Design Features:
1. PFC function.
– except C-15L-12 / C-7L-24.
2. Sleeping mode function.
3. Wide input voltage (universal)
range operation.
– except C-15L-12 / C-7L-24.
4. LCD remote control.
5. Battery temperature sensor
function.
6. Tri-LED color indicator for
different charge stage.
7. With power supply function.
8. Prevent the battery
overcharging, and extend
the battery life.
9. For recovery of the aging
(sulfated) battery.
10. Suitable for lead acid and
Lithium batteries.
ISO: TS16949
Us er M a nu al

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C-15L-12 and is the answer not in the manual?

Questions and answers

Summary of Contents for portable power tech C-15L-12

  • Page 1 Us er M a nu al Design Features: 1. PFC function. – except C-15L-12 / C-7L-24. 2. Sleeping mode function. C-15L-12 / C-7L-24 3. Wide input voltage (universal) range operation. – except C-15L-12 / C-7L-24. 4. LCD remote control. 5. Battery temperature sensor function.

  • Page 2: Table Of Contents

    A. Product Introduction B. Accessory C . Isolated Design Installation Illustration Charging mode Selection & Volt Graph Charger LCD Remote Control C-15L-12 / C-7L-24 specification C-30-12 / C-15-24 specification C-60-12 / C-30-24 specification C-90-12 / C-45-24 specification Charging Formula Charger troubleshooting guide...

  • Page 3: Important Safety Instructions

    1. Important Safety Instructions Before installing and using the charger, read all instructions and cautionary markings on the charger, the batteries, and all appropriate sections of this guide. General Safety Precaution: A. Do not expose the charger to rain, snow, spray, or bilge water. To reduce risk of fire hazard, do not cover or obstruct the ventilation openings.

  • Page 4: Installation Location

    2. Installation Location: Physical requirements for installation IMPORTANT This product is best mounted in a Horizontal position. If the unit is mounted in a vertical position, The cooling fan must be at the bottom of the unit. Condition Description Do not expose the charger to metal filings or any other form of conductive contamination.

  • Page 5: Overview

    Warning: Damage caused by wrong positive (+) and negative (-) connection is not covered by the warranty. Warning: DO NOT charge the frozen battery, may result in the serious injury or death. C-15L-12 ; C-7L-24 Front view Rear view C-30-12 ; C-15-24...
  • Page 6 C-60-12 ; C-30-24 Front view Rear view C-90-12 ; C-45-24 Front view Rear view - 6 -...
  • Page 7 DC OUTPUT : +Red / -Black Charging Mode Selection (Please refer to page 13 ) Second DC output Charging Status Remote control-LCD Sleeping / Normal Mode Fault Slave Switch ( Note 1 ) Sleeping Mode Normal Mode Mode ON / OFF ( Note 3 / Note 4 ) Remote control-LCD Battery Temp.
  • Page 8 When the battery (-) pole temp. reaches 65°C (+/-5°C) / 149°F (+/-41°F), the charger would stop output. DON'T connect the sensor to the battery Positive (+) terminal. It may damage the sensor & charger. Warning: Damage caused by wrong sensor cable connection is not covered by the warranty.

  • Page 9: Accessory

    B. Accessory bracket - 2 parts : rear and frame. How to instal? FRONT VIEW Rear Frame ① With the frame only, if there’s the hole on the wall for phone jack.  ② With the frame and rear both, if the user just can screw the bracket on the wall, no hole for phone jack.

  • Page 10: Isolated Design

    AC power circuits. This feature reduces the risk of electric shock . 4. Installation Illustration Before charging, read the instructions; for indoor use only. Disconnect the supply before making or breaking the connections to the battery. C-15L-12 ; C-7L-24 DC Output Mode Sleeping Normal...
  • Page 11 C-60-12 ; C-30-24 Main battery t t e DC Output Second DC output red (positive) Mode Sleeping Normal black (negative) Mode Selection Remote Battery Temp. Charger Control Sensor State t t e red (positive) 2nd battery ( Note 6 ) black (negative) DC Negative Bus...
  • Page 12 WARNING Explosive gases; Prevent flames and sparks; Provide adequate ventilation during charging. Include a warning against recharging non-rechargeable batteries. If the supply cord is damaged, it must be replaced by a special cord or assembly available from the manufacturer or its service agent. Explosive gas precautions (1).

  • Page 13: Charging Mode Selection & Volt Graph

    5. Charging mode Selection & Volt Graph (0:OFF Mode 1 Suitable for re-charging lead storage (100) battery including AGM. 1 2 3 standby Mode 2 orange orange green Suitable for re-charging gel battery. (120) LED color 1 2 3 Suitable for re-charging lead storage battery, which is in good condition battery (no any sulfated situation),and completely disconnected from the devices it runs.

  • Page 14: Charger Lcd Remote Control

    6. Charger LCD Remote Control : Graph Fault LED (red lighting) Fault Battery ON/OFF Capacity SWITCH charging mode charging current ON / OFF Display Content : Fault Fault Mode Mode ON / OFF ON / OFF 1. OFF 2. Mode 1: no battery connected. / the battery is broken.

  • Page 15: C-15L-12 / C-7L-24 Specification

    C-15L-12 / C-7L-24 specification M o d e l C-15L-12 C-7L-24 INPUT Voltage range 120Vac (100~130Vac) / 230Vac (180~240Vac). Frequency range 50/60Hz Efficiency >=85% Power factor 0.5 at full load (±5％) Input socket IEC plug OUTPUT Mode Selection Mode 1...

  • Page 16: C-30-12 / C-15-24 Specification

    C-30-12 / C-15-24 specification C-15-24 C-30-12 M o d e l INPUT Voltage range 100 ~ 240VAC Frequency range 50/60Hz Efficiency >=85% Power factor 1.0 at full load (+/-5%) Input socket IEC plug OUTPUT Mode Selection Mode 1 Mode 2 Mode 3 Mode 4 Mode 5...

  • Page 17: C-60-12 / C-30-24 Specification

    C-60-12 / C-30-24 specification Model C-60-12 C-30-24 INPUT 100 ~ 240VAC Voltage range Frequency range 50/60Hz Efficiency >=85% Power factor 1.0 at full load (+/-5%) Input socket IEC plug OUTPUT Mode Selection Mode 1 Mode 2 Mode 3 Mode 4 Mode 5 Mode 6 Mode 7...

  • Page 18: C-90-12 / C-45-24 Specification

    C-90-12 / C-45-24 specification Model C-90-12 C-45-24 INPUT 100 ~ 240VAC Voltage range Frequency range 50/60Hz Efficiency >=85% Power factor 1.0 at full load (+/-5%) Input socket IEC plug OUTPUT Mode Selection Mode 1 Mode 2 Mode 3 Mode 4 Mode 5 Mode 6 Mode 7...

  • Page 19: Charging Formula

    Typical charging efficiency forlead-acid batteries Example A Group size battery rated at 100 amp-hours is 40% discharged, that is, it has a DOD = 40. Charging time with a C-15L-12 unit is calculated as follows: 100Ah x 40% Charging time = = 3.3 hours...

  • Page 20: Charger Troubleshooting Guide

    8.Charger troubleshooting guide Problem Possible cause Solution AC input volt is not Ensure AC input volt is at charger AC volt acceptable correct range. AC input frequecny isn't Ensure AC frequency is at charger AC frequency correct acceptable range. No AC input Poor connection Check and improve the AC wiring connection.
