Lucky Duck Rapid Flyer Drake Quick Start Manual

Thank you for your purchasing a Lucky Duck™ Premium Decoy. To see more Lucky Duck™ products please visit
your local Sporting Goods dealer or online at www.luckyduck.com.

Included in the box:

1) Rapid Flyer Lucky Duck body
2) 3pc mounting stake with T bracket
3) 6V rechargeable battery
4) 6V battery charger
5) (1) Set of Rapid Flyer Wings
6) (1) Set of feet with wing nuts
Set up of Rapid Flyer Lucky Duck™ is quite simple. The first thing you will want to do is charge your battery for
24 hours. The battery will have a small charge on it so you can test your duck function if you like before charging
the battery. Attach the Red alligator clip to the (+) battery terminal and Black to the (-) battery terminal
1) Locate the feet found inside the body cavity of the duck and the T shaped mounting bracket found
inserted in the top of one of the metal stake sections.
2) Remove the protective rubber covers from the threaded shafts that protrude from the legs.
3) Slide each of the feet over the threaded studs that come out of the legs on the duck body.
4) Slide the T-shaped mounting bracket over the studs as indicated in the Figure 1 below.
Lucky Duck Feet
Remove the elastic strap found directly behind the motor inside the decoy body and insert the 6V battery as
shown in Figure 2 below. Replace the elastic strap to secure the battery, hook up the Red wire (with fuse) to the
RED (Positive) battery terminal and the BLACK (Negative) battery terminal
BLACK (-) battery
Terminal (black wire)
!
Rapid Flyer Lucky Duck
Drake #71410-2 - Hen #20712-3 - Gadwall #20512-9
Figure 1
!
Figure 2
v13.1
T-shaped mounting
Bracket (shape may vary)
.
Elastic strap (or Wing nut in older
models)
RED (+) battery
Terminal (red wire)
