- Page 1 EVK-GT8230 User Manual Version: V2.0.0 Date: 2013-09-13...
- Page 2 Copyright ©2013 Fibocom Wireless Inc. All rights reserved. Trademarks Notice The FIBOCOM Logo is registered by Fibocom Wireless Inc. All other product or service names or logos are the property of their respective owners. Copyright ©2013 Fibocom Wireless Inc. All rights reserved.
- Page 3 Applicability Table Type Note H330 Concert with ADP-H330-xxx-yy H350 Concert with ADP-H350-xxx-yy EVK-GT8230 User Manual Page 3 of 22...
-
Page 4: Table Of Contents
2.10 Default Jumper Switch........................18 3 Adapter Introduction............................... 19 3.1 Adapter Overview..........................19 3.2 Adapter Appearance........................... 19 3.3 Adapter Structure..........................20 3.4 Adapter Operation..........................21 3.4.1 Work with GT8230........................21 3.4.2 Only Adapter..........................21 3.5 Adapter Installation..........................22 EVK-GT8230 User Manual Page 4 of 22... -
Page 5: Preface
1 Preface 1.1 Scope EVK-GT8230 is the developer board of Fibocom 3G module, it worked with corresponding adapter. This Manual describes the developer board EVK-GT8230, ensures the users can quickly and conveniently develop wireless communications using Fibocom Module. 1.2 Developer Board Structure... -
Page 6: Application Diagram
GT8230 mainly includes the four parts:each functional interface, button, test point and power supply. The diagram as listed below: Figure 1-2 product diagram Note ：the Reset button is only for Mini PCIe, for Adapter is useless. EVK-GT8230 User Manual Page 6 of 22... -
Page 7: Function Description Of Evb
Direct Power Supply: The power supply is connected directly to the module, so the voltage range must comply with the H330 Specifications. Power Connector Description DC Power Supply V40BAT(JP3) Voltage Range: 3.3 V ~ 4.2 V GND(JP2) Recommended Voltage: 4.0V Input Current: > 2.0A EVK-GT8230 User Manual Page 7 of 22... -
Page 8: Power Adaptor
Jumper on Pin 3: VDD33 connected with VSPK: power supplied by VDD33 Note: When you test the parameter of current, please unplug the above six jumpers. The tested current will be the current consumed by module only. EVK-GT8230 User Manual Page 8 of 22... -
Page 9: Uart1（Com
Developer board contains RS-232 Transceiver SP3238EEA inside. PC and other DTE equipment can test all the functions of the module through this interface and AT Commands. The following picture shows the connection of UART1: EVK-GT8230 User Manual Page 9 of 22... -
Page 10: Uart1（Usb
PC. If it is connected successfully, the light will on. The following picture shows the connection of USB (UART1):USB Jumper Switch Description Turn on/off USB interface as communication interface EVK-GT8230 User Manual Page 10 of 22... -
Page 11: Usb Interface
PC through switching cable (USB transfer to mini USB). If it is connected successfully, the light will on. The following picture shows the connection of High Speed USB: Jumper Switch Description for connecting to USB_ID Note：Install corresponding driver（driver for H330 module）when use USB interface. EVK-GT8230 User Manual Page 11 of 22... -
Page 12: Uart2（Com
JP7, otherwise, this port cannot be used. 2.6 SIM Card Interface Developer board includes a complete SIM card socket and interface circuit. The following picture shows the diagram: Figure 2-6 SIM Card Circuit EVK-GT8230 User Manual Page 12 of 22... -
Page 13: Audio Interface
The handle socket JA1 on the developer board is the first channel audio interface. Jumper Switch Description JA6(5-6pin) On/off，connect to MIC+ of the headset On/off，connect to MIC- of the headset JA6(7-8pin) JA6(9-10pin) On/off, connect to EAR- of the headset EVK-GT8230 User Manual Page 13 of 22... -
Page 14: Audio2
The speaker interface and handle socket are connected to the same audio interface of the module, therefore,these two interfaces cannot be used simultaneously. Jumper Switch Description JA8(1-2pin) On/off, connect to AUXO- of the speaker EVK-GT8230 User Manual Page 14 of 22... -
Page 15: Reset Button
Figure 2-10 Jumpers Locations 2.8 RESET Button The developer board has a RESET button. The following picture shows the diagram: Figure 2-11 RESET Circuit Jumper Switch Description JM14 Enable/disable，RESET switch Figure 2-12 Jumpers Locations EVK-GT8230 User Manual Page 15 of 22... -
Page 16: Test Point
Test PIN pin 1：VRTC_1V8 pin 2：VBACKC VRTC & ADC pin 3：ADC2 pin 4：ADC1 pin1：CLKOUT0 pin2：CLK32K pin3：USIF1_SCLK CLOCK & EINT pin4：T_OUT0 pin5：EINT2 pin6：GND pin7：EINT1 pin1：MMC_DAT3 pin2：MMC_DAT0 pin3：MMC_CD JM10 pin4：MMC_DAT1 pin5：MMC_CLK pin6：MMC_DAT2 pin7：MMC_CMD pin1：I2C_SCL pin3：I2C_SDA EVK-GT8230 User Manual Page 16 of 22... - Page 17 1：1V8 pin 2：NC pin 3：MIPI_RX_DATA / SPI MISO pin 4：MIPI_RX_FLG / SPI MOSI pin5：MIPI_RX_RDY / SPI Clock pin6：MIPI_RX_WAKE MIPI pin7：MIPI_TX_DATA / SPI_MRDY pin8：MIPI_TX_FLG / SPI_SRDY pin9：MIPI_TX_RDY pin10：MIPI_TX_WAKE pin11：GPIO_049 pin12：GND Other pin 1：I2SCLK1 EVK-GT8230 User Manual Page 17 of 22...
-
Page 18: Default Jumper Switch
4V switch to 3.3V connection Module output 1.8V to indicator JP7 (pin2-pin3) Supply 1.8V connection from power UART2 connection Power supply for LED indicator UART1 connection Audio connection JM11 (pin2-pin3) Power supply for CODEC inside the EVK-GT8230 User Manual Page 18 of 22... -
Page 19: Adapter Introduction
The adapter is used to connect module and developer board together, here take H330 Adapter (ADP-H330) as an example. 3.2 Adapter Appearance The following figure shows ADP-H330. Figure 3-1 ADP-H330 Top View Figure 3-2 ADP-H330 Bottom View EVK-GT8230 User Manual Page 19 of 22... -
Page 20: Adapter Structure
On button, power on the module Button Off button, power off the module Button Reset button, reset the module (standard module is power off after reset) Test point JTAG test point, used for Debug EVK-GT8230 User Manual Page 20 of 22... -
Page 21: Adapter Operation
2. If you want to use USB to supply the power, please connect the jumpers in 3 and 4. Note: The load capacity of USB port must be 5V, 700mA or above, otherwise the module maybe abnormal. EVK-GT8230 User Manual Page 21 of 22... -
Page 22: Adapter Installation
