AIT WPS 61 Operating Manual

AIT WPS 61 Operating Manual

Series buffer tanks stratified storage tanks

Advertisement

Accessories for
heat pumps
Operating Manual
Series buffer tanks
Stratified storage tanks
UK
83018300lUK – Translation of the original operating manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WPS 61 and is the answer not in the manual?

Questions and answers

Summary of Contents for AIT WPS 61

  • Page 1 Accessories for heat pumps Operating Manual Series buffer tanks Stratified storage tanks 83018300lUK – Translation of the original operating manual...
  • Page 2: Please Read First

    Adhere to the given sequence. ► Single-step instruction for action ● List  Reference to further information elsewhere in the operating manual or in another document. Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 3: Table Of Contents

    ......8 ......23 11 Insulation of the connections and the storage tank ............ 8 12 Draining the storage tank ......8 Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 4: Intended Use

    The operation of the product via the heating and he- at pump control and work on the product which is in- tended for end customers / operators is suitable for all Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 5: Warranty / Guarantee

     For information on which electrical heating ele- ment is suitable for the storage tank: "Technical Data“, from page 9, for the respective model Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 6: Transport, Installation, Assembly

    ► Take suitable precautions, which prevent the tipping hazard. ► Dispose of the transport and packaging materials properly and under ecological aspects. Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 7  For position of the connections: "Dimension- al drawings“, from page 11, for the respective Seal the butt joint with additional insulating tape. model Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 8: Installation Of The Sensor For The Heating And Heat Pump Regulator

     For positioning: "Dimensional drawings“, from page 11, for respective model Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 9: Technical Data

    — ı • • ı — — ı • Sheet metal jacket ı Foil jacket • yes — no 813557d Manufacturer: ait deutschland GmbH Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 10: Tpsk 500 - Tpsk 1500

    — ı • — ı • — ı • Sheet metal jacket ı Foil jacket • yes — no 813557d Manufacturer: ait deutschland GmbH Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 11: Dimensional Drawings

    Rp 1/2" IG Net weight 24 kg ÄM 007/2014 ÄM 007/2014 26.3.2014 D D 26.3.2014 Nominal volume 82 litres 16.11.2012 Zust. Änderungstext Datum Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 12: Wtpsk 100

    Ø i 10 mm Return from heating Rp 1" Return to heat pump Rp 1" Net weight 41 kg Nominal volume 100 litres Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 13: Ups 140

    Heating water inlet R 1 1/ 4 " AG Bushing for sensor electric heating element R 1 1/2" IG Net weight 75 kg Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 14: Tps 200

    Anschluss für Entleerungshahn R 3/4" AG Tilting dimension storage tank 1440 Muffe für Entlüftungs- und Sicherheitsventil R 1" IG Tauchrohr für Fühler Øi = 8mm Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 15: Tpsk 200

    Anschluss für Entleerungshahn R 3/4" AG Tilting dimension storage tank 1440 Muffe für Entlüftungs- und Sicherheitsventil R 1" IG Tauchrohr für Fühler Øi = 8mm Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 16: Tps 500.1

    Bushing for sensor sensor pocket R 1/2" IG Nominal volume Net weight Tilting dimension storage tank 485 litres 111 kg 2080 ÄM 053/2014 Zust. Änderungstext Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 17: Tpsk 500

    Ø i 8 mm    Net weight 120 kg    Tilting dimension storage tank 2050     Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 18: Tps 750, Tps 1000

    L: 880 | W: 750 | H: 2000 TPS 1000 140 kg 2050 L: 980 | W: 850 | H: 2015 TPS 750 1155 1645 1250 1450 1555 2000 Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 19: Tpsk 1000

    D - 95359 K Tilting dimension storage tank (without insulation) 2050 3.7.2017 www.ait-deuts Zust. Änderungstext Datum Moving dimensions L: 980 | W: 850 | H: 2015 Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 20: Tps 1500

    R 1ʺ AG Net weight 255 kg Tilting dimension storage tank (without insulation) 2420 Moving dimensions L: 1100 | B: 1100 | H: 2400 Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 21: Tpsk 1500

    03.07.17 Knoll Tilting dimension storage tank (without insulation) 2420 www.ait-de Zust. Änderungstext Datum Moving dimensions L: 1100 | B: 1100 | H: 2400 Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 22: Installation Plans

    All dimensions in mm. Pos. Name Plan view Minimum area to ensure ability to operate and service Storage tank >1000 Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH Legende: DE819397 Alle Maße in mm.
  • Page 23: Ec Declaration Of Conformity

    Company: Place, date: Kasendorf, 21.07.2020 ait-deutschland GmbH Industrie Str. 3 93359 Kasendorf Germany Signature: Jesper Stannow UK818177d Coordinator of pre-development projects and standards Subject to change without notice | 83018300lUK – Translation of the original operating manual | ait-deutschland GmbH...
