Opitec 111.161 Manual

M a g i c P i c t u r e F r a m e
COOL. UITGEVERIJ PELCKMANS.
PARTS LIST
Wood strip
Wood strip
Plywood sheet
Acrylic sheet
Acrylic rod
Acrylic tube
LED -super bright
Battery clip 9V
Reed contact
Magnet
Cable
E111161#1
111.161
Quantity SIZE (mm)
1 150x10x5
2 250x20x10
1 200x55x4 or 200x55x5
1 100x150x2
1 245xø4
1 245xø10/6
2 ø5
1 100mm
1 0,6x2,5x20
1 24x13,5 or Ø15x6
1 500
Please Note
The OPITEC range of projects is not in-
tended as play toys for young children.
They are teaching aids for young people
learning the skills of Craft, Design and
Technolo- gy.These projects should only
be undertaken and tested with the
guidance of a fully qualified adult. The fi-
nished projects are not suitable to give
to children under 3 years old. Some
parts can be swallowed. Dan- ger of suf-
focation!
Necessary tools:
File and glasspaper
Drills 4&10mm diameter
Fretsaw
Wood glue
Soldering iron
Drawing pins
Description Part no.
Frame 1
Frame 2
Cover 3
Picture holder 4
Picture holder 5
Light tube 6
Light 7
Connection 8
Switch 9
Switch 10
Connection 11
