Patriot Lighting SOLAR SHED LIGHT User Manual

THIS PRODUCT IS DESIGNED TO THE HIGHEST TECHNICAL SPECIFICATIONS AND STANDARDS. IT WILL SUPPLY YEARS OF MAINTENANCE-
FREE USE. PLEASE READ THESE INSTRUCTIONS THOROUGHLY PRIOR TO INSTALLATION.
KEEP THESE INSTRUCTIONS SAFE FOR FUTURE REFERENCE.
IMPORTANT INFORMATION
• Avoid exposing the LED shed light to weather hazards including rain. The solar panel is weatherproof.
• If using a step ladder, have a second person help install the solar panel and/or shed light.
• Prior to installation, make sure all the components mentioned in the part list section (below) are present.
• Never look directly into the shed light when illuminated.
Front View
A
1
Back View
4
166mm
~ 6.5 in
Electric Power Drill
INSTALLATION
The solar panel (B) is fully weatherproofed and can be installed outside. Maximize sun exposure by orientating the panel towards the sun. This procedure
will optimize charging of the light's internal battery pack. Be aware of overhanging trees or obstacles that can affect sun exposure on the panel.
The LED shed light (A) is an interior light and should only be installed in a dry area away from the effects of the weather.
SOLAR SHED LIGHT
USER MANUAL
2
2
3
4
TOOLS REQUIRED
Phillips
Screwdriver Pencil
B
A
PARTS LIST
B
C
1
D
AA
(not included)
Ladder
A - 5 LED Shed Light (x1)
1. Socket for solar panel plug
2. 5 Super bright LEDs
3. ON/OFF Switch
4. Key-hole mounting slots
B - Solar Panel (x1)
1. Mounting bracket
2. 8ft. wire
C - Mounting Screws (x5)
D - AA Battery Pack (x1)
Eye Protection
Part #:
343-2460
Level
B
A
Page 1
