Summary of Contents for Spartus 101X
- Page 1 WELDING HELMET 101X 201X 301X 401X User’s manual...
- Page 2 Therefore, our offer covers such a wide assortment of products. Thank you very much for your trust in our company. We would like to invite you to familiarize yourself with the remaining products and offer at www.spartus. info or directly at a local distributor of SPARTUS® products.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. SAFE USE ..................................2 1.1 Welding arc radiation can be dangerous ......................... 2 1.2 Symbols used in instructions ..............................3 2. CONFORMITY WITH STANDARDS ......................3 3. GENERAL DESCRIPTION ..........................3 3.1 Purpose of use ..................................... 4 4. -
Page 4: Safe Use
zapewnieniu odpowiednich środków ochronnych, spawanie elektryczne i cięcie plazmowe to procesy stosunkowo bezpieczne. Z uwagi na to, kluczowe podczas przeprowadzania prac spawalniczych jest bezwzględne stosowanie się do panujących zasad BHP. Poniższe informacje, nie zwalniają operatora z obowiązku przestrzegania zasad BHP obowiązujących w zakładzie USER’S MANUAL Przy wykonywaniu prac spawalniczych, należy stosować... -
Page 5: Symbols Used In Instructions
CE marking was placed on the product. 3. GENERAL DESCRIPTION SPARTUS® helmet has been designed to protect welder’s eyes and face against the harmful radiation and weld spatters during welding: TIG, MIG/MAG, MMA. Additionally device has a function of grinding. -
Page 6: Purpose Of Use
USER’S MANUAL 3.1 PURPOSE OF USE Automatic welding helmets SPARTUS® are designed to protect the face and eyes of the welder, against sparks and welding spatter and against harmful radiation which arises under normal conditions when: • GMAW gas metal arc welding (MIG/MAG) •... -
Page 7: Used Markings
Headgear adjustable Weight [g] Adjustment knob and switch outside inside 4.3 USED MARKINGS 4.3.1 Welding filter SPARTUS® Easy 101X Marking: 4/9-13 ART 1/1/1/2 EN 379 Light shade The lightest shade The darkest shade Identification Optical class Diffusion of light class... -
Page 8: Operation And Use
Mechanical resistance: medium Energy impact 5. OPERATION AND USE WARNING! SPARTUS® welding helmet is intended for professional and industrial applications. Installation and use of the device may only be carried out appropriately trained professionals. Qualified person (def.) A person who has gained the relevant technical education, training took place and / or gained... -
Page 9: Description Of Construction
USER’S MANUAL 5.1 DESCRIPTION OF CONSTRUCTION WARNING! It is forbidden to make any unauthorized modifications to the welding filter and / or other components of a SPARTUS® welding helmet. 5.1.1 Automatic welding filter SPARTUS® Easy 101X SPARTUS® Master 201X SPARTUS® Pro 301X / Pro 401X... - Page 10 USER’S MANUAL 5.1.2 Welding helmet SPARTUS® Welding helmet shell Outer polycarbonate filter shield Screw nuts (headgear) 5.1.3 Headband of SPARTUS® helmet Sweatband (cloth) Left band & right band Headband top pad Angle adjusting shim (left/right) Front headband Headband fixing screw (left/right)
- Page 11 USER’S MANUAL...
-
Page 12: Using Of Welding Helmet
To select and adjust shade number you should use the knob 2 . The user can choose between values DIN 4 to DIN 8 or DIN 9 to DIN 13, depending on the selected knob 1 position : – for Easy 101X model a) 9 – 13 –... -
Page 13: Maintenance
Incline angle adjustment can be made by using angle adjusting shim 17 in to both sides. 5.2.7 Turning on the grind mode SPARTUS® helmets have a grinding function. To enable the grinding function, set the switch 1 into GRIND position. The degree of protection for the grinding function is DIN 4. -
Page 14: Replacing The Filters Covers
USER’S MANUAL 6.1 REPLACING THE FILTERS COVERS Regular replacement of the filter welding shield is needed to do the correct operation of the helmet. Excessively worn or damaged filter covers must be replaced by a new one. 6.1.1 Replacing outer filter cover Step 1: Carefully remove the filter cartridge. - Page 15 USER’S MANUAL A Helmet shell B Auto darkening filter C Complete headband D Headband knob E Front cover lens F Inside cover lens...
-
Page 16: Environmental Protection
Problems with the operation of the device, are not always an evidence of its failure. You can independently carry out an analysis in search of probable failure. In case of doubt, please contact to SPARTUS® dealer or authorized service center. - Page 17 Notes...
- Page 18 Notes...
- Page 19 A masterly combination of high quality production, excellent parameters and ergonomics – these are fea- tures of the SPARTUS® Master series of devices, which were created with demanding welding jobs in mind. Precision, functionality, excellent parameters and resistance to high workloads –...
- Page 20 Videopresentation of products Subscribe to the channel SPARTUS.INFO...
