- Page 1 HD 16 Channel Digital Video Recorder Quick Start Guide 8200-1368-02 A0...
- Page 2 Notice Please read this manual thoroughly and save it for future use before attempting to connect or operate this unit. The information in this manual was current when published. The manufacturer reserves the right to revise and improve its products. All specifications are therefore subject to change without notice. Copyright Under copyright laws, the contents of this manual may not be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine-readable form, in whole or in part, without...
-
Page 3: Table Of Contents
Table of Contents Important Safeguard and Warning ......................4 Hardware Installation and Connection ....................5 Check Unpacked DVR ........................5 About Front Panel and Rear Panel ....................5 After Remove the Chassis ......................5 HDD Installation ..........................5 Front Panel ............................. 6 Rear Panel ............................ -
Page 4: Important Safeguard And Warning
Important Safeguard and Warning All installation and operation here should conform to your local electrical safety codes. Tyco Security Products assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation. We are not liable for any problems caused by unauthorized modifications or attempted repair. Improper battery use may result in fire, explosion, or personal injury! When replacing the battery, please make sure you are using the same model! 1．Electrical safety... -
Page 5: Hardware Installation And Connection
All figurers listed below for reference only. Slight difference may be found on the front or rear panel. The Holis HD 16 Channel has two SATA HDDs. Loosen the screws of the Fix four screws in the Place upper cover and side panel. -
Page 6: Front Panel
Turn the device upside 5. Connect the HDD cable 6. Put cover down and then turn the screws and power cable accordance with the clip in firmly. and then place the upper cover back. Secure the screws in the rear panel and the side panel. - Page 7 Figure 2-2 Please refer to the following sheet for detailed information. Icon Name Note Alarm input ground port. Alarm input There are two types; NO (normal open)/NC (normal 1～8(16) close). port 1～8(16) When your alarm input device is using external ...
-
Page 8: Alarm Input And Output Connection
Icon Name Note RS485_A port. It is the cable A. You can connect to the RS485（RS- control devices such as speed dome PTZ. 485） RS485_B.It is the cable B. You can connect to the communicatio control devices such as speed dome PTZ. n port Power input Input 12V DC. -
Page 9: Alarm Input Port
Figure 1-3 AB cable connection Figure 1-3 You can refer to the following sheet for alarm input and output information. ALARM 1 to ALARM 16. The alarm becomes active in low voltage. 1，2，3，4，5，6， 7，8，9，10，11， 12，13，14，15，16 The first four are four groups of normal open activation output (on/off NO1 C1，... -
Page 10: Alarm Output Port
To avoid overloading, please read relay parameters sheet in the User’s Manual carefully. RS485 A/B cable is for the A/B cable of the PTZ decoder. Relay Specification JRC-27F Model: Silver Material of the touch Rating Rated switch capacity 30VDC 2A, 125VAC 1A （Resistance... -
Page 11: Overview Of Navigation And Controls
Overview of Navigation and Controls Please note the following figures are for reference only. For detailed operation instruction, please refer to the User’s Manual included in the resources CD. Before operation, please make sure: You have properly installed HDD and all the cable connections. ... -
Page 12: Startup Wizard
Startup Wizard After changed admin password interface, the system goes to the startup wizard interface. See Figure 2-5. Please refer to the user’s manual for detailed startup wizard operation information. Tips Check the box Startup button here, system goes to startup wizard again when it boots up the next time. -
Page 13: Network
Figure 2-3 Network Before the operation, please make sure you have properly connected the device to the network. If there is no router, please set the corresponding IP address. If there is a router, please set corresponding gateway and subnet mask. ... -
Page 14: Remote Device
Figure 2-5 Remote Device Note: You can see this interface after you set IP channel. System supports ONVIF standard protocol. In the main menu, from Camera ->Remote, you can go to an interface shown as in Figure 2-11. Here you can add/delete remote device and view its corresponding information. Figure 2-6... - Page 15 IP search: Click it to search IP address. It includes device IP address, port, device name, manufacturer, type. Use your mouse to click the item name, you can refresh display order. Click IP address, system displays IP address from small to large. Click IP address again, you can see icon, system displays IP address from large to small.
-
Page 16: Record Control
You can check several devices at the same time and then click the edit button . See Figure 2-13. Please check Batch modify button and then input start IP, end IP and default gateway. Figure 2-8 Record Control Note: You need to have proper rights to implement the following operations. -
Page 17: Schedule
Figure 2-9 Schedule Note: You need to have proper rights to implement the following operations. Please make sure the HDDs have been properly installed. After the system booted up, it is in default 24-hour regular mode. You can set record type and time in schedule interface. -
Page 18: Preview
Figure 2-10 Preview After you logged in, the system is in live viewing mode by default. You can see system date, time and channel name. See Figure 2-16. If you want to change system date and time, you can refer to general settings (Main Menu->Setting->System->General). -
Page 19: Playback
When current channel is When video loss alarm occurs, recording, system system displays this icon. displays this icon. When motion detection When current channel is in monitor alarm occurs, system lock status, system displays this icon. displays this icon. Tips Preview drag: If you want to change position of channel 1 and channel 4 when you are ... -
Page 20: Ptz
Usually there are four file types: R: Regular recording file. A: External alarm recording file. M: Motion detection recording file. Intel: Intelligent recoding file. Figure 2-13 Please refer to the following sheet for more information. Name Name Search engines Display pane... -
Page 21: Ptz Operation
After connecting the camera to the DVR, you need to set Control Model as HDUTC and Protocol as HD-UTC. After completed all the setups please click save button, system goes back to the previous menu. Figure 2-14 PTZ Operation In one window display mode, right click mouse (click “Fn” Button in the front panel or click “Fn” key in the remote control) and then select PTZ, the interface is shown as in Figure 2-20. -
Page 22: Channel Type
Name Button Function Shortcut key on the front panel Fast forward Focus Near Previous Next Iris Close Backward Open Pause/Play In Figure 2-20, click to open the menu, you can set preset, tour, pattern, scan and etc. See Figure 2-21. Figure 2-16 Please refer to the following sheet for detailed information. - Page 23 Figure 2-17 Important Add/cancel IP CAM function is for some 4/8/16-channel series product only. Add IP CAM: Click it; you can add corresponding X IP channels. Here X refers to the product channel amount such as 4/8/16 (For 16-channel series product, click once, it can add 16 IP channels).
-
Page 24: Shut Down
For example, there is a 4-channel analog device, after the A/D switch, it can max supports 4 analog channels and 4 IP channels. Once it has become the 3+1 mode (3 analog channels+1 IP channel), you click button, system becomes 3+5 mode (3 analog channels+5 IP channel). Cancel IP CAM: Click it, you can cancel IP channel. - Page 25 Figure 2-20 From power on-off button on the front panel or remote control. Press the power on-off button on the DVR front panel or remote control for more than 3 seconds to shut down the device. From power on-off button on the rear panel. ...
-
Page 26: Web Operation
Web Operation Slightly difference may be found in the interface due to different series. Network Connection Before web client operation, please check the following items: Network connection is right DVR and PC network setup is right. Please refer to network setup(main menu->Setting->Network) ... -
Page 27: Wan Login
Figure 3-2 WAN Login In WAN mode, after you logged in, the interface is shown as below. See Figure 3-3. Figure 3-3 For detailed operation introduction, please refer to our resource CD included in your package for electronic version of the User’s Manual.
