Level Change Engine Oil Oil Pivot Points Inspect Spark Arrester / Muffler Inspect Air Screen Clean or Replace Air Cleaner Cartridge Clean Engine Cylinder Fins Replace Spark Plug RH Gear Case Grease Fitting (1oz.) 1 - Change more often when operating under a heavy load or in high ambient temperatures.

  • Page 13: Engine Lubrication

    Disconnect spark plug wire before performing any maintenance (except car bu re tor adjustment) to prevent accidental start ing of engine. Prevent fi res! Keep the engine free of grass, leaves, spilled oil, or fuel. Re move fuel from tank before tipping unit for maintenance.
  • Page 14 COOLING SYSTEM (See Fig. 21) Your engine is air cooled. For proper engine performance and long life keep your engine clean. • Clean air screen frequently using a stiff-bristled brush. • Remove blower housing and clean as nec es sary. •...

  • Page 15: Service & Adjustments

    SERVICE AND ADJUSTMENTS CAUTION: Disconnect spark plug wire from spark plug and place wire where it cannot come into contact with plug. TILLER TO ADJUST HANDLE HEIGHT (See Fig. 22) Select handle height best suited for your tilling conditions. Handle height will be different when tiller digs into soil. •...

  • Page 16: Service And Adjustments

    SERVICE AND ADJUSTMENTS TINE REPLACEMENT (See Figs. 24, 25 and 26) CAUTION: Tines are sharp. Wear gloves or other protection when han- dling tines. A badly worn tine causes your tiller to work harder and dig more shallow. Most important, worn tines cannot chop and shred organic matter as effectively nor bury it as deeply as good tines.
  • Page 17 SERVICE AND ADJUSTMENTS TO REMOVE BELT GUARD (See Fig. 27) NOTE: For ease of removal, remove hairpin clip and clevis pin from left wheel. Pull wheel out from tiller about 1 inch (2.5 cm). • Remove two (2) screws from side of belt guard. •...

  • Page 18: Service & Adjustments

    SERVICE AND ADJUSTMENTS ENGINE TO ADJUST THROTTLE CONTROL CA BLE (See Fig. 29) The throttle control has been preset at the factory and ad just ment should not be necessary. If adjustment is necessary, proceed as follows: • With engine not running, move remote throttle control lever to “FAST”...

  • Page 19: Engine Fuel System

    Immediately prepare your tiller for storage at the end of the season or if the unit will not be used for 30 days or more. WARNING: Never store the tiller with gasoline in the tank inside a build ing where fumes may reach an open fl ame or spark.

  • Page 20: Troubleshooting

    TROUBLESHOOTING POINTS PROBLEM CAUSE Will not start Out of fuel. Engine not “CHOKED” properly. Engine fl ooded. Dirty air cleaner. 5. Water in fuel. Clogged fuel tank. Loose spark plug wire. Bad spark plug or improper gap. Carburetor out of adjustment. Hard to start 1.

  • Page 21: Handle Assembly

    REPAIR PARTS TILLER - - MODEL NUMBER WET6500A HANDLE ASSEMBLY PART DESCRIPTION 175769 Control, Throttle 150744 Grip, Handle 159227 Bar, Control 71191008 Screw, Pan Hd. #10-24 8389J Grip, Handle 4497H Clip, Hairpin 108281X Rod, Shift 72110608 Bolt, Carriage 3/8-16 x 1 Gr. 5...
  • Page 22 REPAIR PARTS TILLER - - MODEL NUMBER WET6500A MAINFRAME, LEFT SIDE PART DESCRIPTION 73510500 Nut, Keps 5/16-18 10040600 Washer, Lock 3/8 73220600 Nut, Hex 3/8-16 170127 Shield, Inner, Belt Guard 164329 Pin Spirol Flared 110111X Lever, Shift 72110404 Bolt, Carriage 1/4-20 x 1/2 Gr. 5...
  • Page 23 REPAIR PARTS TILLER - - MODEL NUMBER WET6500A MAINFRAME, RIGHT SIDE PART DESCRIPTION 102332X Bracket, Reinforcement 102173X Counter Weight, R.H. 10040600 Washer, Lock 3/8 73220600 Nut, Hex 3/8-16 74760524 Bolt, Hex 5/16-18 x 1-1/2 4497H Clip, Hair pin 126875X Rivet, Drilled...
  • Page 24 REPAIR PARTS TILLER - - MODEL NUMBER WET6500A TRANSMISSION transmission_1.95b PART DESCRIPTION 180677 Transmission Assembly (In cludes Key Nos. 2-53) 180627 Gearcase, L.H. w/Bearing (In cludes Key No. 4) 161963 Gasket, Gearcase 5020J Bearing, Needle 1370H Washer, Thrust 5/8 x 1.10 x 1/32...
  • Page 25 REPAIR PARTS TILLER - - MODEL NUMBER WET6500A TINE SHIELD tine_shield_13_in(sears) PART DESCRIPTION 73900500 Nut, Flange 5/16-18 161415X550 Shield, Side, Outer L. H. 8393J Pin, Stake, Depth 12000035 Ring, Klip 180847 Bolt, Carriage 5/16-18 x 3/4 8394J Spring 8392J Bracket, Latch...

  • Page 26: Tine Assembly

    REPAIR PARTS TILLER - - MODEL NUMBER WET6500A TINE ASSEMBLY PART DESCRIPTION 4459J Tine, Outer, L.H. 132673 Clevis Pin 6554J Tine, Inner, L.H. 3146R Clip, Hairpin 132727 Assembly, Hub and Plate, L.H. 73610600 Nut, Hex 3/8-24 10040600 Washer, Lock 3/8...
  • Page 27 REPAIR PARTS TILLER - - MODEL NUMBER WET6500A DECALS PART DESCRIPTION 162846 Decal, Logo 186761 Decal, Logo 143678 Decal, Instruction, Tilling 141907 Decal, Hand Placement 102180X Decal, Shift Indicator 141906 Decal, Warning, Rotating Tines 156199 Deal, Reverse 162215 Decal, Tine Shield Wrng Dom...

  • Page 28: Warranty

    The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from de- fects in materials and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we fi...
