ABS-Lock® X-Flat
LX-FLAT-XXX
1
LX-FLAT-250
2
LX-FLAT-333
STAHL
STEEL
5,5 mm
180 mm
250 mm
280 mm
333 mm
3
min. 10
mm
min. 0,45
mm
14
x
BLINDNIETE
BLIND RIVET
5,2 x 19,1 mm
