Tool Shop 240-1575 Owner's Manual

Universal tool table

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Work station tabletop size:

MDF lower shelf

Working height

Max. weight capacity

Need Assistance?

Call us on our toll free customer support line:

1-866-349-8665

Technical questions

Replacement parts

Parts missing from package

UNIVERSAL TOOL TABLE

PRODUCT SPECIFICATIONS

14" x 25"

18" x 27"

32"

500 lb.

240-1575

Owner's Manual

Table of Contents

Need help?

Do you have a question about the 240-1575 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tool Shop 240-1575

Page 1: Product Specifications
UNIVERSAL TOOL TABLE 240-1575 Owner’s Manual PRODUCT SPECIFICATIONS Work station tabletop size: 14” x 25” MDF lower shelf 18” x 27” Working height 32” Max. weight capacity 500 lb. Need Assistance? Call us on our toll free customer support line:...
Page 2: Table Of Contents
TABLE OF CONTENTS Product Product specifications……………………………..………………... ……………..... 1 Table of contents…………………………………………..……………..…..…....Safety instructions………………………………………..……………..…………...…. . 3 Safety symbols…………...………………………………..……………..…………….. . Description………………………………………………..……………..…...…………. . Assembly…………………………………………………..……………..……………… Operation………………………………………………..……………..………………… 9-11 Maintenance…………………………………………..……………..…………………….. 12 Exploded view………………………………………..……………..…………………….13 Parts list………………………………………………..……………..…………………….14 Warranty……………………………………………..……………..………………………..15...
Page 3: Safety Instructions
SAFETY INSTRUCTIONS GENERAL SAFETY RULES WARNING: Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. READ AND SAVE THESE INSTRUCTIONS WARNING: Do not modify this tool and/or use it for any application other than that for which it was designed.
Page 4: Safety Symbols
SAFETY SYMBOLS WARNING: Be sure to read and understand all safety instructions in this Operator’s Manual, including all safety alert symbols such as “DANGER”, “WARNING”, and “CAUTION” before using this tool. Failure to following all instructions listed below may result in electric shock, fire, and/or serious personal injury.
Page 5 SAFETY SYMBOLS SAVE THESE INSTRUCTIONS Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and more safely. SYMBOL NAME DESIGNATION/EXPLANATION Volts...
Page 6: Description
SAFETY SYMBOLS No-Hands Symbol Failure to keep your hands away from the blade will result in serious personal injury. No-Hands Symbol Failure to keep your hands away from the blade will result in serious personal injury. No-Hands Symbol Failure to keep your hands away from the blade will result in serious personal injury.
Page 7: Assembly
ASSEMBLY WARNING: If any parts are broken or missing, do not attempt to operate the work station until the broken or missing part is replaced. Failure to do so could result in serious injury. WARNING: Do not attempt to modify this work station or create accessories not recommended for use with this work station.
Page 8 ASSEMBLY Item Description Qty. Tabletop, rear Tabletop with scale, front Shelf Pan head screw (M6x10) Nut (M6) Countersink screw (M8x40) Nut (M8) Washer 8mm Pan head wood screw (ST5.8x14) Washer 6mm...
Page 9: Operation
OPERATION WARNING: Do not use this tool for scaffolding or as a ladder. Make sure to tighten all screws securely prior to use. Maximum capacity is 500lbs. ASSEMBLING THE LOWER AND UPPER CROSS BRACES TO THE LEGS NOTICE: Use pan head screws(K) And nuts(L) to assembly all components except the tabletop and leveling device.
Page 10 OPERATION ASSEMBLING LEVELING DEVICE (Fig.5) Assemble the leveling device into one of the footpads. Insert countersink screw (M) into pad(P). Thread countersink screw (M) with pad (P) into first nut (N). Place washer (Q) and second nut (N) on top of footpad (F).
Page 11 OPERATION Place the assembled frame upside-down onto the table tops. Thread the pan-head wood screws (R) with washers (S) through slots in the brace and into the five holes in each tabletop. NOTICE: The center screws lock the tabletops in position and have one washer (S) on the screw head and one additional washer (S) between the long upper cross brace and the tabletop (Fig.9).
Page 12: Maintenance
MAINTENANCE WARNING: When servicing, use only identical replacement parts. User of any other parts may create a hazard or cause product damage. GENERAL MAINTENANCE Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various types of commercial solvents and may be damaged by their use. Use clean clothes to remove dirt, dust, oil, grease, etc.
Page 13: Exploded View
EXPLODED VIEW...
Page 14: Parts List
240-1575-15 Shelf 240-1575-16 Tabletop, front/ Tabletop, rear WORK STATION MODEL NO. 240-1575 The model number will be found on the nameplate attached to the leg of the work station. Always mention the Model Number when ordering parts for this tool.
Page 15: Warranty
MENARDS® retail store. At its discretion, TOOL SHOP® agrees to have the tool replaced with the same or similar TOOL SHOP® product free of charge, within the stated warranty period, when returned by the original purchaser with original sales receipt.
