Rapid Deployment Wi-Fi Kit— XK-RDW Quick Start Guide Overview The Xirrus Rapid Deployment Wi-Fi Array Kit (RDK) enables fast and easy deployment of Wi-Fi service across a large area and for up to hundreds of users using a single, pre-configured device.
Page 6
No Array or power supply XK-RDW-CASE-L No Array or power supply All except XN4 The Xirrus Wi-Fi Array offers a powerful wireless solution. The capacity and performance of the Arrays that are included in kits are summarized below. Capability XK-RDW-100-N...
Page 7
The Xirrus Power over Gigabit Ethernet (PoGE) injector module supplies power to the Array over the same Cat 5e Ethernet cable that carries data traffic to the Array. The Xirrus 75W midspan injector, Model XP1-MSI-75, is supplied with all RDK versions that include an Array.
Deployment Requirements Weather and environmental considerations The Array must be kept away from moisture and dusty conditions. For outdoor use, a shaded location is preferable. The RDK includes a cover to shield the Array from basic weather conditions. The Array’s operating environment should meet these conditions: ...
Page 9
There are a number of options that may be used to provide Internet uplink connectivity for the RDK. They must meet the interface requirement for a 10 Mbps, 100 Mbps, or 1 Gbps Ethernet connection. Satellite Cable ...
Parts List The RDK is furnished in two cases. Verify that you have the following parts. For the XK-RDW-100-N/200-N 100ft Cat 5e cable 1 Xirrus Wi-Fi Array as described on DB-9 to USB page Array, Cover, and adapter &...
Passwords The Array uses the following default passwords and passkey. To manage the Array via the Web Management Interface (WMI) or Command Line Interface (CLI), enter the default username admin and the password admin. To connect to one of the Array’s predefined secure wireless networks, clients must enter the case-sensitive passkey.
Step 2 — Connect the power supply The injector supplies power and data to the Array on a single Cat 5e Ethernet cable. PoGE Injector 100-240 Data + Power Network Connection Figure 5. Power over Gigabit Ethernet (PoGE) supplies power and data to the Array Select a location for the injector.
Step 3 — Mount the Array on the tripod Remove the tripod from the travel case and place it in the selected location. In situations where the tripod is susceptible to tipping over, you should brace the tripod, for example by placing sand bags on the tripod legs.
Step 4 — Connect cables to the Array Remove the snap-on cover from the Array so that you can observe the Array’s LEDs after you connect the cables. Connections are slightly different for the XN8 and the XN4. Use the proper procedure below.
When all connections are complete: The injector’s CONNECT LED will light (green) after it senses a good connection to the Array using the supplied power. On the top of the Array, verify that the GIG1 LED is on, and that the LED boot sequence begins—the LEDs distributed around the front of the Array will light in rotation.
Page 16
If the network uses DHCP but you don’t have a reserved address and can’t examine the DHCP server tables, you have two options to find the Array address that was assigned by DHCP: • If you have an 8-, 12-, or 16-radio Array (for example, the XN8 furnished with XK-RDW-200-N), you may use an extra Ethernet cable (not supplied) to connect port Ethernet0 on the bottom of the Array directly to an Ethernet port on your laptop computer (we’ll call this the computer...
Page 17
If a window appears notifying you of a problem with the Array’s security certificate, click Continue to this website for Internet Explorer. For Firefox, click Add an exception (on two consecutive windows) until the Add Security Exception window is displayed. Click Get Certificate, and then click Confirm Security Exception. At the login prompt (Figure 10), enter the default username admin and the password...
Step 6 — Connecting wireless clients Make sure that you have all the desired settings on the Array (Alternative Settings). In particular, consider the following settings: • Do you want wireless clients to use the default, secure ConnectHereSecure network, or your own SSID? •...
Alternative Settings Settings may be changed by selecting the appropriate page from the list on the left-hand side of the WMI, as described in the procedures below. After making changes, you must click the Save button at the bottom right of the page to apply your changes and make them permanent.
To continue using WMI, you must point your browser to the new IP address. You may also wish to undo the changes you made in “Setting the IP Subnet of Your Laptop Port to Access the Array” on page Set up an open or secure Wi-Fi network, with or without DHCP The Array furnished with the RDK is shipped with predefined wireless networks (called SSIDs) that you can use to offer a secure or non-secure wireless connection, with or without having the Array assign IP addresses to clients via DHCP.
Page 21
Creating, “renaming”, and enabling SSIDs The default Array configuration presents your users with a generic name for the wireless network—for example, ConnectHereSecure. To make it easier for them to identify and connect to the correct wireless network, you may wish to use a more meaningful name, like “County Response”...
mentioned in Step 6 — Connecting wireless clients. If you set a different key for an SSID, clients must use that key to connect to the SSID. Click the Enabled checkbox for your new SSID. Uncheck the Enabled checkboxes for the other SSIDs if you do not want your clients to use them.
Change the Array host name You may wish to change the host name of the Array to something that is more meaningful to your group, for example, WorldWideEvents or CityEmergencySvcs. Figure 16. Changing the Host Name On the left of the WMI, click Express Setup. (Figure In the top section, set Host Name to the desired name.
Set the Time Zone The Array is pre-configured to use SNTP (Simple Network Time Protocol) to automatically fetch accurate time information from a public server. Thus the Array just needs to be set to your time zone so that system logs and other information will show the correct local time.
To set an IAP to use channel 191 or 195, open the IAP Settings page (also under IAPs). In the Channel column for the selected IAP, select 191 or 195 from the drop-down list. Note that 191 and 195 are not listed in numerical order. They will be at or near the top of the list.
Page 26
Make sure that your mobile broadband connection is working correctly and is able to access the Internet. Verify your Internet access by browsing to a web site. Enable Internet Connection Sharing on your host laptop. • For Windows XP From the Windows Start button, open the Control Panel and double-click Network Connections.
Page 27
• For Windows Vista or Windows 7 From the Windows Start button, open the Control Panel. Under Network and Internet, select View Network Status and Tasks. On the left, for Windows 7 click Change Adapter Settings. For Vista, click Manage Network Connections. In the Network Connections window, find your mobile broadband connection.
• The laptop will provide Network Address Translation (NAT) for DHCP addresses that it assigns. It will also provide DNS service (domain name resolution). Setting the IP Subnet of Your Laptop Port to Access the Array If you are connecting an Ethernet port on your laptop directly to the Ethernet0 port on an Array model with eight or more radios, you must change the IP address of your Computer Port to be on the same IP subnet as Ethernet0.
