Bright Spark BS110 User Instructions

Portable Gas Cooker
USER INSTRUCTIONS
Gas cartridge locking lever -
push down to lock in gas cartridge
Type: Portable gas cooker
Power: 2.2kw
Fuel consumption: 0.15kg/hr
0359 359/BR/691
IMPORTANT: Please read these instructions for use carefully to
familiarise yourself with the appliance before connecting unit to gas
cartridge. Please keep these instructions for future reference.
Use only in well ventilated area away from flammable
materials. Use in accordance with national requirements, for the
supply of combustion air to avoid the dangerous build up of unburnt
gases, for appliances not fitted with a flame supervision device.
NOTE: This appliance should only be used with Butane Battery® gas
cartridge A4. It may be hazardous to attempt to fit or use other types
of gas cartridge.
S FETY PREC UTIONS
• Check that seals between appliance and gas container are in place
and in good condition before engaging gas cartridge.
• Check alignment of gas cartridge collar notch with locating safety
tab.
Gas cartridge
locator tab
A
• Change gas containers in a well ventilated location, preferably
outside, away from any source of ignition, such as naked flames,
pilot lights, electric fires and away from other people.
• Do not use the appliance if seals are damaged or worn.
• Do not use an appliance which is leaking, damaged or does not
operate properly. If there is a leak on your appliance (smell of gas),
take it outside immediately into a well ventilated flame free location
where the the leak may be detected and stopped. If you wish to
check for leaks on your appliance, do so outside. To detect leaks
use soapy water never a flame.
• Do not use this appliance for purposes other than cooking.
• Use only on a flat horizontal surface protected from wind.
GB
BS110
Gas cartridge housing
Lift cover to open
Model: BS110
Gas type: Butane (LPG)
'
0' ring seals in nozzle housing
Butane Battery
A4
B
• Use only in a well ventilated area.
• Do not use the cooker under shelves
and place at least 20cm
away from walls and 100cm below
ceilings.
Keep away from flammable materials.

INSTRUCTIONS FOR USE

CAUTION: During use some accessible parts of this cooker will
become very hot. Keep young children away from the appliance.
• Remove cooker from storage case and place on a flat, stable
surface.
• Lift open gas cartridge housing, using the finger hole.
• Check that gas seals are in position and in good condition. Insert
the gas cartridge, carefully aligning the locator tab (see diagrams
A and B). Push the gas cartridge locking lever down. Close cover.
• Ignite burner by turning the heat control knob counter clockwise to
the spark position indicated by the star
apply pressure until igniter clicks. Repeat this action until burner
ignites. Maintain the pressure and position of dial for 5 - 10
seconds. Adjust knob for temperature.
• After use, extinguish the flame by rotating control knob clockwise
to the upright/off position and disengage gas cartridge by sliding
the locking lever up to the top of the slide. Allow unit to cool and
remove the gas cartridge before cleaning and storage.
• Clean with soapy water, no abrasives. Do not immerse the unit.
• Do not move cooker while in use.
• Be sure cooker is cool and dry before storing.
• Be aware of the the phenomenon of flaring which may occur
during the 2-3 minute warm up period.
Do NOT over-ride safety precautions. If gas carton ejects leave for
at least five minutes and establish cause of ejection before trying
again.
INTEGR TED S FETY FE TURES
• Automatic pressure-sensitive flame extinction system.
• Gas cartridge safety alignment mechanism.
• Integrated gas leak prevention safety control.
• Safety sequencing electronic ignition.
• GB, AT, BE, CH, DE, DK, ES, FI, GR, IE, IS,
IT, LU, NL, NO, PT, SE.
Do not modify this appliance. No user serviceable parts. For repairs
please contact service centre:
JFA Limited, Mill Lane, Taplow, Maidenhead, Berkshire,
England SL6 0AA UK.
®
Tel: +44 (0)1628 637111 Fax: +44 (0)1628 773030
enquiries@jfaexport.com
www.brightspark.eu
We reserve the right to improve and/or modify this appliance without
prior notice.
®
Bright Spark is the registered trade mark of JFA Ltd
>
100cm
>
20cm
. Continue to rotate and
