Incra CLEANSWEEP Owner's Manual

Downdraft dust collection cabinet

LEAN

WEEP

Downdraft Dust Collection Cabinet

SAFETY:

Important safety instructions for using the INCRA CleanSweep

Before using the INCRA CleanSweep, read and follow all instructions and safety information in this manual.

Before using the INCRA CleanSweep in conjunction with any other tool, first read and follow all instructions and safety

information in that tool's owner's manual.

When making any cut, always use a push stick, rubber soled push block, or other safety device to keep your hands safely away

from the cutting tool.

Always wear safety glasses, hearing protection and follow all normal shop safety practices.

AVOID OVERHEATING YOUR ROUTER BY PROVIDING ADEQUATE VENTILATION. Make sure your dust col-

lection system is turned on, working properly, and connected to the CleanSweep Cabinet with the blast gate fully open whenever

your router is operated inside. If you operate your router inside the CleanSweep Cabinet with your dust collector turned off or

not working properly, you MUST first follow the 3 steps below.

Open the CleanSweep door

Open the Blast Gate slide

Remove the dust collection hose

Manufactured by Taylor Design Group, Inc. P.O. Box 810262 Dallas, TX 75381

w w w . i n c r a . c o m

Downdraft Dust Collection Cabinet

INCRA CleanSweep

Owner's Manual

Table of Contents

Do you have a question about the CLEANSWEEP and is the answer not in the manual?

Page 1 CleanSweep Cabinet with the blast gate fully open whenever your router is operated inside. If you operate your router inside the CleanSweep Cabinet with your dust collector turned off or not working properly, you MUST first follow the 3 steps below.
Page 2 Hdwr. Pack E-08 as shown in Fig. 1. 2. Insert the Blast Gate Slide through the slotted hole at the end of the CleanSweep assembly and attach the plastic stop gasket using 2 each of the 10-32 x 5/8” Phillips machine screws with thin washers, lock washers and hex nuts as shown in Fig.
Page 3 CleanSweep OPENING AND CLOSING THE CLEANSWEEP FRONT DOOR IMPORTANT: Always power off your dust collector before opening the CleanSweep’s front door. To open the CleanSweep’s sliding door, raise the door To close the CleanSweep’s door, simply raise the door up up as you pull the knob outward, then allow the door to to the top position as you push the knob gently inward.
Page 4 If you plan to also use your router table router as a hand held router from time to time, you might want to insert a short extension cord into the strain relief bushing with the female plug just inside the CleanSweep Cabinet.
