Radiance instruments TMW023-4P User Manual

Radiance Instruments Co. Ltd.
Flat 2002, 20/F, CEO Tower, 77 Wing Hong Street Lai Chi Kok, Kowloon, Hong Kong, China.
Phone: +852 2466-8608 Fax: +852 2466-1231

PRODUCT SPECIFICATION

Product number: TMW023-4P Product name: SMOKE X4 transmitter and receiver Versions: V1.0
Receiver and transmitter are two products that are used simultaneously,The receiver and transmitter use the same module,
and the module is a two-way transceiver.

Features:

4 Channels BBQ/Oven monitor.

LORA WAN connectivity

IP66 waterproof.

High/low alarm setting.

Min/max temperature reading

Loud alarm sound

Clear LCD display with backlight

External adapter and battery power

Fan control


Specification:

Measuring range
Temperature accuracy
Wireless distance
Display resolution
Alarm sound volume
Unit reading update
Receiver reading update
Water resistant rating
Power
Battery life
Display size
Probe
Product size
Working temperature
Attachment

Operation

1. Insert all the probes with the correct number. Connect the external power.
2. Press [ON-OFF] button to turn on the unit, the backlight will turn on 10 seconds.
3. Press [ON-OFF] button and hold for 3 seconds to turn off the unit.
4. Press [ON-OFF] button and hold for 10 seconds then release to reset the unit.
Select temperature unit
Press [C/F] button to select the temperature unit.
Low and high temperature alarm setting
1. Press [CH] button to select the channel for alarm setting. All the icons flashing that you selected.
2. Press [SET] button to enter alarm on-off setting. Press [▼] or [▲] button to set the alarm on or off.
3. Press [SET] button once again to enter high alarm limit setting mode, high alarm value will be flashing. Press [▼] or [▲] button to
set the high alarm limit.
4. Press [SET] button once again to enter low alarm limit setting mode, low alarm value will be flashing. Press [▼] or [▲] button to set
the low alarm limit.
5. Press [SET] button once again to finish the alarm setting.
6. If the temperature reading is out of the limited, the alarm will sound, the "LOW" or "HIGH" icon flash, press any key to stop the alarm
sound, the low alarm or high alarm icon will be flashing continue.
7. Alarm sound: the channel 1 alarm sound is "di - - -", the channel 2 alarm sound is "di di - -", the channel 3 alarm sound is "di di di -",
the channel 4 alarm sound is "di di di di ".
* If the both alarms sound active, the last alarm sound will be instead the before one.
* The default low alarm value is 32F, the default high alarm value is 160F,
Backlight control
1) Press [ ] button to switch backlight on or off. The backlight will be turn on 20 seconds, and then turn off automatically.
-58 ~ 572 F / -50 ~ 300C
±1.8F(± 1 C) between -4F to 248F（ -20 to 120C）
±3.6F(± 2 C) between -58F to -4F / 248 to 392F（-50 to -20 C /120 to 200C）
±5.4F (± 3 C) between 392~572F(200 to 300C)
About 2000 meters in open areas
Current temperature 0.1,min/max and alarm limit set 1
About 90dB (300mm distance)
1 second
30 seconds
IP66
2 pieces AA alkaline batteries, external adapter power input
Transmitter about 125 hours, receiver about 1800 hours
Transmitter 59(W) X 78 (H) mm, receiver 35(W) X 59 (H) mm,
Curved probe: 3.5() x 150(L) mm, tip 2.2() x 10(L) mm, cable length 1200mm.
Straight probe: 3.5() x 51(L) mm, cable length 1200mm.
Transmitter 90 (W) x 119(H) X 28(D)mm , receiver 52 (W) x 113(H) X 28(D)mm
Main part 32 ~ 122 F/0 ~ 50 C, cable 700F/371C, probe handle 644F/340C
3 pieces curved probes, 1 piece straight probe, 1 piece air clip.
