Summary of Contents for luxvision DM 2000
- Page 1 LENS USER’S MANUAL DRILLING MACHINE DM 2000...
- Page 2 Notification Dear Users, Thank you for your purchase of DM 2000 Lens Drilling Machine . Please take time to read our user’s manual carefully before use. This guarantees you to make full use of this unit and prolongs the operation life of this unit.
- Page 3 Content Function Introduction ..................4 Name of Parts ....................4 Function ......................5 Specifications ....................6...
- Page 4 1. Function Introduction This machine is made mainly by aluminum alloy and convenient to use. It’s main feature is overcoming the disadvantage that common drill machines can not drill diagonally. After fixing the lens, adjust the lens holder to drill and mill accurately. It’s precision is much better than common drill machine.
- Page 5 3. Function It uses dual-purpose motor driving Drill Bit directly, which turning is controlled by switch. The machine can drill straight hole, right and left diagonal hole. If drill straight hole, replace the second hand of sawyer to the center 0.5. If drill diagonal hole, make the second hand to an angle and fix the Lens Angles Site Screw.
- Page 6 4. Specifications Electric 220-240V, voltage 10-120V Power 30 W Frequency 50/60 Hz Rotate speed 18000 Min The drill left maximum angle 20° Drill swing right maximum angle 20° Shift machine´s adjustable range 15 m front and back Shift machine´s adjustable range 20 m front and back...
- Page 7 LUXVISION, Inc. shall not be liable for any errors or for incidental or consequential damages in connection with the furnishing, performance, or use of this manual or the examples...
